- Page 1 RENOGY Core Series Deep Cycle Lithium Iron Phosphate Battery 12.8V 50Ah RBT1250LFP VERSION A0 USER MANUAL...
-
Page 2: Before Getting Started
Renogy is not responsible or liable for any failure, damage, or injury resulting from repair attempts by unqualified personnel, improper installation, or inappropriate operation. -
Page 3: Safety Precautions
Caution Danger Emergency Eye Protection Risk Of Fire Highly High Voltage Eye Wash Must Be Worn Flammable Material Any uncoverd battery material such as Terminals of electrolyte or powder the Lithium Iron ALWAYS wear on the skin or in Phosphate Battery are DO NOT touch protective clothing the eyes must be... -
Page 4: Battery Operation
Inspect the battery for any visible damage including cracks, dents, deformation, and other visible abnormalities. All connector contacts shall be clean, free of dirt and corrosion, and dry. z Step 4: Size the battery cables appropriately. Use high stranded copper and heavy gauge cables to handle possible loads from the battery. Make sure to maintain identical cable lengths. -
Page 5: Battery Storage
Battery Storage z Please charge the battery to 30%~50% and store the battery in an open, well-ventilated, dry, clean area with temperatures of around 25°C (77°F). z Long periods of storage can deteriorate the battery performance. It is recommended to charge the battery at least once every three months to prevent over-discharge. - Page 6 Length 198 mm / 7.8 in Dimensions Width 165 mm / 6.5 in Height 169 mm / 6.7 in Mechanical Weight 5.35 kg / 11.8 lbs Properties Housing Material ABS+PC Terminal Model M8 x 1.25 x 16 mm Additional Terminal Model M8 x 1.25 x 20 mm Protection Circuit Module (PCM) Specifications Battery Operating Status...
- Page 7 Questionnaire Investigation To explore more possibilities of solar systems, visit Renogy Learning Center at: renogy.com/learning-center For technical questions about your product in the U.S., contact the Renogy technical support team through: 1(909)2877111 renogy.com/contact-us For technical support outside the U.S., visit the local website below: Canada ca.renogy.com...
- Page 8 Save 105 gallons of water from being consumed Renogy Power PLUS Renogy Power Plus allows you to stay in the loop with upcoming solar energy innovations, share your experiences with your solar energy journey, and connect with like-minded people who are changing the world in the Renogy Power Plus community.
