739MN (Natural Gas) & 739MP (Propane Gas)
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and shall be
installed for the protection of children and other at-risk
individuals.
!
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
▪ Do not try to light any appliance.
▪ Do not touch any electrical switch; do
not use any phone in your building.
▪ Leave the building immediately.
▪ Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
▪ If you cannot reach your gas supplier,
call the fi re department.
— Installation and service must be
performed by a qualifi ed installer, service
agency or the gas supplier.
4006175-02
©2017, Miles Industries Ltd.
Legend G3
DV Gas Insert
Installation & Owner's Manual
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
L e a v e t h i s m a n u a l
w i t h t h e a p p l i a n c e .
R e t a i n t h i s m a n u a l
f o r f u t u r e r e f e r e n c e .
Please read this manual
BEFORE installing and
operating this appliance.
This manual contains instructions to install the
ENGINE ONLY. A front is also REQUIRED to
complete this installation. A barrier screen is pro-
vided with the front. Refer to the manual sup-
plied with the front for installation.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Ce guide est disponible en français sur demande.
I N S TA L L E R
C O N S U M E R
Advertisement
Table of Contents
Related Manuals for Miles Industries Valor Legend G3
Summary of Contents for Miles Industries Valor Legend G3
- Page 1 fi re department. bedroom or bed sitting room. — Installation and service must be Ce guide est disponible en français sur demande. performed by a qualifi ed installer, service agency or the gas supplier. 4006175-02 ©2017, Miles Industries Ltd.
-
Page 2: Table Of Contents
Spare Parts............41 The information contained in this installation manual is believed to be correct at the time of printing. Miles Industries Ltd. reserves the right to change or modify any information or speci- fi cations without notice. Miles Industries Ltd. -
Page 3: Safety Precautions
Safety Precautions READ and UNDERSTAND all instructions carefully Due to the high temperature, the appliance should be before starting the installation. FAILURE TO FOLLOW LOCATED out of traffi c areas and away from furniture these installation instructions may result in possible fi re and draperies. -
Page 4: Safety And Your Fireplace
Safety and Your Fireplace Safety and Your Fireplace Please Read and Carefully Follow all Safety Warnings and Operating Instructions Contained in Your Owner’s Manual (Replacement Manuals are available by contacting our service department at 1-800-468-2567 or visit www.valorfi replaces.com). withdraw in the event of accidental Please Follow These Important contact with a hot surface. -
Page 5: Owner's Information
INFORMATION Thank You ... WARNING For purchasing a Valor by Miles Industries. Your new radiant EXTREMELY HOT!!! gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Valor fi replace is fully tested during •... -
Page 6: Cleaning Your Fireplace
The following are recommendations only and are alcohol/solvent base cleaner will weaken the coating not meant to guarantee results. and damage it. NOTE: This is a problem beyond Miles Industries’ Dust the barrier screen with a soft brush. control and is not covered under warranty. •... -
Page 7: Checking Pilot And Burner Fl Ames
OWNER’S Owner’s Information INFORMATION Checking pilot and burner fl ames 5. Apply fi rm hand pressure around the window frame to ensure the window is sealed tight against the A periodic check of the pilot and burner fl ames should fi... -
Page 8: Replacing Batteries
OWNER’S Owner’s Information INFORMATION Using Handset Wall Holder The appliance area must always be kept clear and free from combustible materials, gasoline and other fl ammable Your fi replace equipment includes a wall vapors and liquids. holder to store the handset. If it hasn’t be Inspect the vent terminal outdoors regularly to make sure installed, refer to the instructions further on that snow, trees, bushes, leaves, or other objects do not... -
Page 9: How To Turn Your Fireplace Off (Including Pilot)
OWNER’S Owner’s Information INFORMATION How to Turn Your Fireplace OFF How to Ensure Your Fireplace Cannot (including pilot) Be Turned ON Inadvertently Familiarize yourself with each of these methods before operating your fi replace. You can use one of the two following methods to ensure that your fi... -
Page 10: Remote Control Operation
OWNER’S Remote Control Operation INFORMATION NOTE: Before using the remote control system for IMPORTANT: BEFORE YOU BEGIN, please note that on this system, the settings of time, temperature and the fi rst time, the receiver and the handset must be automatic ON/OFF can only be programmed when synchronized. - Page 11 OWNER’S Remote Control Operation INFORMATION MODES OF OPERATION • Press and hold (small fl ame) button to decrease fl ame height or • Briefl y pressing the SET button to set the appliance at pilot fl ame. changes the mode of operation in •...
- Page 12 OWNER’S Remote Control Operation INFORMATION SETTING THE ON / OFF TEMPERATURES SETTING THE “NIGHTTIME SETBACK” TEMPERA- SETTING THE “DAYTIME” TEMPERATURE TURE Default Settings: (sun), 23ºC / 74ºF Default Settings: (moon), “ ” (OFF) TEMP T E M P • Briefl y press SET button to scroll to •...
- Page 13 OWNER’S Remote Control Operation INFORMATION SETTING PROGRAM TIMERS SETTING P1 OFF TIME • You can program two periods of time between 12:00 • Briefl y press SET button to scroll am and 11:50 pm in each 24-hour cycle. to TIMER (moon) while the •...
- Page 14 OWNER’S Remote Control Operation INFORMATION Timer Programming Example (default temperatures shown) 4:00 p.m.— 6:00 a.m.— 8:00 a.m.— 10:00 p.m.— 6:00 a.m.— Start time Start time End time End time Start time Set temp 40˚F Set temp 74˚F Set temp 74˚F Set temp 40˚F AUTOMATIC TURN DOWN...
-
Page 15: Options
OWNER’S Options INFORMATION Required Kits* Optional Accessories* Fuel Beds (choose one) Outer Surrounds, Trims & Frets 739LSK Log Set See your dealer for your choice of Outer Surrounds, Trims & Frets. 739RSK Rock Set Conversion Kits 739DWK Driftwood Kit 739NGK From propane to natural gas Liners (choose one) 739PGK... -
Page 16: Lighting Instructions
OWNER’S Lighting Instructions INFORMATION FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly A. This appliance has a pilot which must be lighted by hand or by remote control. Follow these instructions exactly. To save gas, turn the pilot off when not using the appliance for a prolonged period of time. -
Page 17: Specifi Cations
QUALIFIED Specifi cations INSTALLER Approval & Codes *High Altitude Installations This appliance is certifi ed to ANSI Z21.88-2014 / CSA I nput ratings are shown in BTU per hour and are 2.33-2014 American National Standard / CSA Standard certifi ed without deration for elevations up to 4,500 feet for Vented Gas Fireplace Heaters for use in Canada (1,370 m) above sea level. -
Page 18: Overview
QUALIFIED Overview INSTALLER This appliance may ONLY be installed in an existing unaltered, functioning solid-fuel burning fi replace with a working fl ue and constructed of non-combustible material. DO NOT install into combustible construction. This appliance is NOT APPROVED for installation with a zero clearance kit. WARNING WARNING Chimney Terminal Cap... -
Page 19: Dimensions
QUALIFIED Dimensions INSTALLER 28-5/8” (727 mm) 19-1/2” (495 mm) 12 - 14” (305 - 357 mm) Varies with outer trim options 9-3/4” (248 mm) Optional Outer Trim or (11-3/4” (298 mm) Surround sold separately with 763 plate) AutoFire slider assembly Electrical inlet Gas inlet Gas connection... -
Page 20: Clearances
QUALIFIED Clearances INSTALLER WARNING WARNING Some materials or items, although safe, may discolor, shrink, warp, crack, peel, and so on because of the heat produced by the fi replace. Avoid placing candles, paintings, photos, and other items sensitive to heat around the fi replace. Combustible Mantel Clearances Mantel Pro- 1”... -
Page 21: Venting
QUALIFIED Venting INSTALLER Typical Vent Installation See the Approved Venting Components list on page 39 of this manual. Vent Location The vent terminal must be located through the roof. This direct Terminal Cap vent appliance is designed to operate when an undisturbed airfl... -
Page 22: Installation Planning
QUALIFIED Installation Planning INSTALLER Only qualifi ed licensed or trained personnel should install this appliance. Installer—READ THIS FIRST 12. Put batteries in receiver and remote control 1. YOU NEED TO KNOW FROM THE handset. HOMEOWNER what accessories (surround, door, etc.) will be installed with this fi replace; 13. -
Page 23: Installation
QUALIFIED Existing Fireplace Preparation INSTALLER Gas Line Routing Combustible Mantels Plan the routing of the gas line before proceeding. Combustible mantel clearances must conform to those Utilize the existing hole for the gas line. If the factory- required for the original solid-fuel fi replace into which built fi... -
Page 24: Remove Window
QUALIFIED Installation INSTALLER Remove Window The window is held in place by four spring-loaded bolts, two at the top and two at the bottom. 1. To remove the window, turn each bolt a quarter turn to disengage the bolt pin. 2. -
Page 25: Connect Venting
QUALIFIED Installation INSTALLER Connect Venting IMPORTANT: This appliance’s venting system is room sealed and therefore, does not require room air to be used in the combustion process. 1. Rough-in two 3” diameter vent liners into the existing chimney system from the roof. Be careful not to tear or damage the liners in the process. -
Page 26: Connect Gas Supply
QUALIFIED Installation INSTALLER Connect Gas Supply Pressure Test Points The gas supply inlet connection is a 3/8” NPT female The minimum supply pressure is given in the section connector and is located on the left hand side of the Specifi cations of this manual—page 17. control valve. -
Page 27: Change Fuel Bed Support (If Necessary)
QUALIFIED Installation INSTALLER Adjust Fuel Bed Support (if necessary) Moving the fl ange forward will allow more impigement/ glow/fl ame height; moving the fl ange backward will do The appliance is supplied with the fuel bed support the opposite. already installed. All fuel beds can be used with this Note: The rock support included with the Rock Set support. - Page 28 QUALIFIED Installation INSTALLER 4. Rotate the anchor up and out of the way and slide the right hand side panel against the fi rebox side. The panel should be parallel to the edge of the burner plate. Rotate the anchor back down to hold the panel.
-
Page 29: Install 739Lsk Ceramic Logs
QUALIFIED Installation INSTALLER Install 739LSK Ceramic Logs Unpack the ceramic logs very carefully to avoid damaging the fragile material. Install the logs as shown below. Please note that the position of the logs is critical to ensure proper performance of the appliance. 1. - Page 30 QUALIFIED Installation INSTALLER 5. Locate the top right log on the two pins on the right side of the rear log. Ensure a tight fi t against the fl at area around the pins in the rear log. 6. Place the lower end of the center right log onto the pin on the front right log.
-
Page 31: Install 739Rsk Ceramic Rocks
QUALIFIED Installation INSTALLER Install 739RSK Ceramic Rocks 3. Install the ceramic platform in the fi rebox rotating down Unpack the ceramic rocks kit very carefully to avoid to insert the front fi rst behind damaging the fragile material. Install the components the Front Support. - Page 32 QUALIFIED Installation INSTALLER 4. The underside of each ceramic rock is identifi ed 6. Place the left twig across the second by a number and a specifi c protruding positioning and third rocks from the left; rest its triangle. end on the glass near the edge of the platform as shown below.
-
Page 33: Install 739Dwk Driftwood Kit
QUALIFIED Installation INSTALLER Install 739DWK Driftwood Kit 2. Identify the rear log and place it on top of the base log locating it into the notches on top of the log. Pull Unpack the driftwood kit very carefully to avoid the log forward so it is locked in position. - Page 34 QUALIFIED Installation INSTALLER Pebbles 4. Identify the right side cross log, the longest, and place it across the rear log. The narrow end of the Six pebbles are supplied as decorative elements. log rests in a notch of the rear log. The wide end of If used, they should be placed on the platform only.
-
Page 35: Refi T And Check Window
QUALIFIED Installation INSTALLER Refi t and Check Window DANGER 1. To refi t the window, place the window against the The window unit must be correctly installed, fi rebox’s opening frame. Make sure that the wider fastened and sealed after servicing or serious part of the window frame is at the bottom. -
Page 36: Synchronize Remote Control
QUALIFIED Installation INSTALLER Synchronize Remote Control The receiver and the handset of the remote control sys- tem must be initially synchronized before the fi rst use. 1. Insert alkaline batteries in the remote control receiver and handset. The receiver is located left of the control valve under the burner module. -
Page 37: Install Front, Trim And Barrier Screen
QUALIFIED Installation INSTALLER Install Front, Trim and Barrier Screen Install the front and trim chosen by the customer for their fi replace. Install as well the barrier screen which is provided with the front. Show the customer remove the front and also how to access the controls when the front is installed. -
Page 38: Wiring Diagram
QUALIFIED Wiring Diagram INSTALLER Optional Wall Switch Kit 1265WSK Connector Yellow GV60 Wiring Diagram... -
Page 39: Approved Venting Components
QUALIFIED Approved Venting Components INSTALLER Approved Direct Vent Suppliers for Valor Models 700, 739 , 780, 785 and RF24DV Venting Parts Code / availability by Manufacturer Venting Parts Description 4DVC 940264 HSDV4658- Standard Co-axial 46DVA-VC 4DT-VC TM-4VT — 4DH-1313 — 940364 1313 940206LP... -
Page 40: Warranty
1. Extended Warranty Coverage For a period of up to ten (10) years, Miles Industries Ltd., (the “Company”) or its appointed distributor will at its option pay the initial owner for the repair of, or will exchange the following parts or components which are found to be defective in material or workmanship... -
Page 41: Spare Parts
OWNER’S Spare Parts INFORMATION Part Part Code Description Code Description Number Number VDRT Slide Assembly 4006539 Module Gasket—Left 4000181 Exhaust Slide Gasket 4001662 Olive Nut for Pilot Pipe 220K913 Fan Closure Plate 4001136 Pipe—Valve to Pilot 4001838 Port Cover 4001820 Thermal Switch Retainer 4001519 Fuel Bed Support... - Page 42 OWNER’S Spare Parts INFORMATION Part Code Description Number Left Panel Fluted Black 4001812 Valor Red Brick 4001809 Refl ective Glass 4005015 Filler Panel 4005018 Right Panel Fluted Black 4001813 Valor Red Brick 4001810 Refl ective Glass 4005016 Log Set Complete 739LSK Rear Log 4003787...
- Page 43 OWNER’S Spare Parts INFORMATION Natural gas Propane gas natural gas propane gas 12 13 45a, 45b...
- Page 45 Serial Number: Date Purchase (yyyy-mm-dd): Dealer: Customer Information First Name: Last Name: Contact Information Email: Mailing Address Address: City: Province/State: Postal/Zip Code: Country: Cut out page, fi ll information, and mail to Miles Industries Ltd. Online Warranty registration at www.valorfi replaces.com...
- Page 46 Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Thank you for choosing a Valor Product...
