Installation Instructions
Original Instructions
2090-Series Kinetix TLP Power and Feedback Cables
Catalog Numbers 2090-CTPW-MEDF, 2090-CTPW-MDDF, 2090-CTPB-MDDF, 2090-CTPW-MCDF, 2090-CTPB-MCDF, 2090-CTPB-MADF,
2090-CTPW-MADF, 2090-CTBK-MBDF, 2090-CTFB-MADD, 2090-CTFB-MFDD, 2090-CTPW-MEET, 2090-CTPW-MDET, 2090-CTPB-MDET,
2090-CTPW-MCET, 2090-CTPB-MCET, 2090-CTPW-MAET, 2090-CTPB-MAET, 2090-CTBK-MBET, 2090-CTFB-MFET, 2090-CTFB-MAET
Topic
Page
2
3
3
5
7
9
11

Advertisement

loading
Need help?

Need help?

Do you have a question about the Allen-Bradley Kinetix 2090 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Rockwell Automation Allen-Bradley Kinetix 2090 Series

  • Page 1: Table Of Contents

    Installation Instructions Original Instructions 2090-Series Kinetix TLP Power and Feedback Cables Catalog Numbers 2090-CTPW-MEDF, 2090-CTPW-MDDF, 2090-CTPB-MDDF, 2090-CTPW-MCDF, 2090-CTPB-MCDF, 2090-CTPB-MADF, 2090-CTPW-MADF, 2090-CTBK-MBDF, 2090-CTFB-MADD, 2090-CTFB-MFDD, 2090-CTPW-MEET, 2090-CTPW-MDET, 2090-CTPB-MDET, 2090-CTPW-MCET, 2090-CTPB-MCET, 2090-CTPW-MAET, 2090-CTPB-MAET, 2090-CTBK-MBET, 2090-CTFB-MFET, 2090-CTFB-MAET Topic Page Before You Begin Catalog Number Explanation Motor Connector/Cable Compatibility Install Kinetix TLP Motor Cables Install Continuous-flex Extension Cables...
  • Page 2: Before You Begin

    Standard (non-flex) cables can be bent or reformed during installation and maintenance. Continuous-flex cables can be flexed repeatedly within a specified bend radius when properly installed. Do not use standard cables in a continuous-flex operation. Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 3: Catalog Number Explanation

    • 2090-CTPW-MADF-xxAxx (standard, non-flex) power-only cables • 2090-CTPW-MADF-xxFxx (continuous-flex) power-only cables • TLP-A046-xxx…TLP-A100-xxx motors • Receives rectangular cable plugs • 2090-CTFB-MADD-CFAxx (standard, non-flex) drive-end connector feedback cables • 2090-CTFB-MADD-CFFxx (continuous-flex) drive-end connector feedback cables Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 4 • 2090-CTPW-MEDF-xxFxx (continuous-flex) power-only cables • Receives military style cable plugs • 2090-CTBK-MBDF-xxAxx (standard, non-flex) flying-lead brake cables • 2090-CTFB-MBDF-xxFxx (continuous-flex) flying-lead brake cables For cable specifications, refer to Kinetix Motion Accessories Technical Data, publication KNX-TD004. Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 5: Install Kinetix Tlp Motor Cables

    The motor-end (rectangular) connector that is 19.0 mm (0.75 in.) square, requires a 26 mm (1.02 in.) hole to pass through. The motor-end (military-style) connector that is 37.2 mm (1.50 in.) diameter, requires a 48 mm (1.89 in.) hole to pass through. Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 6 The motor-end (military-style) connector that is 43.0 (1.69) diameter, requires a 53 mm (2.09 in.) hole to pass through. The motor-end (military-style) connector that is 55.2 mm (2.17 in.) diameter, requires a 65 mm (2.56 in.) hole to pass through. Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 7: Install Continuous-Flex Extension Cables

    (2) The motor-end (rectangular) connector that is 19.0 mm (0.75 in.) square, requires a 26 mm (1.02 in.) hole to pass through. The motor-end (military-style) connector that is 37.2 mm (1.50 in.) diameter, requires a 48 mm (1.89 in.) hole to pass through. Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 8 The motor-end (military-style) connector that is 55.2 mm (2.17 in.) diameter, requires a 65 mm (2.56 in.) hole to pass through. Brake Cable Dimensions Bend Area or Continuous Flexing Area Dimensions are in mm (in.) Cable 2090-CTBK-MBET-20Fxx (reference only) Bend Radius Bend Radius Diameter Connector Diameter Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 9: Pinout Specifications

    6 and 4 AWG Cables A H G Shield-to-ground connections required. 2090-CTPW-MCDF-xxFxx 2090-CTPW-MDDF-xxFxx 2090-CTPW-MCDF-xxAxx 2090-CTPW-MDDF-xxAxx 2090-CTPB-MCDF-xxFxx 2090-CTPB-MDDF-xxFxx 2090-CTPB-MCDF-xxAxx 2090-CTPW cables exclude (BR+/BR–) motor brake conductors. 2090-CTPB-MDDF-xxAxx 16 and 12 AWG Cables 12 and 8 AWG Cables Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 10 12 AWG and 8 AWG Cables A H G 2090-CTPW-MCET-xxFxx 2090-CTPB-MCETxxFxx 16 AWG and 12 AWG Cables 2090-CTPW-MCET and 2090CTPW-MDET cables exclude the Red and Black twisted pair conductors. Brake Only Extension Cable Pinout Black 2090-CTBK-MBET-20Fxx Foil Rockwell Automation Publication 2090-IN046A-EN-P - December 2019...
  • Page 11: Additional Resources

    White/Red White Shield/Drain 2090-CTFB-MAET-CFFxx Additional Resources These documents contain additional information concerning related products from Rockwell Automation. Resource Description Provides product specifications for Kinetix VPL, VPC, VPF, VPH, VPS, Kinetix MPL, MPM, MPF, Kinetix Rotary Motion Specifications Technical Data, publication KNX-TD001 MPS, Kinetix TLP, Kinetix TL and TLY, and Kinetix HPK rotary motors.
  • Page 12 How Are We Doing? form at http://literature.rockwellautomation.com/idc/groups/literature/documents/du/ra-du002_-en-e.pdf. Rockwell Automation maintains current product environmental information on its website at http://www.rockwellautomation.com/rockwellautomation/about-us/sustainability-ethics/product-environmental-compliance.page. Allen-Bradley, Kinetix, LDC-Series, LDL-Series, Rockwell Automation, and Rockwell Software are trademarks of Rockwell Automation, Inc. EtherNet/IP is a trademark of ODVA, Inc.
