- Page 1 RENOGY Core Series Deep Cycle Lithium Iron Phosphate Battery 12.8V 100Ah VERSION A0 RBT12100LFP-US USER MANUAL...
- Page 2 Renogy is not responsible or liable for any failure, damage, or injury resulting from repair attempts by unqualified personnel, improper installation, or inappropriate operation.
-
Page 3: Table Of Contents
Step 7. Install the Insulating Sleeves ....................7 Step 8. Connect the Battery to Other Devices ..................8 How to Connect Renogy Core Batteries in Series or Parallel ............... 9 Calculate Voltage and Current in Series and Parallel Connections ..............9 Balance Batteries Prior to Connection ......................9... - Page 4 Maintenance & Storage ......................... 17 Inspection .................................17 Cleaning ................................17 Checking Voltage ..............................17 Storage ................................17 Important Safety Instructions ....................... 18 General ................................18 Battery Safety ..............................18 Renogy Support ........................... 19...
-
Page 5: Symbols Used
NOTE: Indicates an important step or tip for optimal performance. Introduction The Renogy Core Series 12.8V 100Ah Deep Cycle Lithium Iron Phosphate Battery is designed for the drop-in replacement of deep-cycle lead-acid batteries with its standard Battery Council International (BCI) group size. -
Page 6: What's In The Box
What’s In the Box? Renogy Core Series 12.8V 100Ah Deep Cycle RENOGY Core Series Deep Cycle Lithium Iron Phosphate Battery Lithium Iron Phosphate Battery × 1 12.8V 100Ah VERSION A0 RBT12100LFP-US USER MANUAL User Manual × 1 M8*1.25*20 mm Insulating Sleeve × 2 Long Terminal Bolt ×... -
Page 7: Get To Know Deep Cycle Lithium Iron Phosphate Battery
Get to Know Deep Cycle Lithium Iron Phosphate Battery Negative Terminal (M8) Positive Terminal (M8) Li Handles Dimensions 10.6 in (260 mm) 6.9 in (169 mm) 8.6 in (211 mm) Dimension tolerance: ±0.2 in (0.5 mm) — 3 —... -
Page 8: How To Size Battery Adapter Cables
How to Size Battery Adapter Cables? Use appropriately sized Battery Adapter Cables (sold separately) based on expected load. Refer to the table below for copper cable ampacities with different gauge sizes. Cable Gauge Size Ampacity Cable Gauge Size Ampacity 14 AWG (2.08 mm²) 2 AWG (33.6 mm²) 190A 12 AWG (3.31 mm²) -
Page 9: Step 1. Plan A Mounting Site
Step 1. Plan a Mounting Site For optimal battery performance, it is recommended to install the battery in a clean, cool, and dry location, free from any accumulation of water, oil, or dirt. Accumulation of such materials on the battery can lead to current leakage, self-discharge, and even short-circuiting. -
Page 10: Step 3. Remove The Dust Cover
Step 3. Remove the Dust Cover. Step 4. Check the Battery Inspect the battery for any visible damage including cracks, dents, deformation, and other visible abnormalities. All connector contacts shall be clean, free of dirt and corrosion, and dry. Do not touch the exposed electrolyte or powder if the battery is damaged. If uncovered electrolyte or powder contacts your skin or eyes, flush it out immediately with plenty of clean water and seek medical attention. -
Page 11: Step 6. Install Battery Terminals
Step 6. Install Battery Terminals Long Terminal Bolts Spring Washer Flat Washer 10 N·m Battery Battery Adapter Adapter Cable Cable Ensure the cable lug and the top surface of the terminal are in contact, and place the washers on top of the lug. -
Page 12: Step 8. Connect The Battery To Other Devices
Step 8. Connect the Battery to Other Devices Please use circuit breakers, fuses, or disconnects appropriately sized by a certified electrician, licensed installers, or regional code authorities to protect all electrical equipment. █ For a Single Battery Inverter DC-DC Charger Battery Fuse DC Distribution Charge Controller... -
Page 13: How To Connect Renogy Core Batteries In Series Or Parallel
How to Connect Renogy Core Batteries in Series or Parallel Calculate Voltage and Current in Series and Parallel Connections Parallel Connection Series Connection 12V(12.8V) 400Ah 48V(51.2V) 100Ah 12.8V 12.8V 100Ah 100Ah 12.8V 12.8V 100Ah 100Ah 12.8V 12.8V 100Ah 100Ah 12.8V 12.8V... -
Page 14: Series Connection Vs. Parallel Connection - Installation Steps
Step 2: Use a voltmeter to measure the voltage of each battery. It is best to keep the voltage difference of each battery less than 0.1V. Step 3: Connect all the batteries in parallel and allow them to rest together for 12 to 24 hours. 12~24h It is recommended to periodically rebalance the battery voltages every six months when connecting multiple batteries as a battery system. - Page 15 Battery System 12V (12.8V) 200Ah Energy 2560Wh Battery System 12V (12.8V) 800Ah Energy 10240Wh █ Series Connection Battery System 24V (25.6V) 100Ah Energy 2560Wh Battery System 48V (51.2V) 100Ah Energy 5120Wh █ Parallel & Series Connection Battery System 24V (25.6V) 200Ah 2P2S Energy 5120Wh...
-
Page 16: Battery Cell Balancing
Battery System 48V (51.2V) 200Ah 2P4S Energy 10240Wh Battery System 24V (25.6V) 400Ah 4P2S Energy 10240Wh Battery Cell Balancing The battery employs bypass circuit to maintain the balance between each battery cell group. Each battery cell group is connected with a bypass resistor and a switch in parallel. During the charging process, if the highest- voltage battery cell group reaches the set balancing starting voltage and the voltage difference between the highest-voltage and the lowest-voltage battery cell group exceeds the set voltage difference, the switch connected to the highest-voltage battery cell group will be closed to shunt the charge current around the... -
Page 17: Battery Charging And Discharging Logic
█ Discharge Low Voltage Reconnect 12.6V Undervoltage Warning 12.0V Undervoltage Shutdown 10.0V The parameters in the table are applicable to 12V (12.8V) battery packs. Please multiply by 2 for 24V (25.6V) packs and multiply by 4 for 48V (51.2V) packs. Battery Charging and Discharging Logic The battery may be received at a partial state of charge (SOC) depending on the time between manufacturing and shipping. -
Page 18: Discharging Logic
Discharging Logic During standard discharging, the battery is discharged at a constant current of 50A until the voltage drops to 10V. To ensure safe discharging, the battery temperature should be between -4°F (-20°C) and 131°F (60°C). To ensure safe and optimal battery usage, it is recommended to pair the battery with discharge equipment that features a low voltage disconnect (LVD) function. -
Page 19: Troubleshooting
Disconnect the battery from the charging source or loads as soon as possible. too high current passing through during charging or the battery. discharging. For further assitance, contact Renogy technical support service at https://www.renogy.com/contact- — 15 —... -
Page 20: Specifications
Specifications General Battery Cell Type Lithium Iron Phosphate Rated Capacity (0.5C, 25°C) 100Ah Nominal Voltage 12.8V Voltage Range 10V to 14.8V Cycle Life (0.5C, 25°C) 5000 Cycles (80% DOD) Dimension 10.6 x 6.9 x 8.6 in / 260 x 169 x 211 mm Weight 23.15 lbs. -
Page 21: Maintenance & Storage
Maintenance & Storage Inspection Please perform regular inspections following the steps below: z Examine the external appearance of the battery. The housing and terminals of the battery shall be clean, dry, and free of corrosion. z Check battery cables and connections. Replace any damaged cables and tighten any loose connections. In certain application scenarios, corrosion may occur around the terminals. -
Page 22: Important Safety Instructions
Important Safety Instructions The manufacturer accepts no liability for any damage caused by: z Force majeure including fire, typhoon, flood, earthquake, war, and terrorism. z Intentional or accidental misuse, abuse, neglect or improper maintenance, and use under abnormal conditions. z Improper installation, improper operation, and malfunction of a peripheral device. z Contamination with hazardous substances or radiation. -
Page 23: Renogy Support
Renogy Support To discuss inaccuracies or omissions in this quick guide or user manual, visit or contact us at: renogy.com/support/downloads contentservice@renogy.com For technical questions about your product in the U.S., contact the Renogy technical support team through: renogy.com/contact-us 1(909)2877111 For technical support outside the U.S., visit the local website below: Canada ca.renogy.com... - Page 24 Save 105 gallons of water from being consumed Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
