- Page 1 /SPECIALTY 042023 TY3/4 I S LAND MERCHANDI S ER U S E R M A N U A L ‐ TY3‐3X4.5E‐R ‐ TY3‐3X5.5E‐R ‐ TY3‐3X4.5E‐S ‐ TY3‐3X4.5E‐S ‐ TY4‐3X4.5E‐R ‐ TY4‐3X5.5E‐R...
-
Page 2: Table Of Contents 1. General Instructions
Check your shipment for any possible shortages of material. If a shortage should exist and is found to be the responsibility of Hussmann Chino, notify Hussmann Chino. If such a shortage involves the carrier, notify the carrier immediately, and request an inspection. -
Page 3: Table Of Contents
2.Table of Contents 1. General Instructions...............2 2. Table of Contents ..............3 3. Warning ...................4 4. Cut and Plan View ..............5 5. Notice..................6 6. Installation................7 7. Electrical …………………………………………………………12 8. Wiring Diagram Index............13 9. Wiring Diagrams ………………………………………………..15 10. Spec Sheet ................56 11. Parameter Report ..............58 12. -
Page 4: Warning
3. Warning IMPORTANT INFORMATION Please read these instructions completely before beginning case installation 1. Do not push, pull, adjust or manipulate the merchandiser by any glass component. • Doing so will result in severe damage to such compo- nents. • Glass or acrylic breakage may result in serious injury. -
Page 5: Cut And Plan View
4. Cut and Plan Views 1/2 (826) 1/2 (826) (254) Angled Shelf Insert Angled Shelf Insert -optional (254) -optional (1464) (254) (1718) (870) (254) (616) (254) Shelves - optional Shelves - optional (298) (298) (740) (740) (695) (695) (514) (514) 1/2 (724) 1/2 (724) 1/8 (918) -
Page 6: Notice
5. Notice Receiving Case NOTICE Upon receiving your new Hussmann Case all equipment should be thoroughly examined for shipping damage be- fore and during unloading. This equipment has been care- Do NOT remove Foam Blocks from shelves fully inspected at our factory. Any claim for loss or damage and glass until the merchandisers are must be made to the carrier. -
Page 7: Installation
6. Installation Do Not Install the Vented Panels of the Store Conditions self-contained model against a wall or • Case is designed to operate at temperatures at either 75°F at 55% relative humidity or 80°F at 55% relative other storage fixture. humidity. - Page 8 Installation (Cont’d) Condensate Pan Setup and Maintenance Clearances Setup: Minimum Clearances for Self-Contained cases are to be There are two condensate evaporator pans on this unit. The followed as instructed for proper placement inside store drain pipes from the case feed into the Condensate Pan. locations.
- Page 9 Installation (Cont’d) Close-off Removal Step 1 Slide bottom of close-off in upward motion to remove close-off panel slots from lower close-off tabs. Step 2 Pull Close-off in outward then downward motion to com- pletely remove side panel close-off The side close-off panels are held in place by upper and lower tabs located on the underside of the tub and bottom base channel near the bottom of the case.
- Page 10 Installation (Cont’d) Entyce Lifting and Transporting Instructions J-Bar Lift Zone (Approximate) Lift Point J-Bar Lift Point J-Bar J-Bar Lift Point Lift Point J-Bar J-Bar Lift Point Lift Point 1. The Entyce can be lifted by a forklift only at the specified location in the diagram WARNING Improper placement of forks may damage drainage piping.
- Page 11 Installation (Cont’d) 8. Do not lift in marked areas • Lifting in the prohibited areas can cause serious damage to merchandiser and critical components such as refrigeration and electrical components. • Damage to critical components will affect case performance. 9. For optimal lifting of merchandiser support case along highlighted channels shown above. •...
-
Page 12: Electrical
7. Electrical Field Wiring and Serial Plate Amperage Field Wiring must be sized for component amperes printed on the serial plate. Actual ampere draw may be less than specified. Field wiring from the refrigeration control panel to the merchandisers is required for refrigeration thermostats. -
Page 13: Wiring Diagram Index
8. Wiring Diagram Index 3X4.5E-R 4.5' 3047019 3X5.5E-R 5.5' 3067255 4X4E-R 1H96214 4X6E-R 1H85148 5X9.5E-R 9.5' 3025698 6X8E-R 1H87790 6X10E-R 3047529 5X11.5E-R 11.5' 3025699 6X12E-R 1H93263 3X4.5E-R 4.5" 3147394 3X5.5E-R 5.5" 3105086 4X4E-R 3047020 4X6E-R 1H93523 4X8E-R 3047526 4X10E-R 3047527 5X7.5E-R 8", 12", 14"... - Page 14 Wiring Diagram Index (cont’d) TY4- PRESSURE CONTROL TY4-4X4E-S R-404A/448A 3129624 TY4-4X6E-S R-404A/448A 3129626 TY4-4X8E-S R-448A 3129628 TY4-SELF CONTAINED TY4-4X4E-S 3042639 DAN FOSS TY4-3X5.5E-S 5.5' 3042640 TY4-4X6E-S 3042642 TY4-4X8E-S 3071170 DIXELL CTRL TY3EC-3X4.5E-S W/XR75 CTLR 4.5' 3168381 TY3ECRC-4X6E-S W/XR75 CTLR 3157152 TY3-4X4E-S W/XR75 CTLR 3160998 TY4-4X6E-S W/XR75 CTLR...
-
Page 56: Spec Sheet
10. Spec Sheet SELF-SERVICE DELI REVISION DATE 01/29/19 HUSSMANN - TY3-3 E-END REMOTE (CHINO) REFRIGERATION DATA: EST. 20°F GLYCOL CAPACITY *** TEMPERATURE (ºF) REFG. (BTU/HR/FT) VELOCITY 6° RISE CASE (FT/MIN) CHRG. LENGTHS CASE LENGTHS CASE USAGE RATING DISCHARGE EVAPORATOR (LBS) CONDITION AIR ** (°F) - Page 57 Spec Sheet...
-
Page 58: Parameter Report
11. TY Parameter Report PGM0010A01 PGM0010A02 TANDARD CASE REV B 9/6/1 Sheetz REV B 9/21/17 Parameter Code Default Actual (°C) Actual (°F) Actual (°C) Actual (°F) Temperature (set point) Deli (Type I) -50.0°C 50.0°C 2.0°C -3.3 -5.0 Deli (Deli Type II) -50.0°C 50.0°C 2.0°C... - Page 59 TY Parameter Report Real time clock Six start times for defrost. t01-t06 0 hours 23 hours 0 hours 0 hours 0 hours Setting of hours. 0=OFF t11-t16 0 min 59 min 0 min 0 min 0 min Six start times for defrost. Setting of minutes.
-
Page 60: Danfoss Controller
12. SC (Danfoss Controller) User Guide Controller for temperature control AK-CC 210 ADAP-KOOL® Refrigeration control systems Open Camera IPhone User Hold the camera up to the QR code Android User Open QR Code Reader app if necessary. Hold the camera up to the QR code Tap the notification to be taken to the destination of the QR code... -
Page 61: Dixell Controller
13. SC (Dixell Controller) 026-1210 Rev 3 03-FEB-2015 XR75CX Digital Controller for Medium‐Low Temperature Refrigeration Applications Installation and Operation Manual Open Camera IPhone User Hold the camera up to the QR code Android User Open QR Code Reader app if necessary. Hold the camera up to the QR code Tap the notification to be taken to the destination of the QR code... -
Page 62: Troubleshooting Guide
14. Troubleshooting Guide Problem Possible Cause Possible Solution Case temperature is Ambient conditions may Check case position in store. Is the case located near an too warm. be affecting the case open door, window, electric fan or air conditioning vent that operation. - Page 63 Troubleshooting Guide (Cont'd) Problem Possible Cause Possible Solution Water has pooled Case drain is clogged. Clear drain. under case. PVC drains under case Repair as needed. may have a leak. Case tub has unsealed Seal as needed. opening. Evaporator pan is Check electrical connection to evaporator pan.
- Page 64 Troubleshooting (Cont’d) Condition Troubleshooting Fan Emits Excessive Noise Check that the case is aligned, level and plumb. Check evaporator fan for cleanliness. Unplug fan motors; check motor shaft for excessive bearing wear. Check the fan motors are securely mounted in brackets. Verify that fan blades are securely mounted to fan motor.
- Page 65 Troubleshooting (Cont’d) Troubleshooting Condensing System (Qualified Service Technicians Only) Condition Troubleshooting Head Pressure too High Check that the Condensing Coil is not dirty or covered. Check the Condensing Fans are working. Check that the refrigeration system is not overcharged. Check that case is free of non-condensables. Check that the Liquid Line Drier Filter is not plugged.
-
Page 66: Maintenance
15. Maintenance Case Cleaning Service To insure long life, proper sanitation and minimum • Replace Filter every 6 months or as needed to maintain maintenance costs, the refrigerator should be thoroughly efficient operation.(if applicable) cleaned frequently. SHUT OFF FAN BEFORE CLEANING: •... -
Page 67: Appendices
The installer is responsible for following the installation instructions and recommendations NOTE:Public Health will use the temperature of the product in provided by Hussmann for the installation of each determining if the refrigerator will be allowed to display potentially hazardous food. For the purpose of this individual type refrigerator. - Page 68 User been allowed to stabilize, i.e., maintain a constant reading. Hussmann Corporation provides instructions d) OTHER OBSERVATIONS - Other and recommendations for proper periodic observations should be made which may cleaning. The user will be responsible for...
- Page 69 Keep meat under refrigeration in meat cutting and processing area except for the few moments it is being handled in processing. When a cut or tray of meat is not to be worked For further technical information, please log on to http://www.hussmann.com/products/ISLA.htm...
- Page 70 Additional copies of this publication may be obtained by contacting: unit. Hussmann® Chino They can be found on a small metal plate on the unit. 13770 Ramona Avenue • Chino, California 91710 Please note them below for future reference.
