Adjustments - Perlick PTR Series Installation & Operation Manual

Digital Temperature Control
Figure 1. Digital Temperature Controller
Changing Door Swing Direction
NOTE: Changing the door swing direction is
not advisable if the door is not equipped with
a full length handle. Doing so may result in an
undesirable handle position..
Hinge Kits
Part No. 67439R: Right Hinging
Part No. 67439L: Left Hinging
Tools Required
• Large flat head screwdriver
• Regular Phillips head screwdriver
• Hinge Kit from Perlick
• Plastic putty knife
Procedure
SUPPORT
Pull door to
the side then lower door
Figure 3. Door Removal
Printed in USA

ADJUSTMENTS

Remove hinge pin
Models PTR/PTS Installation & Operation Manual
Setting the Set Point:
To display the Set point value press the
when the 'SET' label is displayed. The Set point
value appears on the display. To change the Set
point value, press the
seconds. Press
1. Support the door in the open position as
shown in Figure 3. Remove the hinge pin.
2. Pull door to the side and then lower the door.
3. Remove top and bottom hinge brackets.
Retain screws for later use. See Figure 4.
4. Remove the hole plugs from the top and
bottom hinge bracket mounting holes (Figure
4). Place the plugs in the holes on the opposite
side made vacant by removing the hinges in
step 3.
Figure 4. Hinge Removal
6
and keys within 15
to confirm the modification.
key
