NEXSYS
TM
Line Interactive UPS Expandable Runtime Battery
User Manual
100-00071 Rev A
22
PA P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIDDLE ATLANTIC NEXSYS UPX-EXPANRUN-10-15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LEGRAND MIDDLE ATLANTIC NEXSYS UPX-EXPANRUN-10-15

Summary of Contents for LEGRAND MIDDLE ATLANTIC NEXSYS UPX-EXPANRUN-10-15

  • Page 1 NEXSYS Line Interactive UPS Expandable Runtime Battery User Manual 100-00071 Rev A PA P...
  • Page 2 All other brand names or marks are used for identification purposes and are trademarks of their respective owners. All patents are protected under existing designations. Other patents pending. Legrand AV Inc. Brands: Chief | Da-Lite | Middle Atlantic Products | Projecta | Sanus | Vaddio ©2022 | Legrand AV, Inc.

  • Page 3: Table Of Contents

    Connecting the Expandable Runtime Battery Option to Your UPS........... 16 Basic Operation and Feature Set ..................... 20 Replacing the Battery ........................21 Replacing the Power Cord (if Necessary) ..................23 Specifications ........................... 24 Warranty ............................27 ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 4: Important Safety Instructions

    Do not connect appliances or devices to the UPS output sockets or terminal that would over load the UPS. Place cables in such a way that no one can step on or trip over them. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 5 Risk of electric shock. Even after the unit is disconnected from the mains (building wiring outlet); components inside the UPS system are still connected to the battery and are electrically live and dangerous. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 6 Do not open or destroy batteries. Escaping electrolyte can cause injury to the skin and eyes. It may be toxic. Only replace the fuse with the same type and amperage to avoid fire hazards. Do not disassemble the UPS system. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 7: Instructions De Sécurité Importantes

    DANGEREUSE produit qui peut être d'une ampleur suffisante pour constituer un risque d'électrocution. Un avertissement vous avertit d'une situation pouvant entraîner des blessures AVERTISSEMENT graves ou la mort. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 8 Lors de l'installation de l'équipement, assurez-vous que la somme du courant de fuite de l'onduleur et des périphériques connectés ne dépasse pas 3.5 mA. Température nominale: Les unités sont considérées acceptables pour une utilisation dans un environnement ambiant maximal de 40°C (104°F). viii ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 9 Avant de toucher, vérifiez s'il n'y a pas de tension. Ne jetez pas les piles dans un feu. Les piles peuvent exploser. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 10 à ses propres frais. Les changements ou modifications non expressément approuvés par la partie responsable de la conformité pourraient annuler l'autorité de l'utilisateur à utiliser l'équipement. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 11: Supplied Components And Hardware

    1, 1.5, or 2KVA Expandable Runtime Battery Unit Power Cord Expandable Battery Communication Cable IEC to IEC Short Cord User Manual To order more hardware, contact support at av.middleatlantic.techsupport@legrand.com NOTE (866) 977-3901. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 12: Required Tools

    First, use the supplied power cord (D) and directly plug your expandable runtime battery NOTE into AC power and allow it to charge for eight hours before connecting it to your UPS and providing direct backup power to connected devices. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 13: Understanding Ups And Expandable Runtime Battery Installation Requirements

    This procedure requires at least one additional person. AVERTISSEMENT Cette procédure nécessite au moins une personne supplémentaire. Carefully team lift your expandable runtime battery (A), remove it from the packaging, and place it on an appropriate work surface. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 14 Use power driver, #2 Phillips bit, and (8x) rackscrews (not provided) to attach the ears on the back rail sliders to rear rackrails at the desired height inside of your enclosure. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 15 Rear Rackrails Front Rackrails Use power driver and (8x) rackscrews (not provided) to attach the ears on the front rail sliders to the front rackrails on your enclosure. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 16: Connecting The Expandable Runtime Battery Option To Your Ups

    If you are adding exactly one expandable runtime battery to your UPS system, you may NOTE decide to leave the main connector port screw and plate intact on your expandable runtime battery, if desired. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 17 15A UPS Model Shown INPUT BATTERY PACK BREAKER Expandable DETECTION Runtime BREAKER Battery Option Expandable Battery Expandable Battery Communication Cable (C) Main Connector Cord (B) ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 18 UPS as shown. Cord Retainer Hook ends of retainer Press inward on through input post holes. retainer sides. ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 19 Press the power button on the UPS to turn on the system. For more information, refer to “Understanding the UPS Power Button” in the Line Interactive UPS User Manual (100-00072) at www.legrandav.com. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 20: Basic Operation And Feature Set

    (C) in either of these ports and connect the other end into the EXB port on your UPS or another expandable runtime battery option (if purchased) to transmit data between the units. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 21: Replacing The Battery

    Squeeze and pull apart both battery wire connections to separate them as shown. Battery Wire Connections Use screwdriver to remove the set screws from each battery cover as shown. Battery Covers Screws ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 22 à votre revendeur en utilisant un emballage de batterie de remplacement, le cas échéant. Slide your new batteries into the front openings. New Batteries Use screwdriver and set screws to re-attach the battery covers. Battery Covers Screws ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 23: Replacing The Power Cord (If Necessary)

    Tout câble d'alimentation utilisé avec cet appareil doit répondre aux spécifications répertoriées dans cette rubrique. Your battery may require a longer length and/or replacement power cable. When replacing the cable with Legrand or any other supplier, the following specifications are required for 1K/1.5K UPS and 2K UPS products, respectively.

  • Page 24: Specifications

    Circuit Breaker Power Cord Length 6' (1.83M) Output Model UPX-EXPANRUN-10-15 UPX-EXPANRUN-20 Voltage 36VDC 48VDC Amperage DC Switch Manual DC breaker. Disables DC output to battery main connector. BTU (Line Mode) BTU (Battery Mode) ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 25 Model UPX-EXPANRUN-10-15 UPX-EXPANRUN-20 Operating Temperature and 32⁰ F (0⁰ C) – 104⁰ F (40⁰ C) Relative Humidity 0% – 95% Non-Condensing Storage Temperature 5⁰ F (-15⁰ C) – 113⁰ F (45⁰ C) ©2022 | Legrand AV, Inc. All rights reserved.
  • Page 26 Tested to UL 1778 & CAN CSA-C22.2 standards. EMI Standards FCC Class A Environmental RoHS REACH Compliant Warranty Model UPX-EXPANRUN-10-15 UPX-EXPANRUN-20 Standard Three Years Limited (2 Years Battery) For warranty information, refer to legrandav.com/policies/warranty_information. ©2022 | Legrand AV, Inc. All rights reserved.

  • Page 27: Warranty

    Legrand | AV Headquarters 6436 City West Parkway Eden Prairie, MN, 55344, USA At Legrand AV Inc. we are always listening. Your comments are welcome. Legrand AV is an ISO 9001 and ISO 14001 Registered Company. ©2022 | Legrand AV,...
