- Page 1 Instruction Manual...
-
Page 2: Specifications
Your Rocktron Bass20 Bass Amplifier has been tested and complies with the following Standards and Directives as set forth by the European Union: Standard(s): This means that this product has been designed to meet stringent guidelines on how much RF energy it can emit, and that it should be immune from other sources of interference when properly used. -
Page 3: Operating Temperature
NOTE: IT IS VERY IMPORTANT THAT YOU READ THIS SECTION TO PROVIDE YEARS OF TROUBLE FREE USE. THIS UNIT REQUIRES CAREFUL HANDLING. • All warnings on this equipment and in the operating instructions should be adhered to and all operating instructions should be followed. •... -
Page 4: Front Panel
Front Panel Input Jack Using a standard guitar cable with a 1/4” jack - plug your bass into this jack. Master Volume Control The control adjusts the overall output of the amplifier. When turning the amplifier on, make sure this control is turned all the way down to zero. -
Page 5: Back Panel
Back Panel Power Cable Connection Using the included power cable connect the amplifier to a standard wall outlet. See”Fuse Replacement” section for details on how to replace the fuse. Effects Loop Jacks These 1/4” jacks allow you to plug into outboard effects units. Return/CD Input Plug the output of the effects unit into this jack. -
Page 6: Fuse Replacement
Fuse Replacement We recommend that you use an authorized repair person to change the fuse in this unit. To access the fuse, first power down the unit and unplug the cable from the wall outlet and the amplifier. Using a small screw driver, open the fuse tray by prying open the small tab as shown in the drawing above. -
Page 7: Other Rocktron Products
Vendetta Head(100 W Head 4-Channels All Tube - MIDI Switchable) Vendetta Combo (100W 2x12 Combo Celestion 90s all Tube4-Channel MIDI Switchable) RT122C (120W 2x12 Amp w/Stereo Chorus, Reverb & Chromatic Tuner) Rack Gear: Voodu Valve (preamp w/12ax7 tube and multi-effects) HUSH ... - Page 8 Rocktron - A Division of GHS Corporation 2813 Wilber Ave Battle Creek MI 49015 Tel: 1-269-968-3351 Fax: 1-269-968-6913 (8am to 5pm Eastern Standard Time) www.rocktron.com Rev. 080105...
