12 Technical data

12 Technical data
▪ A subset of the latest technical data is available on the regional
Daikin website (publicly accessible).
▪ The full set of latest technical data is available on the Daikin
extranet (authentication required).
12.1

Overview: Technical data

This chapter contains information about:
▪ Service space
▪ Piping diagram
▪ Wiring diagram
12.2

Service space: Outdoor unit

Make sure the space around the unit is adequate for servicing and
the minimum space for air inlet and air outlet is available (refer to the
figure below and choose one of the possibilities).
b
c
a a
a a
d
b
c
e
f
a
a
d
b
c
e
f
a
a
d
Layout A+B+C+D
Possibility 1
1 a≥10 mm
b≥300 mm
c≥10 mm
d≥500 mm
2 a≥10 mm
b≥300 mm
c≥10 mm
d≥500 mm
e≥20 mm
Installer and user reference guide
54
b
c
e e
d
b
c
e
d
a
a
b
A+B
Possibility 2
a≥50 mm a≥200 mm
b≥100 mm b≥300 mm
c≥50 mm
d≥500 mm
a≥50 mm a≥200 mm
b≥100 mm b≥300 mm
c≥50 mm
d≥500 mm
e≥100 mm e≥400 mm
Layout A+B+C+D
Possibility 1
3 a≥10 mm
b≥300 mm
c≥10 mm
d≥500 mm
e≥20 mm
f≥600 mm
4 a≥10 mm
b≥300 mm
c≥10 mm
d≥500 mm
e≥20 mm
5 a≥10 mm
b≥500 mm
c≥10 mm
d≥500 mm
e≥20 mm
f≥900 mm
h
2
F
d
(mm)
ABCD Sides along the installation site with obstacles
F Front side
Suction side
▪ In case of an installation site where sides A+B+C+D have
obstacles, the wall heights of sides A+C have no impact on
service space dimensions. Refer to the figure above for impact of
wall heights of sides B+D on service space dimensions.
▪ In case of an installation site where only the sides A+B have
obstacles, the wall heights have no influence on any indicated
service space dimensions.
▪ The installation space required on these drawings are for full load
heating operation without considering possible ice accumulation. If
the location of the installation is in a cold climate, then all
dimensions above should be >500 mm to avoid accumulation of
ice in between the outdoor units.
INFORMATION
The service space dimensions in above figure are based
on cooling operation at 35°C ambient temperature
(standard conditions).
INFORMATION
Further specifications can be found in the technical
engineering data.
A+B
Possibility 2
a≥50 mm —
b≥100 mm
c≥50 mm
d≥500 mm
e≥100 mm
f≥500 mm
a≥50 mm
b≥100 mm
c≥50 mm
d≥500 mm
e≥100 mm
a≥50 mm —
b≥500 mm
c≥50 mm
d≥500 mm
e≥100 mm
f≥600 mm
h
1
b
RYYQ+RYMQ+RXYQ8~20U7Y1B
VRV IV+ heat pump
4P546228-1 – 2018.09
