Calrod Food Warmer/Strip Heater
Models:
177SW24T, 177SW36T, 177SW48T, 177SW60T, 177SW72T,
177SW24IN, 177SW36IN, 177SW48IN, 177SW60IN, 177SW72IN,
177SW24TCP, 177SW36TCP, 177SW48TCP, 177SW60TCP, 177SW72TCP,
177SW24INCP, 177SW36INCP. 177SW48INCP, 177SW60INCP, 177SW72INCP
Please read and keep these instructions. Indoor use only.
www.AvantcoEquipment.com
User Manual
User Manual
06/2020
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Avantco 177SW24T
Summary of Contents for Avantco 177SW24T
- Page 1 User Manual High Wattage Calrod Food Warmer/Strip Heater Models: 06/2020 177SW24T, 177SW36T, 177SW48T, 177SW60T, 177SW72T, 177SW24IN, 177SW36IN, 177SW48IN, 177SW60IN, 177SW72IN, 177SW24TCP, 177SW36TCP, 177SW48TCP, 177SW60TCP, 177SW72TCP, 177SW24INCP, 177SW36INCP. 177SW48INCP, 177SW60INCP, 177SW72INCP Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
-
Page 2: Table Of Contents
User Manual Index Introduction ................... 3 Requirements and Safety Instructions ..........3 Overview ....................4 Operation ....................5 Installation .................... 5 Cleaning ....................5 Parts Diagram ..................6 - 7 Wiring Diagram ..................8 Limited Warranty ................... 9 www.AvantcoEquipment.com... -
Page 3: Introduction
User Manual Introduction, Requirements and Safety Introduction 1. Please read instructions before using this appliance. This appliance is for commercial use only. 2. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and injury. 3. -
Page 4: Overview
User Manual Overview Toggle Hardwired MODEL # OVERALL DIMENSIONS POWER SUPPLY NET WEIGHT 177SW24T 24" L x 6.1"W x 2.6"H 120V, 500W 7.7 lb 177SW36T 36"L x 6.1"W x 2.6"H 120V, 850W 11 lb 177SW48T 48"L x 6.1"W x 2.6"H 120V, 1200W 14.33 lb... -
Page 5: Operation
User Manual Operation 1. Plug cord into grounded electrical outlet of the correct voltage. Electrical shock can occur if appliance is not grounded. 2. Flip the switch to the 'On' position. 3. Place food products directly under the elements for best results. 4. -
Page 6: Parts Diagram
177PSWGUARD (177SW24/36/48/60/72T; 177SW24/36/48/60/72TCP) Element Support 177PSWELEM1 (177SW24/36/48/60/72T; 177SW24/36/48/60/72TCP) (Mid) Reflector Element Support (Left) 177PSWELEM2 (177SW24/36/48/60/72T; 177SW24/36/48/60/72TCP) Cover Plate 177PSWELEM3 (177SW24T/TCP), 177PSWELEM4 (177SW36T/TCP), 177PSWELEM5 Element (177SW48T/TCP), 177PSWELEM6 (177SW60T/TCP), 177PSWELEM7 (177SW72T/72TCP) Housing Mounting Brackets 177PBRACKET (177SW24/36/48/60/72T; 177SW24/36/48/60/72TCP) Indicator Light 177PLIGHTORG (177SW24/36/48/60/72T; 177SW24/36/48/60/72TCP) Terminal Block 177PSWTB (177SW24/36/48/60/72T;... - Page 7 User Manual Parts Diagram - Infinite Control Description Replacement Part# Pcs. Knob 177PSWKNOB (177SW24/36/48/60/72IN, 177SW24/36/48/60/72INCP) Knob Base End Plates Element Guard 177PSWGUARD (177SW24/36/48/60/72IN, 177SW24/36/48/60/72INCP) Element Support 177PSWELEM1 (177SW24/36/48/60/72IN, 177SW24/36/48/60/72INCP) (Mid) Reflector Element Support (Left) 177PSWELEM2 (177SW24/36/48/60/72IN, 177SW24/36/48/60/72INCP) Cover Plate 177PSWELEM3 (177SW24IN/24INCP), 177PSWELEM4 (177SW36IN/36INCP), Element 177PSWELEM5 (177SW48IN/48INCP), 177PSWELEM6 (177SW60IN/60INCP), 177PSWELEM7 (177SW72IN/72INCP)
-
Page 8: Wiring Diagram
User Manual Wiring Diagram - Toggle Control 120VAC 60HZ Description Switch Heater Indicator Wiring Diagram - Infinite Control 120VAC 60HZ Description Energy Regulator Heater Indicator www.AvantcoEquipment.com... -
Page 9: Limited Warranty
Equipment Limited Warranty Avantco warrants its equipment to be free from defects in material and workmanship for a period of 1 year. This is the sole and exclusive warranty made by Avantco covering your Avantco brand equipment. A claim under this warranty must be made within 1 year from the date of purchase of the equipment.
