Operating the machine control
Welding task administration (Menu)
5.6.3 Program sequence
In the program sequence, you can select welding parameters and set their values. The number of para-
meters shown depends on the selected operating mode.
In addition, the user can access advanced settings and the setup mode.
The setting range for the parameter values are summarised in the parameter overview
section > see 8.2 chapter.
Item Symbol
1 ▲
2
3
4
38
Description 0
Parameter position
Displays the currently selected welding parameters in the functional sequence
Advanced settings
Display and setting of advanced process parameters
Setup mode > see 5.6.4 chapter
Operating mode setting
Figure 5-15
