Service Manual
Tumble dryer
TD6–6
Type N1130..
438916890/EN
Original instructions
2020.12.18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N1130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux Professional N1130

Summary of Contents for Electrolux Professional N1130

  • Page 1 Service Manual Tumble dryer TD6–6 Type N1130.. 438916890/EN Original instructions 2020.12.18...

  • Page 3: Table Of Contents

    Contents Contents 1 Symbols .............................5 2 Technical data.............................6 Drawing ............................6 Technical data ...........................7 Connections ..........................7 3 Machine presentation ..........................8 4 Function check............................9 5 Sensors and overheating thermostats ....................10 Inlet air............................10 5.1.1 Overheating thermostat ....................10 5.1.2 Heating sensor (PT100) ....................13 Outlet air ..........................14 5.2.1 Overheating thermostat ....................14 5.2.2 Heating sensor (NTC-sensor)..................17 6 Door ..............................18...
  • Page 4 Contents INTERNAL COM. I/O TYPE 10..................106 INTERNAL COM. I/O TYPE 6..................108 EXTERNAL COM. PAYMENT ..................108 EXTERNAL COM. CMIS....................109 INTERNAL........................110 13 Maintenance ........................... 111 13.1 Clean the fan, the exhaust duct and the fresh-air intake to the room........... 111 13.2 Clean the glide surface for the RMC graphite collectors ............

  • Page 5: Symbols

    Service Manual 1 Symbols Caution Caution, hot surface Caution, high voltage Read the instructions before using the machine...

  • Page 6: Technical Data

    Service Manual 2 Technical data 2.1 Drawing fig.W00648D Operating panel Door opening, ⌀ 370 mm Electrical connection Condense connection (only for condense machines) Exhaust connection (only for exhaust machines)

  • Page 7: Technical Data

    Service Manual 2.2 Technical data Exhaust Condense Weight, net Drum volume litres Drum diameter Drum depth Drum speed G-factor, max. Rated capacity, filling factor 1:22 (Max. load) Heating: Electricity A-weighted emission sound pressure level at working stations dB(A) 2.3 Connections Exhaust Condense ⌀...

  • Page 8: Machine Presentation

    Service Manual 3 Machine presentation Condense Exhaust fig.7552H Sensors and overheating thermostats Door Motor Heating unit Drum Control panel with Control system I/O modules After a repair has been made Whenever a repair has been made, a function check must be performed before the machine can be used again.

  • Page 9: Function Check

    Service Manual 4 Function check May only be carried out by qualified personnel. A function check must be made when the installation is finished and before the machine can be ready to be used. Whenever a repair has been made, a function check must be performed before the machine can be used again. Check the automatic stop of the machine •...

  • Page 10: Sensors And Overheating Thermostats

    Service Manual 5 Sensors and overheating thermostats 5.1 Inlet air 5.1.1 Overheating thermostat Description — exhaust machines There are two inlet overheating thermostats. One is placed at the back of the machine and one is placed on the bot- tom of the machine on the heating element. The inlet overheating thermostat opens in the event of overheating and shuts off the machine.
  • Page 11 Service Manual Resetting — condense machines Disconnect the power to the machine. Press the reset button (A) on the overheating thermostat. Note! Resetting must not be done before the cause for overheating is verified and resolved. fig.7594 Replacement of overheating thermostat — exhaust machines Disconnect the power to the machine.
  • Page 12 Service Manual Replacement of overheating thermostat — condense machines Disconnect the power to the machine. Demount the casing over the rear panel and the plastic cover. Disconnect the air channel panel. Disconnect the overheating thermostat and remove it. Connect the new overheating thermostat. It is recommended to replace the complete heating element cover with the overheating thermostat on.

  • Page 13: Heating Sensor (Pt100)

    Service Manual 5.1.2 Heating sensor (PT100) Description The heating sensor is placed at the back of the machine. The heating sensor measures the temperature in the inlet air and the signal is returned to the CPU. The CPU turns the heating unit off when the inlet air thermistor indicates that the required temperature has been reached.

  • Page 14: Outlet Air

    Service Manual 5.2 Outlet air 5.2.1 Overheating thermostat Description — exhaust machines The outlet overheating thermostat is placed on the bottom of the machine on the outlet air flow. The overheating thermostat ensures that the machine does not overheat during program operation. The overheating thermostat opens automatically and has to be reset manually.
  • Page 15 Service Manual Resetting — condense machines Disconnect the power to the machine. Open the door and demount the door switch. Press the reset button (A) on the overheating thermostat. Note! Resetting must not be done before the cause for overheating is verified and resolved. fig.7593 Remount the door switch.
  • Page 16 Service Manual Replacement of overheating thermostat — condense machines Disconnect the power to the machine. Open the door and demount the door switch. Disconnect the overheating thermostat and remove it. Connect the new overheating thermostat. fig.7596 Remount the door switch.

  • Page 17: Heating Sensor (Ntc-Sensor)

    Service Manual 5.2.2 Heating sensor (NTC-sensor) Description — condense machines The heating sensor is placed next to the outlet overheating thermostat behind the door switch. The heating sensor measures the temperature in the outlet air and the signal is returned to the PCB. The PCB turns the heating unit off when the outlet air thermistor indicates that the required temperature has been reached.

  • Page 18: Door

    Service Manual 6 Door 6.1 Door switch The door switch (A) ensures that the machine stops automatically if the door is opened during operation. If the machine does not stop when the door is opened or if the door is closed and the error code DOOR IS OPEN is dis- played (and the machine is unable to start), for example, the door switch needs to be replaced.
  • Page 19 Service Manual Replacement of door magnets Remove the magnet to be replaced and mount the new one. fig.7459...

  • Page 20: Reversing The Door

    Service Manual 6.2 Reversing the door Disconnect the power to the machine. Demount the lower hinge and lift off the door. Note! Make sure to hold the door in position when loosening the hinge mounting. Demount the upper hinge. fig.W00180A Demount the cover screws on the other side and mount them where the hinges was.
  • Page 21 Service Manual Demount the locking panels by loosening the barb with a screwdriver. Press out the locking panels, swap them over and press into position. fig.W00184A Mount the door on the other side. Push the door and the top pivot into the upper hinge and then adjust the lower pivot into the lower hinge.

  • Page 22: Motor

    Service Manual 7 Motor 7.1 Replacement of motor Disconnect the power to the machine. Demount the casing over the rear panel and the cover panel at the air outlet. Demount the top panel. Disconnect the overheating thermostat and the heating sensor and push the connections into the hole. Exhaust Condense fig.7519G...
  • Page 23 Service Manual Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires. fig.7527 Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws.
  • Page 24 Service Manual Disconnect the ground cable and the motor cable. fig.7539 Carefully tilt the machine backwards and remove the four screws under the machine. Remove the motor with the fan. fig.7540 Demount the fan from the motor by loosening the set screw. The set screw can be accessed through a hole in one of the blades.
  • Page 25 Service Manual Mount the fan on the new motor and mount the new motor with the fan in the machine. Fasten the four screws under the machine. Carefully put the new drum package back in the machine. Fasten the support rollers at the front of the machine. Connect the RMC and the “FREE”...

  • Page 26: Replacement Of The Belt Around The Motor Pulley

    Service Manual 7.2 Replacement of the belt around the motor pulley Disconnect the power to the machine. Demount the casing over the rear panel and the cover panel at the air outlet. Demount the top panel. Disconnect the overheating thermostat and the heating sensor and push the connections into the hole. Exhaust Condense fig.7519G...
  • Page 27 Service Manual Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires. fig.7527 Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws.

  • Page 28: Replacement Of Fan

    Service Manual Remove the belt (A) and put the new belt in position. fig.7536 Carefully put the drum package back in the machine. Fasten the support rollers at the front of the machine. Connect the RMC and the “FREE” connection if disconnected. Connect the wires and mount the cover panel to the electrical connections.
  • Page 29 Service Manual Demount the air channel panel. On condense machines: Pull out the hose to the drain from its upper connection. Loosen the belt around the drum. Exhaust Condense fig.7522J Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires.
  • Page 30 Service Manual Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws. Use an L-key to turn counter clock- wise until they stop to move down the support rollers.
  • Page 31 Service Manual Carefully tilt the machine backwards and remove the four screws under the machine. Remove the motor with the fan. fig.7540 Demount the fan from the motor by loosening the set screw. The set screw can be accessed through a hole in one of the blades.

  • Page 32: Replacement Of Fan Motor

    Service Manual Use a puller to remove the fan from the motor. Mount the new fan on the motor. Make sure the air cover and the pressure spring gets in position. Mount the motor with fan in the machine. Fasten the four screws under the machine. Carefully put the new drum package back in the machine.
  • Page 33 Service Manual Demount the plastic cover and the air channel panel. Disconnect the fan motor and replace the fan motor with the new one and connect it. fig.7599 Mount the air channel panel and the plastic cover. Connect the overheating thermostat and the heating sensor. Mount the cover panel at the air outlet and the casing over the rear panel.

  • Page 34: Heating Unit, Electric

    Service Manual 8 Heating unit, electric 8.1 General Spare part number, effect and voltage are printed on each heating element. 8.2 Replacement of heating element Exhaust machines Disconnect the power to the machine. Demount the casing over the rear panel and the cover panel at the air outlet. Demount the top panel.
  • Page 35 Service Manual Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires. fig.7527 Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws.
  • Page 36 Service Manual Carefully tilt the machine backwards and remove the three screws under the machine to release the lower element cover panel. Disconnect the wires, demount the cover panels and remove the heating element. fig.7550 Connect the new element. Reconnect the wires as before, use the electric schematic supplied with the machine. Mount the element unit back in the machine and fasten the three screws under the machine.
  • Page 37 Service Manual Demount the the plastic cover and the air channel panel. Unscrew the screws to the heating element cover. Disconnect the wires and remove the heating element. fig.7547 Connect the new element. Reconnect the wires as before, use the electric schematic supplied with the machine. Mount the air channel panel and the plastic cover.

  • Page 38: Drum

    Service Manual 9 Drum 9.1 Replacement of drum Disconnect the power to the machine. Demount the casing over the rear panel and the cover panel at the air outlet. Demount the top panel. Disconnect the overheating thermostat and the heating sensor and push the connections into the hole. Exhaust Condense fig.7519G...
  • Page 39 Service Manual Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires. fig.7527 Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws.
  • Page 40 Service Manual Remove the bolt and washer from the bearing to release the drum. Remove the rear panel from the old drum. Mount the rear panel with the bearing on the new drum. fig.7532 Carefully put the new drum package back in the machine. Fasten the support rollers at the front of the machine.

  • Page 41: Replacement Of Bearing

    Service Manual 9.2 Replacement of bearing Disconnect the power to the machine. Demount the casing over the rear panel and the cover panel at the air outlet. Demount the top panel. Disconnect the overheating thermostat and the heating sensor and push the connections into the hole. Exhaust Condense fig.7519G...
  • Page 42 Service Manual Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires. fig.7527 Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws.
  • Page 43 Service Manual Remove the screws, bolt and washer on the bearing. Remove the bearing and mount the new one. Use tighening tor- que 27-38 Nm for nut A and 1.8-2.5 Nm for nuts B. fig.7532B Carefully put the new drum package back in the machine. Fasten the support rollers at the front of the machine.

  • Page 44: Replacement Of The Belt Around The Drum

    Service Manual 9.3 Replacement of the belt around the drum Disconnect the power to the machine. Demount the casing over the rear panel and the cover panel at the air outlet. Demount the top panel. Disconnect the overheating thermostat and the heating sensor and push the connections into the hole. Exhaust Condense fig.7519G...
  • Page 45 Service Manual Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires. fig.7527 Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws.
  • Page 46 Service Manual Remove the belt from the outer drum. Put the new belt temporarily in position on the outer drum and carefully put the drum package back in the machine. fig.7538 Fasten the support rollers at the front of the machine. Connect the RMC and the “FREE”...

  • Page 47: Control Panel

    Service Manual 10 Control panel 10.1 Control system 10.1.1 Description The control system CPU is electronic and comprises a circuit board containing microprocessor, program memory, se- rial interface to the motor, I/O boards etc. The control system CPU receives its power from a separate power supply unit. fig.7553 The control system receives information about inputs like temperature sensors, RMC, vacuum, door status etc, and activates outputs like drum, fan and heat control.

  • Page 48: 2Connections

    Service Manual 10.1.2 Connections The control system CPU has the following connections: Board connector Function M-COM Communication, motor control (not used) D-BUS Databus D-BUS Databus TACHO Tachometer (not used) COIN Coin meter (coin 1, coin 2, blocking) price programming INP 1 Input 1, stop button INP 2 Free program (key switch) / Input 2...

  • Page 49: 3Replacement Of Control System Cpu

    Service Manual 10.1.3 Replacement of control system CPU Disconnect the power to the machine. Demount the top panel. Demount the control knob Insert a screwdriver in the upper hole. fig.7491 Gently push the screwdriver inwards and turn the control knob counter-clockwise until the screwdriver goes further in. fig.7492 Continue turning a quarter of a turn until it is possible to remove the control knob.
  • Page 50 Service Manual Demount the cover ring When the control knob is removed, insert the screwdriver in the lower hole and press gently. Turn the cover ring counter-clockwise until it is possible to remove the cover ring. fig.7490 Demount the control system CPU Demount the control system CPU and disconnect the cables.
  • Page 51 Service Manual Mount the new control system CPU Mount the new control system CPU. Make sure that the guide pins (D) are in position. fig.7511 Connect the cables. Mount the cover ring and the control knob Mount the cover ring and rotate it clockwise until it is in position. Rotate the inner knob until the locking device is pointing downwards.
  • Page 52 Service Manual Mount the control knob on the inner knob. Continue to press with the screwdriver and turn the control knob clockwise until it stops when it is in position. fig.7495A...

  • Page 53: Control Knob

    Service Manual 10.2 Control knob 10.2.1 Replacement of control knob Disconnect the power to the machine. Insert a screwdriver in the upper hole. fig.7491 Gently push the screwdriver inwards and turn the control knob counter-clockwise until the screwdriver goes further in. fig.7492 Continue turning a quarter of a turn until it is possible to remove the control knob.
  • Page 54 Service Manual Cover ring When the control knob is removed, insert the screwdriver in the lower hole and press gently. Turn the cover ring counter-clockwise until it is possible to remove the cover ring. fig.7490 Mount the new cover ring and rotate it clockwise until it is in position. Rotate the inner knob until the locking device is pointing downwards.
  • Page 55 Service Manual Mount the new control knob on the inner knob. Continue to press with the screwdriver and turn the control knob clockwise until it stops when it is in position. fig.7495A...

  • Page 56: O Modules

    Service Manual 11 I/O modules 11.1 General The machine can be equipped with either one or two I/O modules: • I/O module type 82 is always installed in the machine at delivery. It controls internal machine functions and outputs to heating, motors etc. •...

  • Page 57: Replacement Of I/O Module

    Service Manual 11.2 Replacement of I/O module I/O module type 82 and I/O module type 2 are installed in the same way. If the machine has I/O module type 2, it is lo- cated on I/O module type 82. The illustration shows replacement of I/O module type 82. Disconnect the power to the machine.

  • Page 58: External Connections To I/O Module Type 2

    Service Manual Insert the new module and make sure it is in position. Connect the electrical connections in the same way as before and mount the plastic cover. If both I/O module type 82 and I/O module type 2 is to be replaced it is recommended to fit the modules together be- fore mounting in the machine.

  • Page 59: Circuit Diagram Of Function Options For I/O Module Type 2

    Service Manual 11.4 Circuit diagram of function options for I/O module type 2 11.4.1 Central payment (2J) To start the machine from a central payment system, the payment system must transmit a start pulse 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. The start pulse can be either 230V or 24V.

  • Page 60: External Coin Meter/Central Payment (2K)

    Service Manual 11.4.3 External coin meter/Central payment (2K) The signal received from external coin meters must be a pulse between 300–3000 ms (500 ms is recommended) with a minimum pause of 300 ms (500 ms is recommended) between two pulses. fig.7438...

  • Page 61: Price Reduction (2K)

    Service Manual 11.4.4 Price reduction (2K) By maintaining an activated (high) signal on connection 5 ("Price red"), the price of the program can be reduced. This function has a number of uses, including providing reductions during a specific period of the day. Whilst the signal re- mains active (high), the price of the program is reduced (or the time is increased on time programs), by the percent- age entered in the price programming menu.

  • Page 62: Troubleshooting

    Service Manual 12 Troubleshooting 12.1 General The troubleshooting section is used to trace errors in the machine to a defective component or unit. There is a memory in the control system that will save the selected program for 10 minutes in the case of power fail- ure.

  • Page 63: Error Code

    Service Manual 12.2 Error code An error in the program or in the machine is indicated on the display by an error code and a descriptive text. The error codes are divided into different groups called “Major” comprising different error codes called “Minor”. The errors will be displayed as for example 11:2 DOOR OPEN.
  • Page 64 Service Manual Error code Text Major Minor O.H. THERMOSTAT - INLET AIR MAIN DRYER O.H. THERMOSTAT - OUTLET AIR INLET AIR SENSOR - OPEN INLET AIR SENSOR - SHORT CIRCUITED OUTLET AIR SENSOR - OPEN OUTLET AIR SENSOR - SHORT CIRCUITED CONDENSE WATER CONTAINER IS FULL HEAT PUMP LOW PRESSURE HP HIGH PRESSURE CHECK COOLING SYSTEM AND FILTERS...
  • Page 65 Service Manual Error code Text Major Minor O.H. DRUM MOTOR DRUM MOTOR COMMON NO MOTOR COMMUNINCATION LOST MOTOR COMMUNICATION Error code Text Major Minor HEATSINK TOO HOT DRUM MOTOR EWD MOTOR TOO HOT NO INTERLOCK NO COMMUNICATION MOTOR SHORT CIRCUIT INTERLOCK HARDWARE LOW DC VOLTAGE HIGH DC VOLTAGE...
  • Page 66 Service Manual Error code Text Major Minor HEATSINK TOO HOT DRUM MOTOR OBIWAN MOTOR TOO HOT NO INTERLOCK NO COMMUNICATION MOTOR SHORT CIRCUIT INTERLOCK HARDWARE LOW DC VOLTAGE HIGH DC VOLTAGE UNDEFINED ERROR Error code Text Major Minor O.H. FAN MOTOR FAN MOTOR COMMON Error code Text...
  • Page 67 Service Manual Error code Text Major Minor FATAL ERROR INVALID RUNNING MODE INTERNAL FATAL ERROR EXTERNAL FLASH WRITE FATAL ERROR INVALID OPTION FATAL ERROR INVALID MODULE FATAL ERROR INVALID COIN INPUT FATAL ERROR INVALID FONT...

  • Page 68: Description Of Error Codes And Causes

    Service Manual 12.3 Description of error codes and causes MAIN COMMON 10:1 INTERNAL ERROR CPU TACHO Tacho input on CPU delivers values that is out of range. Recommended actions: 1. Run motor on highest possible speed in service mode. Check input value for RPM speed. 2.

  • Page 69: Main Washer

    Service Manual MAIN WASHER 11:1 NO WATER This error is shown if the programmed water level is not reached within a certain time, typically 10 minutes. Max. filling time is defined in Config. 1 parameter MAX FILL TIME. This error message can be turned off in Configuration - Error code. Possible causes: Long filling times can be caused by a leaking drain valve, blocked filler valve, defective filler valve, defective valve control board, clogged level sensor hose, leaking level system, etc.
  • Page 70 Service Manual 11:5 WATER HIGH TEMP This error code is shown if the temperature sensor indicates temperature above + 98°C/208°F. Maximum allowed temperature is defined in Config. 2 parameter MAX PROG TEMP. Possible causes: This high temperature means that the resistance in the sensor is too low (< 350Ω on all machines except Barrier Washers) or too high (>137Ω...
  • Page 71 Service Manual 11:9 DRUM OVERFILLED This error code is shown if the mechanical level sensor connected to input DRUM OVERFILLED detects a high level (used primary in W&D machines) Possible causes: This error code can be caused by for example water inlets not closing correctly, faulty level switch, blocked level hose, drops of water in the level hose, foam in drum or level hose, etc.
  • Page 72 Service Manual 11:27 LEVEL OFFSET This error code is shown at program start if the level sensor indicates a level above what the control system CPU can compensate for. If high level is indicated a attempt is made to first drain the machine. Maximum allowed level offset is defined in Config.
  • Page 73 Service Manual 11:127 DRAWER OUT CLOSE TO START This is only a warning message. Shown if input DETERGENT BOX SENSOR is active at program start or during program run if water is supposed to flush in detergent compartment. The program will pause until input DETERGENT BOX SENSOR is deactivated. The function to check for open detergent box can be turned off in Config 1 DETERGENT BOX SENSOR.

  • Page 74: Main Dryer

    Service Manual MAIN DRYER 12:1 O.H. THERMOSTAT - INLET AIR This error code is shown if the input O.H. INLET AIR is deactivated. Normally this is due to that protection thermostat for inlet air has trigged due to overheating. The overheating thermostat for inlet air needs to be mechanically restored. Cut power and turn off gas supply (if gas heated) and check contactors/heat relays before restoring the thermostat.
  • Page 75 Service Manual 12:4 INLET AIR SENSOR - SHORT-CIRCUITED The error code is shown if the analog input INLET AIR TEMP (PT100) is reading a resistance of less than 100 Ω. Probably caused by broken PT100 sensor or damaged wiring. If the inlet air temperature in the SHOW INPUTS menu show a temperature of 0 °C the inlet air sensor is shorted. When the inlet air sensor is restored the error code is automatically reset and the ongoing program will continue.
  • Page 76 Service Manual 12:6 OUTLET AIR SENSOR - SHORT-CIRCUITED The error code is shown if the analog input OULET AIR TEMP (NTC) is reading a resistance of less than 330 Ω. Probably caused by broken NTC sensor or damaged wiring. If the outlet air temperature in the SHOW INPUTS menu shows a temperature of 100 °C the outlet air sensor is shorted.
  • Page 77 Service Manual 12:10 HP HIGH PRESSURE CHECK COOLING SYSTEM AND FILTERS The error is activated if the input HP HIGH PRESSURE (high pressure switch, P1) has tripped. The errror can be trigged if there is no cooling water to machine or if the airflow is obstructed, by lint, overload, etc. The error can be restored with the knob when the pressure is restored and the ongoing program will continue.
  • Page 78 Service Manual 12:14 GAS ERROR PRESS GAS RESET BUTTON The error code is shown if input GAS ERROR is activated. This means that no flame has been detected by the gas control box. The metal probe of the flame sensor generates an electrical current when exposed to the burner's flame. This signal is detected by the ignition control module which, in turn, cuts off the gas valve immediately if the sensor does not indi- cate flame within 3 attempts at each 10 seconds.
  • Page 79 Service Manual 12:18 REDISTRIBUTION OF LOAD NEEDED The error code is shown if the input VACUUM has deactive several times during program run and the function to han- dle vacuum error during program run has failed to recreate vacuum in the machine. The error code is reset from the control system by a short press on the control knob/start button.
  • Page 80 Service Manual 12:255 JUMPER 3 The error code is shown if input JUMPER 3 is not activated. Jumpers are a by-pass of input not used in the machine. How many jumpers used is depending on configuration. When the jumper is restored the error code is automatically reset and the ongoing program will continue. A long press on the control knob/start button will make the control system reset and ongoing program will be ended.

  • Page 81: Main Barrier

    Service Manual MAIN BARRIER 13:1 DRUM POSITIONING TIMED OUT The error code is shown if input POSITION DRUM 1 and POSITION DRUM 2 is not activated within set time in Con- fig parameter DRUM POS TIMEOUT. Recommended actions: 1. Check inputs from positioning sensors DP1 and DP2. 13:2 DRUM LOCKING / UNLOCKING The error code is shown if drum is not able to unlock/lock when expected.
  • Page 82 Service Manual 13:6 DRUM LOCK POSITION SWITCH The error code is shown if inputs DRUM UNLOCKED and DRUM LOCKED are both active or inactive at the same time during program run. Since it occurs during program run it is required to turn power off to the machine to clear the error message.
  • Page 83 Service Manual 13:11 UNLOADING DOOR NOT LOCKED This error code will be shown if the control system has not detected the input UNLOADING DOOR LOCKED to be ac- tive within a certain time after closing the unloading door. Possible causes: This can be caused by a mechanical problem preventing door lock to lock, defective door lock, loose cable connec- tion to door lock, broken cables to door lock or mechanical problem with emergency opening of the door.

  • Page 84: Main W&D

    Service Manual 13:16 DRUM LOCK POSITION SWITCH The error code is shown if inputs DRUM UNLOCKED and DRUM LOCKED are both active or inactive at the same time during positioning sequence. By pressing the start button it is possible to have another trial. Possible causes: Heavy unbalance in drum that prevents the motor to position the drum.

  • Page 85: Main Dryer

    Service Manual MAIN DRYER 15:2 UNLOADING DOOR OPEN Only on Pocket washer: This error code will be shown if the control system detects that the input DOOR CLOSED 2 (unloading side) has been deactivated during an on-going program. The error can only occur during an on-going program. Possible causes: This can be caused by for example a bad or defective door lock, loose cable to door lock, problem with door lock edge connection, defective input on I/O unit type 10 etc.

  • Page 86: Drum Motor Common

    Service Manual DRUM MOTOR COMMON 20:1 O.H. DRUM MOTOR This error code will be shown if the control system detects that the input OH DRUM MOTOR is deactivated during program run. The overheating protection is automatically restored. When the overheating protection is restored the error code is automatically reset and the ongoing program will continue.

  • Page 87: Drum Motor Ewd

    Service Manual DRUM MOTOR EWD 21:1 HEATSINK TOO HOT This error code is generated by the MCU for drum motor. There is a temperature sensor (NTC) mounted on the MCU cooling flange next to the power transistors in the output stage.
  • Page 88 Service Manual 21:3 NO INTERLOCK This error code is generated by the MCU for drum motor. The MCU must be powered with 230V / 50 or 60 Hz on the interlock input in order to drive the motor. This signal is a confirmation that the door is closed and locked.
  • Page 89 Service Manual 21:6 INTERLOCK HARDWARE This error code is generated by the MCU for drum motor. The MCU must be powered with 230V / 50 or 60 Hz on the interlock input in order to drive the motor. The interlock cir- cuits in the MCU have been split into two channels so that a component error in MCU cannot give a false confirma- tion that the door is locked.
  • Page 90 Service Manual 21:15 MOTOR NOT FOLLOW This error code is generated by the MCU. The MCU must always receive information on the rotation of the motor from the tacho sensor in order to rotate. If the tacho sensor is not working, the motor can rotate for max. 10 seconds during the starting process.

  • Page 91: Drum Motor Keb

    Service Manual DRUM MOTOR KEB 22:0 SECURITY INPUT Machine indicates that Interlock signal is missing to MCU. Internal MCU error code STO. The interlock signal is missing to MCU STO1+ or STO2+ inputs when expected to be active. Recommended actions: 1.
  • Page 92 Service Manual 22:6 OVERHEAT INTERNAL The Motor Control Unit indicates error E.OHI. Internal overheating in frequency controller. Can only be reset when internal temperature has dropped by 3 °C. This is indicated by message E.nOHI. See also error code 22:7. Internal message 6.
  • Page 93 Service Manual 22:12 POWER UNIT The Motor Control Unit indicates error E.Pu. General power circuit fault. Internal message 12. Recommended actions: 1. Switch off the main power to machine for 5 minutes. 2. Restart the machine. 22:13 POWER UNIT NOT READY The Motor Control Unit indicates message nO_PU.
  • Page 94 Service Manual 22:17 NO OVERLOAD The Motor Control Unit indicates error E.nOL. Overload counter is reset to 0%. See also error 22:16. Internal message 17. 1. Switch off the main power to machine for 5 minutes. 2. Restart the machine. 22:18 BUS The Motor Control Unit indicates error E.buS.
  • Page 95 Service Manual 22:23 BUS SYNCHRON. The Motor Control Unit indicates error E.SbuS. Problem with Bus synchronization. Internal message 23. 1. Switch off the main power to machine for 5 minutes. 2. Restart the machine. 22:30 MOTOR PROTECTION The Motor Control Unit indicates error E.OH2. Electronic motor protection relay has tripped.
  • Page 96 Service Manual 22:47 PROTECT. ROT. REVERSE The Motor Control Unit indicates error E.Prr. Reverse (left) limit switch is activated. Not used in this application. Internal message 47. 22:49 POWER UNIT CODE INVALID The Motor Control Unit indicates error E.Puci. Power unit code invalid. During initialization the power unit was not recognized or identified as invalid. Internal message 49.
  • Page 97 Service Manual 22:57 INITIALISATION MFC The Motor Control Unit indicates error E.InI. MFC not booted. Internal message 57. 22:58 OVER SPEED ERROR over speed in KEB Motor Control Unit. Internal message 105. Recommended actions: 1. Restart the machine. 22:87 OVERHEAT INT. Warning: The Motor Control Unit indicates A.OHI.
  • Page 98 Service Manual 22:92 NO OVERHEAT INT. Warning: The Motor Control Unit indicates A.nOHI. Overheat internal is reset. See also error code 22:87. Internal message 92. Recommended actions: 1. Restart the machine. 22:93 BUS Warning: The Motor Control Unit indicates A.buS. Timeout of monitoring time of communication between bus operator and inverter (Watchdog).
  • Page 99 Service Manual 22:99 OVERLOAD 1 Warning: The Motor Control Unit indicates A.OL. Overload counter has reached 100%. The warning can only be reset after overload counter has reached 0% again. This is indicated by the message A. nOL. See also message 22:98. Internal message 99.

  • Page 100: Drum Motor Obiwan

    Service Manual DRUM MOTOR OBIWAN 23:1 HEATSINK TOO HOT This error code is generated by the MCU for drum motor. There is a temperature sensor (NTC) mounted on the MCU cooling flange next to the power transistors in the output stage.
  • Page 101 Service Manual 23:3 NO INTERLOCK This error code is generated by the MCU for drum motor. The MCU must be powered with 230V / 50 or 60 Hz on the interlock input in order to drive the motor. This signal is a confirmation that the door is closed and locked.
  • Page 102 Service Manual 23:6 INTERLOCK HARDWARE This error code is generated by the MCU for drum motor. The MCU must be powered with 230V / 50 or 60 Hz on the interlock input in order to drive the motor. The interlock cir- cuits in the MCU have been split into two channels so that a component error in MCU cannot give a false confirma- tion that the door is locked.

  • Page 103: Fan Motor Common

    Service Manual 23:15 MOTOR NOT FOLLOW This error code is generated by the MCU. The MCU continuously estimates the motor speed. If the estimated speed is less than 180 rpm 10 seconds after drive command, or higher than 180 rpm 60 seconds after stop command, the error will be shown.

  • Page 104: Internal Com

    Service Manual INTERNAL COM. 40:1–40:10 I/O INTERLOCK Axxx This error code will be shown if the control system detects that the input IO INTERLOCK is not active. I/O unit desig- nation, Axxx, that is shown in the error description is according to electric schematics and electrical component list. Recommended actions: 1.
  • Page 105 Service Manual 40:22 I/O BOARD MISHMASH The error code is shown if wrong Type of I/O unit is fitted. Could also occur if adressessing of the I/O units is made in a incorrect way. After addressing of I/O units the CPU reads the Type of each unit. If there is a mismatch between what the Type of I/O unit the CPU finds, and what the I/O unit type the software con- figuration expects, the error will be shown.

  • Page 106: Internal Com. I/O Type 10

    Service Manual INTERNAL COM. I/O TYPE 10 41:1 CHARGE CIRCUIT The DLCU on I/O board type 10 contains an arming circuit that is charged when the door lock coil is to be activated. For safety reasons, this arming circuit must be discharged when the door lock coil is not to be activated. If the arming circuit for operating the door lock is charged when it is not supposed to be, an error message will be sent to the CPU.
  • Page 107 Service Manual 41:21 CHARGE CIRCUIT Only on Pocket washer. Pocket washer uses two I/O boards type 10, one for the "Loading side" and one for the "Unloading side". This error relates to I/O board type 10 on "Unloading side". See also corresponding error 41:1 for I/O type 10 on "Loading side". The DLCU on I/O board type 10 contains an arming circuit that is charged when the door lock coil is to be activated.

  • Page 108: Internal Com. I/O Type 6

    Service Manual INTERNAL COM. I/O TYPE 6 42:1 I/O TYPE 6 INTERNAL ERROR I/O unit type 6, reading of internal analog values out of range. Possible causes: • Intermittent error in wiring to I/O type 6 unit. • Internal error in I/O type 6. Recommended actions: 1.

  • Page 109: External Com. Cmis

    Service Manual EXTERNAL COM. CMIS 52:1 CMIS COMMUNICATION ERROR Communication between machine and CMIS computer has been interrupted. The warning will be shown at program start for 5 seconds, the next 5 programs. It is then removed automatically. After the warning message has disapeared the machine will start, but no CMIS data statistics/data will be logged. Possible causes: •...

  • Page 110: Internal

    Service Manual INTERNAL 60:5 FATAL ERROR INVALID RUNNING MODE The control system has an internal error during memory read. Recommended actions: 1. Press the control knob/start button to retry. 2. If problem persists, upload new software. 60:11 FATAL ERROR EXTERNAL FLASH WRITE The control system has an internal error during memory read.

  • Page 111: Maintenance

    Service Manual 13 Maintenance 13.1 Clean the fan, the exhaust duct and the fresh-air intake to the room Check that the following are not clogged by lint and dust or otherwise blocked and clean with a vacuum cleaner: • The fan. Be careful not to damage the fan. •...

  • Page 112: Clean The Area Around The Drum

    Service Manual 13.3 Clean the area around the drum Disconnect the power to the machine. Demount the top panel. Remove all lint around the drum and in the area over the drum with a vacuum cleaner. fig.7603A 13.4 Clean the motor Disconnect the power to the machine.
  • Page 113 Service Manual Demount the air channel panel. On condense machines: Pull out the hose to the drain from its upper connection. Loosen the belt around the drum. Exhaust Condense fig.7522J Unscrew the four screws at the panel around the heating element. Demount the cover panel to the electrical connections and disconnect all wires.
  • Page 114 Service Manual Unscrew the rest of the screws on the panel. Disconnect the RMC and cut the cable ties. If there is a “FREE” connection, disconnect it. At the front of the machine: Open the door and remove the two plugs and screws. Use an L-key to turn counter clock- wise until they stop to move down the support rollers.

  • Page 115: Check The Belt

    Service Manual Clean the motor and the fan with a vacuum cleaner. Also clean the area around the motor and fan and other areas if needed. fig.7540B Remount the motor. Tighten the four screws under the machine. Carefully put the new drum package back in the machine. Fasten the support rollers at the front of the machine.
