Summary of Contents for Avantco 177SSH7V
- Page 1 User Manual User Manual Stainless Steel Horizontal Sausage Stuffers Models: 177SSH7V, 177SSH11V, 177SSH15V 06/2021 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
- Page 2 User Manual General Safety Regulations WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions or situations that could occur. It must be understood by the operator that common sense and caution are factors that cannot be built into this product, but must be supplied by the operator.
- Page 3 User Manual Assembly and Installation STUFFER ASSEMBLY 1. Attach the Handle by sliding it onto either the Fast or the Slow Gear. 2. Crank the Handle to bring the Plunger to the top of the Stuffer. 3. Rest the Canister’s Bottom Brackets onto the Canister Mounts inside the Housing of the Stuffer. 4.
- Page 4 User Manual Stuffing Instructions CAUTION! When the plunger is pulled out of the Canister, STUFFING TIPS: RELEASE THE HANDLE SLOWLY! Pressure or gravity could The following are suggestions to help reduce the cause the Handle to spin back slightly and cause injury. resistance when stuffing with the 13 mm Stuffing Funnel.
- Page 5 User Manual Exploded Diagram and Parts List Part # Description Part # Description Front Ring Nut Slow Speed Control Gear Stainless Steel Funnel Set (4 Funnels) Gear Housing Cover Bottom Plate w/ Hardware Kit Stainless Steel Canister Gear Housing w/ Hardware Kit Pressure Release Valve (4 Piece Set) Fast Speed Control Gear Plunger Seal...
- Page 6 Equipment Limited Warranty Avantco warrants its equipment to be free from defects in material and workmanship for a period of 1 year. This is the sole and exclusive warranty made by Avantco covering your Avantco brand equipment. A claim under this warranty must be made within 1 year from the date of purchase of the equipment.
