Xylem SI Analytics Lab 865 Quick Start Manual page 6

English
Display
3
2
AutoCal TEC
1
HOLD AR
Info
Jack field /connections
Initial
commissioning
6
01.07.2011
USB output
08:00
1
1 Insert the supplied batteries.
Make sure that the poles are in the correct position.
2 Connect the power pack if necessary.
3 Switch on the meter with the <On/Off> key.
Caution
Follow the safety instructions of the used sensors.
The operating manuals of the sensors are available on the supplied CD and on
the Internet under www.WTW.com.
1
4
2
3
4
5
5
6
6
7
7
8
1
2
3
4
5
6
4
2 3
Status information
Measured value (with unit)
Measured parameter
Continuous measurement control
(CMC function)
Sensor symbol
(calibration evaluation)
Measured temperature (with unit)
Further status information
Softkeys and date/time
pH electrode
Reference electrode
Temperature sensor
USB B interface (device)
Connection for line adaptor
Service interface
