4 About the units and options
4.5.2

Possible combinations of indoor units

In general following type of indoor units can be connected to a VRV
IV heat pump system. The list is non-exhaustive and is depending
on both outdoor unit model and indoor unit model combinations.
▪ VRV direct expansion (DX) indoor units (air to air applications).
▪ SA/RA (Sky Air/Residential Air) direct expansion (DX) indoor units
(air to air applications). Further referred to as RA DX indoor units.
▪ Hydrobox (air to water applications): HXY080/125 series only.
▪ AHU (air to air applications): EKEXV-kit+EKEQ-box are required,
depending on application.
▪ Aircurtain (air to air applications): CYQ/CAV (Biddle) series,
depending on application.
4.5.3

Possible combinations of outdoor units

Possible standalone outdoor units
Non-continuous heating
RXYQ8
RXYQ10
RXYQ12
RXYQ14
RXYQ16
RXYQ18
RXYQ20
Possible standard combinations of outdoor units
INFORMATION
U-series units cannot share the same refrigerant circuit
with T-series units. However, electrically , U-series units
and T-series units can be connected via F1/F2.
▪ RXYQ22~54 consists of 2 or 3 RXYQ8~20 units.
▪ RYYQ22~54 consists of 2 or 3 RYMQ8~20 units.
▪ RYYQ8~20 units cannot be combined.
▪ RYMQ8~20 units cannot be used as standalone outdoor unit.
Non-continuous heating
RXYQ22 = RXYQ10 + 12
RXYQ24 = RXYQ8 + 16
RXYQ26 = RXYQ12 + 14
RXYQ28 = RXYQ12 + 16
RXYQ30 = RXYQ12 + 18
RXYQ32 = RXYQ16 + 16
RXYQ34 = RXYQ16 + 18
RXYQ36 = RXYQ16 + 20
RXYQ38 = RXYQ8 + 10 + 20
RXYQ40 = RXYQ10 + 12 + 18
RXYQ42 = RXYQ10 + 16 + 16
RXYQ44 = RXYQ12 + 16 + 16
RXYQ46 = RXYQ14 + 16 + 16
RXYQ48 = RXYQ16 + 16 + 16
RXYQ50 = RXYQ16 + 16 + 18
RXYQ52 = RXYQ16 + 18 + 18
RXYQ54 = RXYQ18 + 18 + 18
Installer and user reference guide
10
Continuous heating
RYYQ8
RYYQ10
RYYQ12
RYYQ14
RYYQ16
RYYQ18
RYYQ20
Continuous heating
RYYQ22 = RYMQ10 + 12
RYYQ24 = RYMQ8 + 16
RYYQ26 = RYMQ12 + 14
RYYQ28 = RYMQ12 + 16
RYYQ30 = RYMQ12 + 18
RYYQ32 = RYMQ16 + 16
RYYQ34 = RYMQ16 + 18
RYYQ36 = RYMQ16 + 20
RYYQ38 = RYMQ8 + 10 + 20
RYYQ40 = RYMQ10 + 12 + 18
RYYQ42 = RYMQ10 + 16 + 16
RYYQ44 = RYMQ12 + 16 + 16
RYYQ46 = RYMQ14 + 16 + 16
RYYQ48 = RYMQ16 + 16 + 16
RYYQ50 = RYMQ16 + 16 + 18
RYYQ52 = RYMQ16 + 18 + 18
RYYQ54 = RYMQ18 + 18 + 18
4.5.4

Possible options for the outdoor unit

INFORMATION
Refer to the technical engineering data for the latest option
names.
Refrigerant branching kit
Description
Refnet header
Refnet joint
For the selection of the optimal branching kit, please refer to
"5.3.3 To select refrigerant branch kits" on
Outdoor multi connection piping kit
Number of outdoor units
2
3
Cool/heat selector
In order to control the cooling or heating operation from a central
location, the following option can be connected:
Description
Cool/heat changeover switch
Cool/heat changeover PCB
With optional fixing box for the
switch
External control adaptor (DTA104A61/62)
To instruct specific operation with an external input coming from a
central control the external control adaptor can be used. Instructions
(group or individual) can be instructed for low noise operation and
power consumption limitation operation.
PC configurator cable (EKPCCAB)
You can make several commissioning field settings through a
personal computer interface. For this option EKPCCAB is required
which is a dedicated cable to communicate with the outdoor unit.
The user interface software
www.daikineurope.com/support-and-manuals/software-downloads/.
Heater tape kit
To keep the drain holes free in cold climates with high humidity, you
can install a heater tape kit. If you do so, you also have to install the
heater tape PCB kit.
Description
Heater tape kit for 8~12 HP
Heater tape kit for 14~20 HP
See also: "5.2.2 Additional installation site requirements of the
outdoor unit in cold climates" on
Demand PCB (EKRP1AHTA)
To enable the power saving consumption control by digital inputs
you must install the demand PCB.
For installation instructions, see the installation manual of the
demand PCB and addendum book for optional equipment.
Model name
KHRQ22M29H
KHRQ22M64H
KHRQ22M75H
KHRQ22M20T
KHRQ22M29T9
KHRQ22M64T
KHRQ22M75T
page 15.
Model name
BHFQ22P1007
BHFQ22P1517
Model name
KRC19-26A
BRP2A81
KJB111A
is available on http://
Model name
EKBPH012TA
EKBPH020TA
page 12.
RYYQ+RYMQ+RXYQ8~20U7Y1B
VRV IV+ heat pump
4P546228-1 – 2018.09
