Summary of Contents for Avantco 177CU30ETL
- Page 1 User Manual User Manual Stainless Steel Coffee Urn Models: 177CU30ETL 10/2021 Please read and keep these instructions. Indoor use only. www.AvantcoEquipment.com...
-
Page 2: Table Of Contents
User Manual NOTE: Save these instructions for future reference. Index Important Safety Information ............. 3 Specifications ..................4 Coffee Measuring Guide ..............4 Prior to First Use ..................5 Helpful Hints ..................5 How to Use ...................5 Boil Dry Protection & Manual Reset Button ........6 Cleaning &... -
Page 3: Important Safety Information
User Manual IMPORTANT SAFETY INFORMATION 1. Read all instructions carefully. Remember to follow basic safety measures when using electrical equipment. 2. Only use urn with a grounded 120V AC socket. 3. Do not use the coffee urn if the cord or plug is damaged. Replace before use. a. -
Page 4: Specifications
User Manual Specifications MODEL NO. POWER VOLTAGE VOLUME 177CU30ETL 950W 120V/60Hz 30 cups Coffee Measuring Guide CUPS (5 OZ. SERVING) GROUND COFFEE (8 OZ. DRY) 12-15 3/4 Cup 20-25 1 1/2 Cups 2 Cups www.AvantcoEquipment.com... -
Page 5: Prior To First Use
User Manual Prior to First Use 1. Remove all packaging from inside and outside of the coffee urn. 2. Bring water to a boil, then discard. This clears the urn of any packaging residue. Helpful Hints 1. Do not use soft water. Soft water may cause the coffee basket to flood. 2. -
Page 6: Boil Dry Protection & Manual Reset Button
User Manual Boil Dry Protection & Manual Reset Button Boil dry accidents are the result of boiling all the water out of an urn. These kinds of accidents shorten component and product life in all water boiling appliances. To prevent boil dry accidents, this appliance is equipped with a thermal limiter with a manual reset button (see below picture). -
Page 7: Cleaning & Maintenance
User Manual Cleaning and Maintenance 1. Unplug the unit and pour out any remaining water or coffee. Allow the unit to cool. 2. After the urn has cooled, add hot water, brush the interior sides, and rinse with hot water until water exiting the faucet runs clear. -
Page 8: Electric Circuit Diagram
User Manual Electrical Circuit Diagram Thermal Fuse This coffee urn is fitted with a thermal fuse for added safety. If this appliance’s boil dry protection measures fail, its thermal fuse will activate and shut off the appliance. The thermal fuse is a one-time-use component. Once it activates, the fuse automatically breaks and cannot be used again. -
Page 9: Warranty
Equipment Limited Warranty Avantco warrants its equipment to be free from defects in material and workmanship for a period of 6 months. This is the sole and exclusive warranty made by Avantco covering your Avantco brand equipment. A claim under this warranty must be made within 6 months from the date of purchase of the equipment.
