KRUPS SAVOY EC314 - Espresso Coffee Maker Manual

Also See for SAVOY EC314:

Manual (38 pages)

Table of Contents

Contents

1 DESCRIPTION
2 SETTING THE CLOCK
3 BEFORE FIRST USE
4 MAKING COFFEE
5 OTHER FEATURES
6 CLEANING
7 DESCALING
- 7.1 How to descale your KRUPS coffee maker
- 7.2 DUO FILTER CARTRIDGE
8 TROUBLESHOOTING
9 Documents / Resources
- 9.1 Download manual

KRUPS SAVOY EC314 - Espresso Coffee Maker Manual

DESCRIPTION

Device Overview

Body of the appliance
Lid
Water tank
Water level indicator
Carafe lid
Carafe handle
Carafe
Warming plate
Filter holder
Permanent filter (avoids paper filters)
BREW/control knob
Clock button
REGULAR/ BOLD button
1-4 cup button
CLEAN button
AUTO ON button
Filter cartridge holder
Filter cartridge
Keep Warm TEMP Button
Keep Warm TIME button
Spoon
Replacement indicator of the filter cartridge

SETTING THE CLOCK

Place the coffee maker on a hard flat surface.
Connect the power cord to a 120V wall socket.

When you connect the coffee maker for the first time, "1:00 pm" displays and flashes on screen. Fig. 1. Program the time by turning the brew knob (k) to the right to increase, to the left to decrease. Validate by pressing the clock button (l) or the brew button (k). The time is displayed. Fig. 2 and 3.
You may also program or change the time at any other time. Press the clock button (l) and turn the brew knob (k). Set by pressing the clock button (l) or the brew button (k). The time is displayed.

Note: Your clock is now programmed and will continue to display the time even when your appliance is on standby.
If the appliance is disconnected or there is a power failure, the clock will return to 1:00 PM. The steps above must be repeated to program the clock again.

BEFORE FIRST USE

Remove stickers from your coffee maker.
Before first use, run your coffee maker without coffee to flush the circuit. Fill the water tank up to the maximum level and begin a cycle by pressing the brew knob (k).

Your appliance was designed to operate only with cold or water at room temperature.

MAKING COFFEE

Open the lid of the coffee maker (b). Fig. 4.
Fill the carafe (g) with cold or water at room temperature. Pour the water in the water tank (c) Fig. 5. The water level indicator displays the number of cups. Do not exceed 12 cups. Fig. 6.
Place the carafe (g) with its lid on the warming plate (h) making sure that it is properly placed to activate the mechanism that will allow the coffee to flow. Fig. 7.
It is best to remove the filter holder with the filter before adding the ground coffee. If ground coffee has accidentally been poured into the water tank, please do not run the cycle; instead clean the water tank. The ground coffee could plug the water circuit.
Add 1 KRUPS (u) spoonful of ground coffee per cup. Do not exceed 12 spoons (2 ounces). Fig. 10.
Make sure the filter holder (i) is inserted. Fig. 8. Place the permanent filter (j) in the filter holder (i) or a No. 4 paper filter. If you use a paper filter, be sure it is fully open and properly positioned in the filter holder. Fig. 9a and 9b.
Close the lid (b).
Press the brew button (k). The button lights up to indicate that the coffee maker has begun the brew cycle. It beeps once. Fig. 11.
When the cycle has ended, the 'keep warm' feature turns on automatically (the countdown showing the time during which it will remain warm is displayed on screen). The brew button (k) flashes slowly.
After the default keep warm time of 30 minutes your appliance beeps 3 times and the brew button (k) switches off.
At any time during the brew cycle, you may turn off the coffee maker by pressing the brew button (k). The light on the brew button will also go out. It beeps 3 times prior to turning off.
Even if the brew cycle has ended, there is still hot liquid in the filter. Wait a few minutes for the rest of the liquid to flow into the carafe before removing the filter.

Note:

The amount of coffee in the carafe at the end of the cycle is less than the amount of water poured into thewater tank, since the ground coffee and the filter absorb about 10% of it.
The water tank is equipped with an overflow outlet at the rear of the appliance. If you add too much water, it will come out of this opening.
Clean the permanent filter in between each use, or use a paper filter.

To avoid overflowing, the carafe should be properly placed on the warming plate of the coffeemaker, otherwise the hot water or hot coffee may overflow.
The coffee maker becomes very hot during the brew cycle. Handle it carefully.

OTHER FEATURES

AUTO START FUNCTION

Programming the auto-start settings.

Your appliance is equipped with two auto-start programs.
Check whether the clock is set to the right time. If not, follow the instructions in the SETTING THE CLOCK section.
Press the AUTO ON button. An AUTO 1 icon displays on screen. Fig. 12.
Turn the brew knob (k) to set the time. Validate by pressing the brew button (k). The time is displayed. Fig. 13 and 14.
Without validation with the brew knob (k), the time is recorded automatically after about 5 seconds.
To set the second program, push the AUTO ON button twice, so that the AUTO 2 icon appears on screen. Fig. 15.
Turn the brew knob (k) to set the time. Validate by pressing the brew knob (k). The time is displayed. Fig. 16 and 17.
If you do not confirm using the brew knob (k), the time is recorded automatically after about 5 seconds.

Activate a delayed start-up where the time is already regulated.

Select AUTO 1 or AUTO 2 by pressing the AUTO ON button. Press the brew button (k) to launch autostart program.

REGULAR OR BOLD

This feature allows you to make a coffee that is more or less full-bodied.
The BOLD feature increases the time of the cycle for a stronger coffee.
Press the REGULAR or BOLD button to select the intensity of your coffee. Fig. 18.
The REG or BOLD icon appears on screen.
The feature is stored in the memory for subsequent cycles.

1-4 CUPS

To activate this feature, press the 1-4 button (n) before starting the cycle. Fig. 19.
This feature is especially designed for making small amounts of coffee, i.e. between 2 and 4 cups. It makes it easier to extract optimal aroma and flavor.

KEEP WARM

TIME

The default keep warm duration on your appliance is 2 hours.
To cancel the keep warm function, press Time (t) and KEEP WARM will disappear from the screen.

To set the keep warm duration:

If the keep warm function has already been activated, press Time (t) once to deactivate it.
If not, press Time (t) and turn the BREW button (k) to select the keep warm duration. The keep warm function may be set from 15 minutes to up to 4 hours. Fig. 20 and 21.
Confirm by pressing BREW (k). As a default setting, the duration is confirmed automatically after approximately 5 seconds. Fig.21
KEEP WARM will appear on the screen and the duration is confirmed.
To cancel the keep warm function, press Time (t) and KEEP WARM will disappear from the screen.
You can change the keepwarm duration while it is in operation by turning the BREW button (k).

TEMPERATURE

You may program 3 temperature levels to keep your coffee warm: LOW, MEDIUM or HIGH.
Press the TEMP button (s) and turn the brew button (k) to select the temperature level. Fig. 22 and 23.
Set by pushing the brew knob (k) or by default, validation is done automatically about every 5 seconds.

CLEANING

To dispose of used ground coffee, remove the filter and the filter holder of the coffee maker. Fig. 24a-b and 25 a-b.
Do not clean the appliance if it is still hot.
Wash the carafe, the removable filter holder and the permanent filter with warm, soapy water. You may place the carafe in the dishwasher.

Do not place the carafe in the microwave.
Do not put other parts of the coffee maker into the dishwasher.

Clean the coffee maker with a damp cloth or sponge. Never use abrasive or strong products on any part of the coffee maker.
To clean the stainless steel parts of your coffee maker, dampen a soft cloth or sponge with warm water. Wipe carefully with a dry cloth.
For difficult stains, use a cloth with white vinegar.
Do not immerse the appliance in water or under the tap.

DESCALING

Why descale
- Limestone forms naturally in your coffee maker. Descaling preserves the coffee maker and ensures it will lastlonger and provide quality coffee over time. Limestone can permanently affect the machine's performance. Malfunctions associated with scaling will not be covered by the warranty if the product is returned.
When to descale
- When descaling is necessary, your machine will tell you and the CLEAN icon will appear on screen.
- How often you need to descale depends on the hardness of the water and the coffee cycle number. Whenyou see the following signs: extended cycle times, high steam, a high noise level at the end of the cycle, stoppage during a cycle, this means your machine is scaled.
- Descaling should be done about once a month, depending on the hardness of the water.

How to descale your KRUPS coffee maker

Remove the filter cartridge. Fig. 26.
Use the KRUPS descaling solution® or 17 fl. oz of white vinegar diluted in 17 fl.oz of cold or water at room temperature or 1.5 oz of citric acid diluted in 17 fl. oz until complete dissolution of crystals. Fig. 27.
Pour the solution into the water tank (without coffee). Fig. 28.
Press the CLEAN button (o) and then the BREW button (k) to start the descaling cycle. Fig. 29.
The cycle lasts for 30 min.
Please wait until the end of the cycle.
If the water tank is not empty, please launch another descaling cycle by pressing CLEAN button.
To rinse the machine, run 2 full 12 cups cycles with water but without coffee. Fig. 30.
Repeat the operation if needed.
Replace the filter cartridge. Fig. 34 and 35.
The warranty does not cover coffee makers that do not work, or do so poorly, due to lack of descaling.

DUO FILTER CARTRIDGE

Your appliance allows you to filter with the DuoFilter filters: double action filter – reduces chlorine and scaling – based on active plant ingredients. This Duo Filter allows you to luxuriate in the most delicate aromas of your coffee and reduces the need to descale.
In its upper part, the filter cartridge support is equipped with an indicator for replacement of the cartridge.
Select the number of the month when you replace the filter. It will display the month when you should change your filter according to water hardness. Fig. 33.
To change the filter, remove the DuoFilter from the tank. Fig. 32.
Open it by unlatching and opening the lower part and replacing it. Fig. 34.

The DuoFilter filter must only be used with water.
Your coffee maker operates even if the water filter is not installed.
If you have not used your coffee machine for over a month, rinse the DuoFilter filter under running water.
It is recommended not to leave the DuoFilter water filter in place for over 5 months.
The duo filter can cause the water to flow slow, excess steam, high noise lever. The filter may need to be replace.

TROUBLESHOOTING

PROBLEM	SOLUTION
The coffee does not brew or the appliance does not turn on.	Make sure the appliance is well connected to a working outlet and that it is in the "ON" position. The water tank is empty. There is a power outage. Unplug the machine, then plug it back in. The clock should be reprogrammed after a power outage. The automatic stop feature has turned off the appliance. Turn off the appliance and then turn it back on to make more coffee. For more information, please consult the "Making Coffee" section.
The appliance seems to leak.	Make sure the water tank has not been filled beyond the maximum limit.
Brewing takes a long time.	It may be time to descale the appliance. Several minerals can accumulate in the coffee maker's circuitry. Regular descaling of the machine is recommended. This may need to be done more often depending on the hardness of your water. For more information, please consult the "Descaling" section. Do not take the appliance apart.
The filter basket overflows or the coffee flows too slowly.	The coffee maker needs cleaning. There is too much coffee. We recommend using one measuring spoon or one soup spoon of ground coffee per cup. The ground coffee is too fine (e.g., ground coffee for espresso won't work in a drip coffee maker). There is ground coffee lodged between the paper filter and the filter holder. The paper filter is not opened properly or is not well placed. Rinse the filter holder before inserting the paper filter so it will adhere to the damp walls of the filter basket. Be sure you have not inserted a paper filter at the same time as the permanent filter. There is more than one paper filter in the filter holder. Make sure the filter basket is pushed down all the way.
The coffee tastes bad.	Clean the coffee maker. The ground coffee is not right for your coffee maker. The proportion of coffee and water is not sufficient. Adjust to suit your taste. The quality and freshness of the coffee is not the best. The water is of poor quality.
The coffee does not flow.	See if there is water in the water tank. The coffee flow system may be obstructed. You may clean it simply by rinsing with water.
The time is not correct (there is a time difference).	The timer is synchronized and depends on your electrical network. If there is a time difference, we recommend that you program the time once a week to be sure it is correct.
