  • Page 1 OE-Level Diagnostic Tablet...
  • Page 2 WELCOME TO THE INNOVA FAMILY! Hello... On behalf of everyone at INNOVA, we want to welcome you and thank you for purchasing the SDS Inspector! Every automotive diagnostic scan tool we make includes tons of INNOVA ® pro-level features designed to help maximize, and simplify, your OBD2 diagnostic routine. In this manual, we will guide you on how to access your tablet’s intuitive functions including:...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS LEGAL INFORMATION � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 1 FCC Compliance Statement � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �1 Trademarks �...
  • Page 4 TABLE OF CONTENTS OBD2 Report � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 17 Erasing Diagnostic Trouble Codes (DTCs) - $04 �...
  • Page 5 TABLE OF CONTENTS EVAP Purge Solenoid Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 EVAP Vent Solenoid Test .
  • Page 6 TABLE OF CONTENTS A/C Clutch Manual Operation Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 CRK Pattern Clear .
  • Page 7 TABLE OF CONTENTS Wi-Fi Setting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 63 Adjusting Display Brightness �...

  • Page 8: Legal Information

    Licensee and End Users acknowledge such ownership, confidential information, and intellectual property rights and will not take any action to jeopardize, limit or interfere in any manner with Innova’s or its licensors’ or other suppliers’ ownership of or rights with respect to the Products and Services. The Products and Services may be protected by Patent, Trademark, Copyright and/or other intellectual property laws and by international treaties.

  • Page 9: Patents

    LEGAL INFORMATION Patents listing of trademarks, please visit https://www.innova.com/pages/trademarks. PATENTS Innova Electronics Corp. protects its intellectual property with numerous U.S. patents, which were used to research, design and manufacture this product. Please visit https://www.innova.com/pages/patents for additional information. SOFTWARE VERSION Please note that the images and functions on this manual may differ based on the current Firmware Version (FW) and Software Version you have.

  • Page 10: Safety Precautions

    SAFETY PRECAUTIONS Safety First! SAFETY PRECAUTIONS SAFETY FIRST! It is important that every user utilizing this product read all instructions and warnings included within this manual to ensure your safety, the safety of others, and to prevent damage to this product & vehicles being diagnosed and repaired.

  • Page 11: Safety Alert Icons

    SAFETY PRECAUTIONS Safety Alert Icons SAFETY ALERT ICONS As you read this manual, color-coded icons are used throughout to identify safety alerts and warnings. These are provided to help prevent serious injury to you, injury to bystanders, and damage to property or equipment. They are characterized as follows: Yellow Icon –...

  • Page 12: Introduction

    INTRODUCTION Tablet Controls and Indicators INTRODUCTION TABLET CONTROLS AND INDICATORS See Figure 1 for the locations of items 1 through 11, below. 4.3-inch LCD Screen - Color LCD display shows menus sub-menus, test results, tablet functions and vehicle status information. Diagnostic Port - Connects the Tablet to the vehicle’s Data Link Connector (DLC).

  • Page 13: Tablet Display Functions

    INTRODUCTION Tablet Display Functions TABLET DISPLAY FUNCTIONS See Figure 2 for the locations of items 1 through 19 below. I/M MONITOR STATUS: SINCE DTCs CLEARED field - Identifies the I/M Monitor status area. Indicate which Monitor icons Monitors are supported by the vehicle under test, and whether or not the associated Monitor has completed its diagnostic testing (Monitor status).

  • Page 14: Technical Specifications

    (Captured when Priority Code was set / Code #1). 16. I/M STATE – Displays acronym of I/M program location. Wi-Fi Icon – When OFF, indicates there is no Wi-Fi connection. Bluetooth Icon – Indicates communication status with a compatible INNOVA mobile application. A solid ®...

  • Page 15: The Repairsolutionspro™ App

    *Manufacturer reserves the right to change technical specifications at any time. THE RepairSolutionsPRO™ APP Innova’s RepairSolutionsPRO (RSPRO) app is a web-based service created to assist Professional technicians simplify and augment their vehicle diagnostic process. In essence, it helps you decode the diagnostic data collected by your INNOVA OBD2 Tablet to arrive at a most likely fix.

  • Page 16: Using The Repairsolutionspro App

    If you have not yet established an account, you must register for a FREE account before proceeding. Follow the screen prompts to pair your INNOVA Tablet. Be sure your mobile device is connected to an available Wi-Fi network. Begin the pairing process by selecting your handheld tablet from the list.

  • Page 17: Using The Tablet

    USING THE TABLET Home Screen USING THE TABLET HOME SCREEN Home Screen provides access to all the tablet’s primary functions. See Figure 3 for the explanation of items 1 through 6, below: OBD2 Diagnostics Tab – Use to perform OBD2 menu, display 10 modes of OBD2. [See page OEM Diagnostics Tab –...

  • Page 18: Obd2 Diagnostics

    RSPRO app. The app offers additional information including Most Likely Component/System Cause for DTC, Repair Tip, and much more. [See page Enjoy your INNOVA Smart Diagnostic System! OBD2 DIAGNOSTICS The OBD2 Diagnostic provides access all 10 modes of OBD2. The following functions are available: [See page I/M Readiness Status –...

  • Page 19: I/M Readiness Status - $01, $41

    USING THE TABLET OBD2 Diagnostics I/M READINESS STATUS - $01, $41 A Drive Cycle for a Monitor requires that the vehicle is driven in such a way that all the required “Enabling Criteria” for the Monitor to run and complete its diagnostic testing are met. You can use the Tablet to view the Drive Cycle Procedures for a selected Monitor.
  • Page 20 USING THE TABLET OBD2 Diagnostics Turn the ignition OFF. Locate the vehicle’s 16-pin Data Link Connector (DLC). Connect the Tablet’s cable connector to the vehicle’s DLC. The cable connector is keyed and will only fit one way. If you have problems connecting the cable connector to the DLC, rotate the connector 180°...
  • Page 21 USING THE TABLET OBD2 Diagnostics ━ Turn the ignition OFF and disconnect the Tablet. Contact Technical Support for assistance. ━ If the Tablet can decode the Vehicle Identification Number (VIN) for the vehicle under test, the OBD2 results screen displays. Proceed to Step 9. If the Tablet cannot decode the Vehicle Identification Number (VIN) for the vehicle under test, the Vehicle Selection screen displays.
  • Page 22 USING THE TABLET OBD2 Diagnostics Yellow LED – Indicates one of the following conditions: A PENDING CODE IS PRESENT – If the yellow LED is illuminated, it may indicate a Pending code is present. Check the display for confirmation. A Pending code is confirmed by the presence of a numeric code and the word Pending.

  • Page 23: Fix For Dtcs

    Innova’s RepairSolutionsPRO reports offer a fix, which is cross referenced for accuracy against a database of millions of verified fixes. It is real-world data that has been collected for over 25 years by Innova’s network of ASE Master Technicians across the U.S. (For the RSPRO App, [See page From OBD2 Diagnostic screen, select Fix for DTCs, then press OK.

  • Page 24: Obd2 Report

    USING THE TABLET OBD2 Diagnostics To stop showing this screen, press the OK button to check the “Do not show this again” check-box, select Confirm and press OK to confirm your selection. Alternatively, select Confirm without the check mark, and press OK to not make any changes.
  • Page 25 USING THE TABLET OBD2 Diagnostics can view at a later time on your registered RSPRO app. The OBD2 Report function is available from the second DTC or from the first DTC that does not offer a Fix for DTC. This option is removed once a report has been successfully completed and will reappear after each vehicle relink.

  • Page 26: Erasing Diagnostic Trouble Codes (Dtcs) - $04

    USING THE TABLET OBD2 Diagnostics ERASING DIAGNOSTIC TROUBLE CODES (DTCs) - $04 NOTE: When the Tablet’s ERASE function is used to erase the DTCs from the vehicle’s on-board computer, “Freeze Frame” data and manufacturer-specific enhanced data are also erased. If you plan to take the vehicle to a Service Center for repair, DO NOT erase the codes from the vehicle’s computer. If the codes are erased, valuable information that might help the technician troubleshoot the problem will also be erased.

  • Page 27: Freeze Frame - $02

    USING THE TABLET OBD2 Diagnostics FREEZE FRAME - $02 If more than one Diagnostic Trouble Code (DTC) was retrieved and to view Freeze Frame Data, following procedures bellow: From OBD2 Menu, select Freeze Frame - $02 and press the OK button. The Freeze Frame data displays.

  • Page 28: Viewing Live Data

    USING THE TABLET OBD2 Diagnostics DANGER: If the vehicle must be driven in order to perform a troubleshooting procedure, ALWAYS have a second person help you. One person should drive the vehicle while the other person observes the Tablet data. Trying to drive and operate the Tablet at the same time is dangerous and could cause a serious traffic accident.

  • Page 29: Customizing Live Data (Pids)

    USING THE TABLET OBD2 Diagnostics Choose Merge Graph to view more PID results on one graph. Choose Multi Graph to view more Graphs in one screen. NOTE: The “expanded” definition functionality is available only when enabled through Settings. [See page Troubleshoot any diagnostic issues by referencing your vehicle’s repair manual to view and/or compare Live Data (PID) information displayed on the Tablet against recommended vehicle specifications.
  • Page 30 USING THE TABLET OBD2 Diagnostics Back to return to the OBD2 Menu. If custom Live Data was previously configured, the Select PIDs to Use screen displays. To use the existing custom Live Data selections, ━ select Existing PIDs, then press OK. Proceed to step 5.

  • Page 31: Record Live Data

    USING THE TABLET OBD2 Diagnostics RECORD LIVE DATA You can record and save several frames of Live Data information for each PID supported by the vehicle in the Tablet’s memory. Once recorded, each session can be played back for further analysis. There are two ways that the Tablet can record Live Data: Record by DTC Trigger †...

  • Page 32: Record Manually

    USING THE TABLET OBD2 Diagnostics If DTCs are presently stored in the vehicle’s computer, an advisory message displays. Choose Erase DTCs. A “One moment please…” message displays while DTCs are erased ━ from the vehicle’s computer. If the erase is not successful, an advisory message displays. To retry the erase process, verify that the Tablet is properly connected to the vehicle’s DLC ━...

  • Page 33: Playback Live Data

    USING THE TABLET OBD2 Diagnostics Select Record Manually, then press OK. The Select PIDs to Record screen displays. If the Tablet fails to establish communication with the vehicle, a “Communication Error” message displays. Ensure your vehicle is OBD2 compliant. ━ ━...
  • Page 34 USING THE TABLET OBD2 Diagnostics From Live Data Mode, select Live Data Menu and press OK. Select Playback Live Data, then press OK. The Playback Live Data menu displays. NOTE: If there is no Live Data currently stored in the Tablet’s memory, an advisory message shows on the display.

  • Page 35: O2 Sensor Monitor - $05

    USING THE TABLET OBD2 Diagnostics Press OK on any PID to open a graph view for that PID. To exit Live Data Playback mode, select Exit Playback selection at the bottom of the list, then press OK. O2 SENSOR MONITOR - $05 The O2 Sensor Monitor lets you view the test results of the vehicle’s two or more O2 sensors.
  • Page 36 USING THE TABLET OBD2 Diagnostics NOTE: The diagnostic tablet does not perform the OBD monitor test but retrieves results from the most recently performed tests from the on-board computer’s memory. You may retrieve OBD monitor test results for only one test at any given time.

  • Page 37: Request Control On-Board System - $08

    USING THE TABLET OBD2 Diagnostics REQUEST CONTROL ON-BOARD SYSTEM - $08 The Request Control On-Board System - $08 allows you perform an EVAP Test or Particulate Filter Regeneration and Inducement System Reinitialization. EVAP Test - lets you initiate a leak test for the vehicle’s EVAP system. Particulate Filter Regeneration –...

  • Page 38: Viewing Vehicle Information - $09

    USING THE TABLET OBD2 Diagnostics NOTE: If the Tablet retrieves Permanent DTCs only, MIL Off and California state is selected, Drive Cycle Procedures can be viewed from the OBD2 Diagnostic screen. When Monitor status has been retrieved, the Drive Cycle Procedures menu displays. Depending on the Monitor status, you can view Drive Cycle Procedures for Complete Monitors, Incomplete Monitors or Disabled Monitors.

  • Page 39: Viewing Available Modules

    USING THE TABLET OBD2 Diagnostics The vehicle’s VIN number. The control module identification number. The vehicle’s calibration ID(s). These IDs uniquely identify the software version(s) for the vehicle’s control module(s). The Vehicle’s Calibration Verification Number(s) (CVNs) required by ODB2 regulations. CVNs are used to determine if emission-related calibrations for the vehicle under test have been changed.

  • Page 40: Oem Diagnostics

    USING THE TABLET OEM Diagnostics Select In-Use Performance Tracking then press OK. When the retrieval process is completed, the In-use Performance Tracking statistics for the vehicle under test display. If In-use Performance Tracking is not available for your vehicle, an advisory message shows on the diagnostic tablet’s display.

  • Page 41: Reading Dtcs For A Selected Module

    USING THE TABLET OEM Diagnostics Choose Scan All Systems, then press OK. A “Linking…” message displays while the Tablet scans all available modules. When the scan is complete, the All Modules Scan screen displays. The screen shows the number of DTCs recorded for each available module. The results window lists all tested Control Modules with its corresponding result: Fault –...

  • Page 42: Viewing Live Data For A Selected Module

    USING THE TABLET OEM Diagnostics Choose Erase DTCs. A confirmation message shows. Ensure that the ignition in the Key ON, Engine OFF position. If you are sure you want to proceed, choose Erase DTCs for a second time. If you do not want to proceed, press Back to cancel the erase procedure.

  • Page 43: Nvld Evaporative Vent Valve Solenoid Control State

    USING THE TABLET OEM Diagnostics Intake Manifold Tuning Valve (MTV) Solenoid Control State Intake Manifold Short Runner Valve (SRV) Solenoid Control State Radiator Cooling Fan Relay #2 Control State Radiator Cooling Fan Relay PWM Control State Oxygen Sensor 1/1 Heater Control State Oxygen Sensor 2/1 Heater Control State Oxygen Sensor 1/2 Heater Control State Oxygen Sensor 2/2 Heater Control State...

  • Page 44: Cooling Fan Test

    USING THE TABLET OEM Diagnostics Select Air Pump Relay in the ECM Active Test menu, then press OK. An “instructional” screen displays. Follow the instructions to prepare the vehicle for the test procedure. Press On or Off as desired. The screen refreshes to show the Result. Press Back to return to the Active Test menu.

  • Page 45: Fuel Pump Relay Test

    USING THE TABLET OEM Diagnostics Repeat step 2 as desired. Press Back to return to the ECM Active Test menu. Fuel Pump Relay Test The Fuel Pump Relay function lets you turn the fuel pump relay ON or OFF. Select Fuel Pump Relay in the Active Test menu, then press OK. An “informational’...

  • Page 46: Gear Commanded By Output State Control Test

    USING THE TABLET OEM Diagnostics ━ Place the transmission in PARK. Start and idle the engine. ━ Press OK to continue. The Spark Advance screen displays. Select Increase or Decrease, as desired, then press OK. The screen refreshes to show the test result. Repeat step 3 as desired.

  • Page 47: (Evap) Vapor Blocking Valve Test

    USING THE TABLET OEM Diagnostics (EVAP) Vapor Blocking Valve Test The (EVAP) Vapor Blocking Valve function lets you turn the vapor blocking valve ON or OFF. Select (EVAP) Vapor Blocking Valve in the Active Test menu, then press OK. An “instructional” screen displays. Prepare the vehicle for test as directed: ━...

  • Page 48: Fuel Pump Test

    USING THE TABLET OEM Diagnostics The screen refreshes to show the test result. Repeat step 3 as desired. Press Back to return to the Active Test menu. Fuel Pump Test The Fuel Pump function lets you turn the fuel pump ON or OFF. Select Fuel Pump in the Active Test menu, then press OK.

  • Page 49: Check Engine Lamp (Mil) Test

    USING THE TABLET OEM Diagnostics Fuel Pump Relay † A/C Compressor Relay † Fuel Pump Control † Immobilizer Lamp (Option) † Check Engine Lamp (MIL) Test The Check Engine Lamp (MIL) function allows you to check the operation of the MIL warning lamp. Select Engine Check Lamp (MIL) in the Active Test Menu, then press OK.

  • Page 50: Variable Intake Solenoid (Option) Test

    USING THE TABLET OEM Diagnostics Variable Intake Solenoid (Option) Test Select Variable Intake Solenoid (Option) in the Active Test Menu, then press OK. A “confirmation” screen displays. Select OK to continue. An “instructional” screen displays. Prepare the vehicle for the test as directed: Engine RUN.

  • Page 51: Purge Vol Control Valve Test

    USING THE TABLET OEM Diagnostics Select Back to return to the Active Test menu. Purge Vol Control Valve Test Select Purge Vol Control Valve in the Active Test menu, then press OK. An “instructional” screen displays. Prepare the vehicle for test as directed. Engine: After Warning Up Above 158°F (70°C), run Engine at 1500-2000rpm.

  • Page 52: Egr Cut Vsv Test

    USING THE TABLET OEM Diagnostics Cranking Request † PWM Output Test † Cooling Fan Hi / Mid / Lo / Stop † OFF Ave Cg Relay † NOTE: If an error occurs while performing any function, an “advisory” message displays. Press Back to return to the Active Test Menu.

  • Page 53: Inspection Mode Test

    USING THE TABLET OEM Diagnostics Press Back to return to the Active Test Menu. Inspection Mode Test The Inspection Mode function is used to check exhaust gases by engine intermittent prohibition or to allow use of a chassis dynamometer by cutting Traction Control (TRC). Select Inspection Mode in the Active Test Menu, then press OK.

  • Page 54: Cooling Fan Test

    USING THE TABLET OEM Diagnostics Select PWM Output Test in the Active Test Menu, then press OK. An “instructional” screen displays. Prepare the vehicle for test as directed: Turn the ignition on. DO NOT start the engine. ━ Place the transmission in PARK. ━...

  • Page 55: Honda Active Tests

    USING THE TABLET OEM Diagnostics Select On to activate the relay. Select Off to deactivate the relay. The display refreshes to show the test results. Repeat as desired. Select Back to return to the Active Test Menu. Honda Active Tests Depending on the vehicle under test, the Active Test menu provides access to one or more of the following tests on Honda vehicles:...

  • Page 56: Reading Ecu Information

    USING THE TABLET OEM Diagnostics ━ Battery Voltage: 12V. Select Next to proceed. A “Please waiting for clear….” message displays, followed by one or more “informational/ instructional” screens. Perform test procedures as directed. When the process has competed, a confirmation message displays. NOTE: If the process was not successful, an advisory message displays.

  • Page 57: Vehicle Inspection

    USING THE TABLET OEM Diagnostics Erase DTCs – refer to [See page † Live Data – refer to [See page † Active Test – refer to [See page † ECU Information – refer to [See page † VEHICLE INSPECTION Performing a full vehicle scan ensures peace of mind for you and your customers. Many systems do not turn on a light or places a message on the vehicle’s Diagnostic Information Center, so following this process can help uncover hidden issues.

  • Page 58: Workshop Tools

    USING THE TABLET Workshop Tools Service Warning Lights, and Vehicle Care. Collision Industry Report – Provides a report for OBD2 Data, Scan All Systems Data, Service Warning Lights, and Service Check. Choose the report type you wish to view, then press OK. The PreScan –...

  • Page 59: Battery Reset

    USING THE TABLET Workshop Tools Workshop Tools screen. If the Oil Maintenance Reset was not successful, an advisory message display. NOTE: If the Tablet cannot reset the Oil Maintenance Light, an “instructional” dialog displays, showing the manual procedures for resetting the indicator light. When finished viewing the instructions, press Back to return to the Workshop Tools screen.

  • Page 60: Battery Initialization (Audi, Bmw, Ford, Volkswagen, Volvo)

    USING THE TABLET Workshop Tools Choose the procedure you wish to view, then press OK. The selected procedure displays. When you have finished viewing the retrieved information, choose Back to return to the Battery Reset Procedures menu. Repeat step 3 to view additional procedures. When you have finished viewing all desired procedures, choose Back to return to the Workshop Tools.

  • Page 61: Steering Angle Sensor (Sas) Calibration

    USING THE TABLET Workshop Tools The screen shows the previously entered Battery part number, Battery manufacturer and Battery serial number. Select the desired option: To proceed with coding, select Carry Out Coding and press OK. Proceed to step 6. To re-enter battery reference information, select Repeat Input and press OK. Repeat steps 3 and 4.

  • Page 62: Dpf Reset (Except Chrysler, General Motors, Nissan, And Volkswagen)

    USING THE TABLET Workshop Tools Select EPB Reset in the Workshop Tool screen, then press OK. A “One moment please…” message displays. For some vehicles, one or more sub-menus display. Select the desired module and/or option, as appropriate, then press OK. Proceed to step 2. NOTE: If EPB reset is not supported by the vehicle under test, an “advisory”...

  • Page 63: Dpf Reset (Chrysler)

    USING THE TABLET Workshop Tools DPF RESET (Chrysler) Select Diesel Particulate Filter Reset in the Workshop Tools screen, then press OK. A “One moment please…” message displays, followed by the Diesel Particulate Filter Reset menu. Select the desired option, then press OK. An “instructional”...

  • Page 64: Dpf Reset (Volkswagen)

    USING THE TABLET Workshop Tools A “confirmation” screen displays when the routine is completed. NOTE: If the routine does not complete successfully, an “advisory” message display. Choose Exit to return to the Workshop Tools screen. Choose End to return to the Workshop Tools screen. DPF RESET (Volkswagen) Select Diesel Particulate Filter Reset in the Workshop Tools screen, then press OK.

  • Page 65: Ev/Hev/Phev Battery Health

    USING THE TABLET Workshop Tools Perform test procedures as directed. Choose Next or Continue, as appropriate, to scroll to the next screen. For some vehicles, “status” screens display as each phase of the calibration procedure is successfully completed. Choose Next or Continue, as appropriate, to scroll to the next screen. A “results”...

  • Page 66: View Battery Live Data

    USING THE TABLET Workshop Tools The Battery/Alternator Test Menu displays. Select Battery Test, then press OK. An “instructional” message displays, showing the procedures to prepare the vehicle for the battery check. Prepare the vehicle for the battery check: Turn the engine off. Place the transmission in PARK or NEUTRAL and set the parking brake.

  • Page 67: Perform A Charging System Check

    USING THE TABLET Workshop Tools the vehicle is not an electric or hybrid vehicle, the Battery/Alternator Monitor menu displays. Proceed to step 2. Select Battery/Alternator Test, then press OK. The Battery/Alternator Test menu displays. Select Battery Live Data (12 Volts), then press OK. The Battery Live Data (12 Volts) screen displays.

  • Page 68: Previous Vehicles

    USING THE TABLET Previous Vehicles When you’ve concluded viewing the Alternator Live Data, choose Back to return to the Battery/Alternator Test menu. PREVIOUS VEHICLES The Tablet stores the results of the most recent vehicle scans you have performed. The Previous Vehicles function allows you to retrieve these historical scan records and view them as needed.

  • Page 69: Settings

    USING THE TABLET Settings Select the scan type report you wish to view, then press OK. Choose Back to return to the Memory System Menu. When you have finished viewing the information, choose Back to return to the Previous Vehicles screen or press Home to exit to the Home Screen.

  • Page 70: Autolink Setting

    USING THE TABLET Settings Select Save to save your changes and auto-return to the Report Selection screen. To exit and not proceed, select Cancel to return to the Report Selection screen. AUTOLINK SETTING Select AutoLink Setting in the Settings menu, then press OK. The AutoLink Setting screen displays.

  • Page 71: Adjusting Display Brightness

    USING THE TABLET Settings Enter the Wi-Fi network password using the keyboard. Once the password has been entered, tap the button to save your changes and complete your connection. To select a different network, press Back to cancel your changes and return to the Sign in To Your Wi-Fi Network dialog screen.

  • Page 72: Setting The Unit Of Measurement

    USING THE TABLET Settings SETTING THE UNIT OF MEASUREMENT Select Unit of Measurement in the Settings menu, then press OK. The Unit of Measurement screen displays. Select the desired unit of measurement (Standard or Metric), the tablet will automatically save your changes. NOTE: To return to the Settings menu without making changes, press the Back button.

  • Page 73: Updating The Tablet

    USING THE TABLET Settings UPDATING THE TABLET Select Update in the Settings menu, then press OK. Verify that the tablet is connect to a Wi-Fi Network. If the tablet is not connected to a Wi-Fi network, an alert message displays “Please connect to Wi-Fi to continue”.

  • Page 74: Tool Library

    USING THE TABLET Tool Library TOOL LIBRARY Tool Library contains valuable reference information for the Tablet. The following functions are available: Icon Definition – Shows the full names for the I/M MONITOR STATUS icons shown and descriptions of informational icons on the Tablet’s display. DTC Library –...

  • Page 75: Smog Check Or I/M Program Led Definitions

    USING THE TABLET Tool Library The Enter DTC screen displays. The screen shows the code “P0001,” with the “P” highlighted. Press Up / Down, as necessary, to scroll to the desired DTC type (P=Powertrain, U=Network, B=Body, C=Chassis), then choose Next Digit.

  • Page 76: Icon Monitor Status

    USING THE TABLET Tool Library Select the desired model, then press OK. The DLC Location screen for the selected vehicle displays. The DLC Location screen shows the selected vehicle make and model, a description of the DLC location and whether the DLC is “covered” or “uncovered,” and includes a picture of the DLC location.

  • Page 77: Warranty+ Customer Service

    CUSTOMER SERVICE Our ASE Certified technical staff is here to help if you have any questions or require service. For information on UPDATES and OPTIONAL ACCESSORIES, please contact your local store, distributor or Innova’s Service Center. USA & Canada: (800) 544-4124...

  • Page 78: Glossary

    GLOSSARY OBD2 Terminology GLOSSARY OBD2 TERMINOLOGY The following terms and their definitions are related to OBD2 systems. Powertrain Control Module (PCM) - The PCM is the OBD2 accepted term for the vehicle’s “on-board computer.” In addition to controlling the engine management and emissions systems, the PCM also participates in controlling the powertrain (transmission) operation.

  • Page 79: Obd2 Monitors

    GLOSSARY OBD2 Monitors vehicle has been driven in such a way as to have all the “Enabling Criteria” met for all its applicable Monitors. Only those trips that provide the Enabling Criteria for all Monitors applicable to the vehicle to run and complete their individual diagnostic tests qualify as an OBD2 Drive Cycle.

  • Page 80: Non-Continuous Monitors

    GLOSSARY Additional Terminology + Acronyms NON-CONTINUOUS MONITORS The other twelve Monitors are “non-continuous” Monitors. “Non-continuous” Monitors perform and complete their testing once per trip. = Oxygen Sensor Monitor = Oxygen Sensor Heater Monitor = Catalyst Monitor = Heated Catalyst Monitor = EGR (Exhaust Gas Recirculation) System Monitor = EVAP System Monitor = Secondary Air System Monitor...
  • Page 81 GLOSSARY Additional Terminology + Acronyms OBD = On Board Diagnostics OBD2 / OBD II = On Board Diagnostics, Second Generation OEM = Original Equipment Manufacturer PID = Parameter Identification Data SRS = Safety Restraint System TPMS = Tire Pressure Monitoring System TSBs = Technical Service Bulletins...
