Service Manual
Washing Machine
Model:
DWD-G1282SC
✔
Caution
: In this Manual, some parts can be changed for improving,
their performance without notice in the parts list. So, if you
need the latest parts information, please refer to PPL(Parts
Price List) in Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CORP.
http : //svc.dwe.co.kr
Aug. 2013

Advertisement

Table of Contents
loading

Related Manuals for Daewoo DWD-G1282SC

Summary of Contents for Daewoo DWD-G1282SC

  • Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CORP. http : //svc.dwe.co.kr Aug. 2013...

  • Page 2: Table Of Contents

    AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER AUTO WASHER...

  • Page 3: Specifications

    ■ DWD-FC1X8X SERIES COLD (OPTION) INLET HOSE DETERGENT CASE POWER CORD CONTROL PANEL DOOR HOSE DRAIN ADJUSTABLE LEG LOWER COVER MODEL DWD-FC1081/FC1082/FC1083/FC1084/FC1281/FC1282/FC1283 POWER SOURCE 220-240V, 50/60Hz DiMENSION (WXDXH) 595MM x 590MM x 850MM WEIGHT 59Kg(NET) / 63Kg(GROSS) WATER CONSUMPTION POWER CONSUMPTION 2200W MAXIMUM MASS WASH...

  • Page 4: Installation

    2. INSTALLATION ■ Transit bolts The appliance is fitted with transit bolts to prevent internal damage during transport. ■ Removing transit bolts 1. To prevent internal damage during transport, the 2. Unscrew the 3 bolts with the spanner supplied, special 3 bolts are locked. Before operating the and take out the 3 bolts with the rubber bungs.

  • Page 5: Installation Place Requirement

    ■ Installation place requirement Level floor : Allowable slope under entire washer is 1°. Power outlet : Must be with 1.5 meters of entire side of location of washer. Do not overload the outlet with more than one appliance. Additional Clearance : For wall, door and floor modeling is required.

  • Page 6: Connecting Inlet Hose

    ■ Connecting inlet hose In using only one water tap or in case of only one water inlet valve, connect the inlet hose to the cold water inlet valve. Option : Be careful not to confuse hot water inlet and cold water inlet. FOR ORDINARY TAP 1 Pull down the collar 2 Loosen the four...

  • Page 7: Installation Of Drain Hose

    ■ ■ Installation of drain hose Installation of drain hose Laundry tub max. 100 cm min. 60cm strap max. 100 cm min. 60cm • The drain hose should not be placed higher than 100cm above the floor. • Proper securing of the drain hose will protect the floor from damage due to water leakage. •...

  • Page 8: Level Adjustment

    ■ Level adjustment 1. The level adjustment of the washing machine prevents excessive noise and vibration. Install the washing machine on a solid and even floor surface, if possible, in a corner of the room. Note: The wooden floor may cause excessive vibration.

  • Page 9: Maintenance

    3. MAINTENANCE ❈ Before cleaning the washer interior, unplug the electrical power cord avoid electrical shock hazards. ■ Cleaning your washer 1. Exterior Proper care of your washer can extend its life. The outside of the machine can be cleaned with warm water and a neutral non abrasive household detergent. Immediately wipe off any spills.

  • Page 10: Cleaning The Water Inlet Filter

    ■ ■ Cleaning the water inlet filter Cleaning the water inlet filter • "IE" error message will blink on the control panel when water does not enter the detergent drawer. • "IE" error message will blink on the control panel when water does not enter the detergent drawer. •...

  • Page 11: Cleaning The Detergent Case

    ■ ■ Cleaning the detergent case Cleaning the detergent case ❈ After a while detergents and fabric softeners leave a deposit in the detergent case. ❈ After a while detergents and fabric softeners leave a deposit in the detergent case. •...

  • Page 12: Direction For Disassembly

    4. DIRECTION FOR DISASSEMBLY DOOR LOCK SWITCH 1) Open the door and remove the gasket clamp. 2) Remove the gasket from the front cabinet. 3) Remove two screws, and remove the door lock switch. HEATER AND THERMISTOR 1) Remove four screws on the back cover, and 2) Remove connectors and the earth terminal.
  • Page 13 3) Remove the nut by using a box wrench, and 4) Loosen the nut by using a box wrench, and pull out remove the earth terminal. the heater. UNIVERSAL MOTOR 1) Remove the belt from the pulley. 2) Lay the right side of the washer on the floor, and remove the connector.
  • Page 14 DRAIN PUMP 1) Lay the right side of the washer on the floor, and 2) Remove connectors. remove the lower panel by pressing six sanp fits. 3) Remove the screw, and remove the drain pump from 4) Remove the drain hose. the lower frame.

  • Page 15: Explode View And Parts List

    5. EXPLODE VIEW AND PARTS LIST ■ BOX INLET AS DWD-FC1X6X SERIES DWD-FC1X7X SERIES EXPLODE VIEW AND PARTS LIST...
  • Page 16 PART NAME PART CODE SPECIFICATION Q'TY REMARK 3612608700 DWD-F1X11(2) 3612608710 ABS + SPRAY DWD-F1X13 3612608900 DWD-F1X21(2) 3612608910 ABS + SPRAY DWD-F1X23 3612609700 DWD-F1X31(2) 3612609710 ABS + SPRAY DWD-F1X33 HANDLE CASE 3611148000 HIPS, D-FU124'S DWD-F1X41(2) (CASE HANDLE) DWD-F1X51(2) 3611148001 ABS + SPRAY DWD-F1X43 DWD-F1X53 3611149500...
  • Page 17 ■ BOX INLET AS (DWD-FC1X8X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK A01 CASE HANDLE 36111T2W00 HIPS, FT1081 DWD-FT1*81 ABS + SPRAY, FT1081 DWD-FT1*81 A02 CASE DETERGENT 3611145800 DWD-FT1*81 A03 CAP SOFTENER 3610907800 DWD-FT1*81 A04 INLET BOX 3617511800 PP, D-FU1081 DWD-FT1*81 A05 NOZZLE UNDER 3618103410...
  • Page 18 ■ PANEL FRONT AS (DWD-FC1X8X SERIES) PART NAME PART CODE SPECIFICATION Q'TY REMARK F01 PANEL F 36142T3A00 HIPS, FT1081 F02 BUTTON P.S 3616647600 ABS, FT1081 F03 WINDOW DISPLAY 3615511700 ABS(TR), FT1081 F04 DECO DIAL 36166DGQ00 ABS, FT1081 F05 KNOB DIAL 3616647700 ABS, FT1081 F06 SHAFT KNOB...
  • Page 19 ■ CABINET FRONT AS • 2 pcs Type PART NAME PART CODE SPECIFICATION Q'TY REMARK 3610811210 PCM, SGCC 0.8T, SILVER DWD-FT1XX3 CABINET FRONT 3610811220 SECD 0.7T DWD-FT1XX1(2) SWITCH DOOR LOCK 3619047100 DL-LC.BITRON_3P.250V16A.BI-METAL SCREW TAPPING 7122401208 T2S TRS 4X12 SUS PLATE HINGE SUPPORT 3614531900 SGCC T1.6 No use...
  • Page 20 ■ TUB ASS’Y EXPLODE VIEW AND PARTS LIST...
  • Page 21 PART NAME PART CODE SPECIFICATION Q'TY REMARK T01 BALANCER WEIGHT F L/R 3616106330 D-FC/FB 6.5 kg (L,R 2EA, FD's) T02 SPECIAL SCREW 3616029400 SWCH 8.5X30 B/W Front / B/W Top T03 GASKET 3612327300 EPDM, D-FT1081 T04 CLAMP GASKET AS 3611204520 HSW3, GS T05 TUB *F 3618831000...
  • Page 22 ■ CABINET AS EXPLODE VIEW AND PARTS LIST...
  • Page 23 PART NAME PART CODE SPECIFICATION Q'TY REMARK E01 CABINET 3610811101 SGCC(GI), 0.7TX825.7X1630.8 E02 FRAME LOWER 3612205501 SGCC T1.0 160X580 1 piece E03 FRAME TOP *L 36122UDY00 SGCC T=1.2, FT1081 SVC part E04 FRAME TOP *R 36122UDZ00 SGCC T=1.2, FT1081 E05 BASE UNDER *L 3610392201 SGCC T1.4 100x500 E06 BASE UNDER *R...
  • Page 24 ■ PLATE T AS + PANEL LOWER AS PART NAME PART CODE SPECIFICATION Q'TY REMARK 3614532900 DWD-800W(HIPS, MFC, WH) DWD-F1X11(2) 3614532910 ABS+UV SPRAY, MFC, SILVER DWD-F1X13 3614532920 DWD-F1X2X(HIPS, MFC, WH) DWD-F1X21(2) 3614532930 ABS+UV SPRAY, MFC, SILVER DWD-F1X23 3614533300 FX1X31~2, 41~2(HIPS, MFC, WH) DWD-F1X31(2) DWD-F1X41(2) DWD-F1X51(2)
  • Page 25 ■ DWD-FC1X8X SERIES Program selector For switching the washing machine on and off and for selecting the programs. You can select the course you want by rotating program selector. For the more detailed information, please refer to the page 11~20. Can be rotated in both direction.

  • Page 26: Functions Of The Control Panel

    Time Delay • It can be used to pre-engage time for wash. • Reservation can be made from 1 hours to 12 hours. • Time Delay function is selectable with all programs. Child Lock Mode • Use this function when you want to protect any accident occurring from handling of washer by a child.

  • Page 27: Functions Of The Controller

    7. FUNCTIONS OF THE CONTROLLER Sequence Chart Cotton Sythetic Division Progress Time Small Small Small Sensing 20sec. Water Supply 2min. Pre Wash 10min. 8min. Drain 1min. B-Spin 1min. Middle Spin 3min. ■ ■ ■ ■ ■ ■ Sensing 20sec. ■ ■...
  • Page 28 Delicate Sports wear Wool Hand wash Quick 30 Rinse + Spin Division Progress Time 1X~5X 6X,7X Small Small Small Small Small Soak 30min. ■ ■ ■ ■ ■ (1min.) Water Supply 2min. Wash 1 60min. (Heating) 50min. 35min. 30min. ■ 5min.
  • Page 29 Sequence Chart (for apply 'Islamic Rinse' option) Example) Apply 'Islamic Rinse' option with Cotton/Normal course. Cotton/Normal Islamic Rinse Option Division Progress Time S (A) L (B) S (a) L (b) ■ ■ Sensing 20sec. ■ ■ Water Supply 2min. Wash 1 30min.

  • Page 30: Function Of The Convenient Service

    8. FUNCTION OF THE CONVENIENT SERVICE ■ The test mode of the operation You can check the PCB AS and the operation of the washing machine simply. • The method to test and operate 1 Press the Power button. 2 Press the Option button 3 times while press the Temp button. At this time, the version is displayed on the Custom LED 3 Whenever the Time Delay button is pressed, the washing machine is operated as following.
  • Page 31 ■ The spinning test mode You can continually spin the washing machine with constant speed. • The method to test and operate 1 Press the Power button. 2 Press the Time Save button 3 times while press Temp button. 3 '400' displays on '18:88 LED'. 400 means the spinning rpm. You can adjust the spinning rpm by pressing Spin button.

  • Page 32: Troubleshooting Guide

    9. TROUBLESHOOTING GUIDE This wahing machine is equipped with automatic safety function which detect and diagnose faults at an early stage and react appropriately. When the machine does not function properly or does not fuction at all, check the following points. SYMPTOM CAUSE SOLUTION...
  • Page 33 SYMPTOM CAUSE SOLUTION Washer does not start. Electronical power cord may not be Make sure plug fits tightly in wall outlet. plugged in or connection may be loose. House fuse blown, circuit breaker Reset circuit breaker or replace fuse. tripped, or a power outage has Do not increase fuse capacity.
  • Page 34 MESSAGE ERROR CAUSE SOLUTION The water tap is closed. Open the water tap. The filter of the valve inlet is clogged. Clean the filter of the valve inlet. The valve inlet is an inferior product or broke down. Change the valve inlet. WATER INLET The water level sensor (sensor pressure) is an inferior product Change the water level sensor...
  • Page 35 MESSAGE ERROR CAUSE SOLUTION The water temp. is over 45˚C in delicate & wool course. WATER TEMP. Change the thermistor wash. ERROR (The thermistor wash is an inferior product or broke down.) The heater wash dose not work. HEATER WASH Change the heater wash.

  • Page 36: Wiring Diagram

    10. WIRING DIAGRAM WIRING DIAGRAM...
