U1T Series Dome Camera
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the models below:
Type
Type I Camera
Type II Camera
Type III Camera
This manual may contain technical incorrect places or
printing errors, and the content is subject to change
without notice. The updates will be added to the new
version of this manual. We will readily improve or update
the products or procedures described in the manual.
TURBO HD
User Manual
Model
DS-2CE59U1T-(A)VPIT3ZF
DS-2CE56U1T-(A)ITZF
DS-2CE5AU1T-(A)VPIT3ZF
0100001080708

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CE59U1T-VPIT3ZF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HIKVISION DS-2CE59U1T-VPIT3ZF

  • Page 1 TURBO HD U1T Series Dome Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the models below: Type Model Type I Camera DS-2CE59U1T-(A)VPIT3ZF DS-2CE56U1T-(A)ITZF Type II Camera...
  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4 To avoid heat accumulation, good ventilation is  required for the operating environment. Keep the camera away from liquid while in use for non-  water-proof device. While in delivery, the camera shall be packed in its  original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark...
  • Page 5: Installation

    Note: Press and hold the switch button for 5 seconds to switch the video output. Four kinds of video outputs are available: TVI, AHD, CVI, and CVBS. 1.2.3 Overview of Type III Camera Figure 1-3 Overview of Type III Camera Note: Press and hold the switch button for 5 seconds to switch the video output.
  • Page 6 Type I Camera Type II Camera Figure 2-1 The Drill Template Note: Drill the cable hole, when adopting the ceiling outlet to route the cable. 3. Loosen the screws on the bubble of the dome camera to remove the bubble and the black liner. 4.
  • Page 7 Type I Camera 0° to 355° 0° to 75° 0° to 355° Figure 2-4 3-Axis Adjustment 9. Fit the black liner back to the camera and tighten the screws on the bubble of the dome camera to finish the installation. 2.2 Wall Mounting of Type I and Type II Camera Before you start: You need to purchase a wall mount first.
  • Page 8 Steps: 1. Paste the drill template to the celling. 2. Drill screw holes and the cable hole (optional) on the ceiling according to the supplied drill template. Figure 2-7 The Drill Template Note: Drill the cable hole (hole A) when adopting the ceiling outlet to route the cable.
  • Page 9 8. Fit the bubble back to the camera. Figure 2-11 Fit the Black Liner Back 9. Tighten the screws on the bubble of the dome camera to finish the installation. Figure 2-12 Finish Installation 2.4 Wall Mounting of Type III Camera Before you start: You need to purchase a wall mount first.
  • Page 10: Menu Description

    3 Menu Description Purpose: Call the menu by clicking the button on the PTZ Control interface, or call preset No.95. Steps: 1. Connect the camera with the TVI DVR, and the monitor, shown as the figure 3-1. Figure 3-1 Connection 2.
  • Page 11: Video Format

    3). Click left/right direction button to adjust the value of the selected item. 3.1 VIDEO FORMAT You can set the video format as 8MP@12.5 fps, 8 MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps, and 2MP@30fps. Note: When switching the video output as CVBS, you can ...
  • Page 12 B & W (Black and White) The image is black and white all the time, and the IR LIGHT turns on in the poor light conditions. You can turn on/off the IR LIGHT and set the value of SMART IR in this menu Figure 3-4 B &...
  • Page 13: Video Settings

    3.4 VIDEO SETTINGS Move the cursor to VIDEO SETTINGS and click Iris+ to enter the submenu. IMAGE MODE, WHITE BALANCE, BRIGHTNESS, CONTRAST, SHARPNESS, SARUTATION, DNR, and MIRROR are adjustable. VIDEO SETTINGS IMAGE MODE WHITE BALANCE BRIGHTNESS CONTRAST SHARPNESS SATURATION MIRROR BACK EXIT SAVE &...
  • Page 14: Factory Default

    SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce. You can set the SHARPNESS value from 1 to 9. SATURATION Adjust this feature to change the saturation of the color. The value ranges from 1 to 9. DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light...
