USER'S MANUAL

PACKAGED TERMINAL

AIR CONDITIONER

WITH HEAT PUMP / HEAT STRIP

Model: CH-PT09HPGF

CH-PT09HSGF

The warranty is only valid when installed by a LICENSED HVAC

TECHNICIAN.

F or proper operation, please read and keep this manual carefully.

www.cooperandhunter.com

Table of Contents

Need help?

Do you have a question about the CH-PT09HSGF and is the answer not in the manual?

Questions and answers

Summary of Contents for Cooper & Hunter CH-PT09HSGF

Page 1 PACKAGED TERMINAL AIR CONDITIONER WITH HEAT PUMP / HEAT STRIP Model: CH-PT09HPGF CH-PT09HSGF The warranty is only valid when installed by a LICENSED HVAC TECHNICIAN. F or proper operation, please read and keep this manual carefully. Designed by Cooper&Hunter International Corporation, Oregon, USA...
Page 2: Table Of Contents
CONTENTS 1. SAFETY PRECAUTIONS..............2 2. IMPORTANT SAFETY INSTRUCTIONS ..........4 3. AIR CONDITIONER FEATURES............5 4. CONTROL PANEL OPERATION............6 5. INSTALLATION .................7 6. CARE AND CLEANING..............9 7. TROUBLESHOOTING...............10 Read This Manual Inside you will find many helpful hints on how to use and maintain your air conditioner properly.
Page 3: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury.
Page 4 ! CAUTION When the air filter is to be Do not clean the air Ventilate the room well when conditioner with water. used together with a stove, removed, do not touch the metal parts of the unit. etc. It may cause an injury. Water may enter the unit and An oxygen shortage may occur.
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS For your safety WARNING NOTE The power supply cord with Do not store or use gasoline or other flammable vapors and liquids in this air conditioner contains a current the vicinity of this or any other appliance. detection device designed to reduce Avoid fire hazard or electric shock.
Page 6: Air Conditioner Features
Operation of Cur rent Device(optional) The power supply cord contains a current device that senses damage to the power cord. To test your power supply cord do the following: 1. Plug in the Air Conditioner. 2. The power supply cord will have TWO buttons on the plug head. Press the TEST button, you will notice a click as the RESET button pops out.
Page 7: Control Panel Operation
CONTROL PANEL OPERATION The control panel keypad will look like the following UP/DOWN BUTTONS ( Fig.1: - Push the UP (or DOWN) button to increase (or decrease) the set temperature of the unit in cooling or heating mode.The temperature can be set by increments of 1 C (1 F).The setting temperature appears in the display.
Page 8: Installation
INSTALLATION HOW TO INSTALL THE UNIT Dimension of air conditioner CAUTION 1067mm/4 2in ch There are sharp edges that can cause serious cuts. When lifting the air conditioner,it is HEAVY.Use 2 408mm/1 6in ch people to lift. - For existing sleeve,you should measure the wall sleeve dimensions.
Page 9 INSTALLATION（CONTINUED） UNIT INSTALLATION (CONTINUED) CAUTION - Rotate the vent control lever to either open or close the vent door.(See Fig.6) Do not put obstacles around air-inlet or inside of air-outlet of the unit, such as window curtain etc. Vent control lever Always insert the filter securely, clean filter once every two weeks as required.
Page 10: Care And Cleaning
CARE AND CLEANING - Removing Air Filter FRONT PANEL AND CASE - Turn unit off and disconnect power supply.To clean, 2 Air filters use water and a mild detergent.DO NOT use bleach and abrasivers.Some commercial cleaners may Pull up damage the plastic parts. OUTDOOR COIL - Coil on outdoor side of unit should be checked regularly.Unit will need to be removed to inspect...
Page 11: Troubleshooting
TROUBLESHOOTING POSSIBLE CAUSES SOLUTONS UNIT DOES NOT START Check that plug is plugged securely in wall receptacle. Unit may have become unplugged Note:Plug has a test/reset button on it.Make sure that the plug has Fuse may have blown not tripped. Circuit breaker may have been tripped Replace the fuse.See Note 1.
Page 12 www.cooperandhunter.us LIMITED WARRANTY STATEMENT PACKAGED TERMINAL AIR CONDITIONER This warranty should be registered on our web-site www.cooperandhunter.us The warranty is only valid when installed by a Licensed HVAC Technician FOR WARRANTY SERVICE OR REPAIR: Contact your installing contractor. You may find the installer’s name on the equipment or in your Owner’s packet. Complete product registration below and send back by e-mail at warranty@cooperandhunter.us PRODUCT REGISTRATION: Model No.: ______________________________________________________________________________________________...
Page 13 LIMITATIONS OF WARRANTIES: ALL IMPLIED WARRANTIES AND/OR CONDITIONS (INCLUDING IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR USE OR PURPOSE) ARE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY. SOME STATES OR PROVINCES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY OR CONDITION LASTS, SO THE ABOVE MAY NOT APPLY TO YOU.
