QUICK START

Chapter 2 – Quick Start

Preparing an RBS301 Sensor

Sensors ship with batteries installed. There is a plastic tab over the battery, which needs to be removed.
Pull the tab out of the sensor to connect the battery. If the tab does not pull out easily, you may need to
open the case to remove it.
To open the case:
1. Use a pen or similar object to press the button on the opposite side of the case.
2. Remove the battery tab. You may need to remove the battery to remove the tab.
3. Re-insert the battery and close the case.
Quick Start
Use your sensor through either the console or a third-party network. To use the console, use the following steps.
To use a third-party network, refer to the Connecting LoRaWAN Sensors on Gateways and Networks (RB00001) ,
which is available through the sensor page at
1. Create a console account at:
2. Click on Devices on the left.
3. Click Add Device.
4. Select the network you want to use.
5. Make sure Console Only Device is NOT selected.
6. Specify if you want to Register Through Radio Bridge or use an existing account with the network.
7. Enter the Device Name, Device ID, and Device Key.
Note: For easy Device ID and Key entry, scan the QR code on the yellow key card included with your
device. Then copy and paste data into the console. With the QR code, the first line is the Device ID and
the rest is the key.
8. Select the model from the Device Type drop down. Model is on the device label.
9. Set the Join EUI to 7894E80000000000 and click Continue.
10. Review the summary and click Confirmation.
The console shows complete when the device is successfully added.
6
https://www.multitech.com/products/sensors
https://console.radiobridge.com/
Radio Bridge LoRaWAN
®
Wireless Sensor Door Window Sensor User Guide
