- Page 1 SOPHIA HIGH-WALL DUCTLESS AIR CONDITIONING & HEATING SYSTEM OWNER'S MANUAL Models: CH-S30FTXW-SV (230V) CH-S36FTXW-SV (230V) IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.
-
Page 2: Operation And Maintenance
Precautions WARNING Operation and Maintenance This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 3 WARNING Maintenance must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Do not repair air conditioner by yourself. It may cause electric shock or damage. Please contact dealer when you need to repair air conditioner. Do not extend fingers or objects into air inlet or air outlet.
- Page 4 WARNING Attachment Installation must be performed by qualified professionals. Otherwise, it may cause personal injury or damage. Must follow the electric safety regulations when installing the unit. According to the local safety regulations, use qualified power supply circuit and circuit break. Do install the circuit break.
- Page 5 WARNING Do not put through the power before finishing installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. The temperature of refrigerant circuit will be high, please keep the interconnection cable away from the copper tube.
- Page 6 WARNING For the air conditioner with plug, the plug should be reachable after finishing installation. For the air conditioner without plug, an circuit break must be installed in the line. If you need to relocate the air conditioner to another place, only the qualified person can perform the work.
-
Page 7: Unit Parts
Unit Speci cations and Features Unit Parts Power Cable (Some Units ) Front Panel Louver Remote Control Functional Filter (On Front of Main Filter - Some Units) ON/OFF TEMP MODE SILENCE SWING SPEED TIMER SWING TIMER SLEEP Remote Holder (Some Units) TURBO SELF FOLLOW... -
Page 8: Achieving Optimal Performance
Achieving Optimal Performance Optimal performance for the COOL, HEAT, and DRY modes can be achieved in the following temperature ranges. When your air conditioner is used outside of these ranges, certain safety protection features will activate and cause the unit to perform less than optimally. Inverter Split Type FOR UNITS WITH COOL mode... -
Page 9: Other Features
• Wi-Fi Control (some units) For a detailed explanation of each function, Wi-Fi control allows you to control your air refer to the Remote Control Manual. conditioner using your mobile phone and a Wi-Fi connection. Other Features • Louver Angle Memory(some units) •... - Page 10 • Setting Angle of Air Flow Setting vertical angle of air ow While the unit is on, use the SWING /DIRECT button to set the direction (vertical angle) of airflow. 1. Press the SWING /DIRECT button once to activate the louver. Each time you press the button, it will adjust the louver by 6°.
-
Page 11: Sleep Operation
• Sleep Operation The SLEEP function is used to decrease energy use while you sleep (and don’t need the same temperature settings to stay comfortable). This function can only be activated via remote control. Press the SLEEP button when you are ready to go to sleep. -
Page 12: Manual Operation (Without Remote)
Manual Operation (Without Remote) How to operate your unit without CAUTION the remote control The manual button is intended for testing In the event that your remote control fails to purposes and emergency operation only. Please work, your unit can be operated manually with do not use this function unless the remote is the MANUAL CONTROL button located on lost and it is absolutely necessary. -
Page 13: Care And Maintenance
Care and Maintenance 6. Rinse the lter with fresh water, then shake Cleaning Your Indoor Unit o excess water. BEFORE CLEANING OR 7. Dry it in a cool, dry place, and refrain from exposing it to direct sunlight. MAINTENANCE 8. When dry, re-clip the air freshening lter to ALWAYS TURN OFF YOUR AIR CONDITIONER SYSTEM AND DISCONNECT ITS POWER SUPPLY the larger lter, then slide it back into the... -
Page 14: Maintenance - Long Periods Of Non-Use
Maintenance – CAUTION Long Periods of Non-Use • Before changing the lter or cleaning, If you plan not to use your air conditioner for an turn o the unit and disconnect its power extended period of time, do the following: supply. -
Page 15: Troubleshooting
Troubleshooting S AFETY PRECAUTIONS If ANY of the following conditions occurs, turn o your unit immediately! • The power cord is damaged or abnormally warm • You smell a burning odor • The unit emits loud or abnormal sounds • A power fuse blows or the circuit breaker frequently trips •... - Page 16 Issue Possible Causes A rushing air sound may occur when the louver resets its position. The indoor unit makes noises A squeaking sound may occur after running the unit in HEAT mode due to expansion and contraction of the unit’ s plastic parts.
- Page 17 Troubleshooting When troubles occur, please check the following points before contacting a repair company. Problem Possible Causes Solution Temperature setting may be higher than ambient Lower the temperature setting room temperature The heat exchanger on the indoor or outdoor unit is Clean the a ected heat exchanger dirty Remove the filter and clean it...
- Page 18 Problem Possible Causes Solution Wait for the power to be Power failure restored The power is turned o Turn on the power The fuse is burned out Replace the fuse The unit is not working Remote control batteries are Replace batteries dead The Unit’...
-
Page 19: System Operation
SYSTEM OPERATION COOLING OPERATION How it works: In cooling mode, your sophia indoor unit will absorb heat from the room, then the Sophia outdoor unit will discharge the heat to the outdoors. The sophia cooling capacity decreases as the outdoor temperature increases. This causes the ali ce to work harder and longer to hold the selected room temperature. -
Page 20: Energy Saving Tips
ENERGY SAVING TIPS 1. Relaxing room temperature at night is OK : During the nighttime hours you don’t require the same level of conscious cooling or heating. Try using Sleep Mode to gradually relax room temperature and allow the unit to run less and save energy. 2. -
Page 21: Limited Warranty Statement
www.cooperandhunter.us LIMITED WARRANTY STATEMENT Ductless Heat Pump Split System This warranty should be registered on our web-site www.cooperandhunter.us The warranty is only valid when installed by a Licensed HVAC Technician FOR WARRANTY SERVICE OR REPAIR: Contact your installing contractor. You may find the installer’s name on the equipment or in your Owner’s packet. Complete product registration below and send back by e-mail at PRODUCT REGISTRATION: Model No.: ______________________________________________________________________________________________... -
