- Page 1 INSTALLATION GUIDELINES GUIDE D’INSTALLATION CAMSO TRACK SYSTEMS FOR ALL-TERRAIN / SIDE-BY-SIDE VEHICLES SYSTÈMES DE CHENILLES CAMSO POUR VÉHICULES TOUT-TERRAIN ET CÔTE À CÔTE ARGO 5000-38-1094-MAN VERSION A...
- Page 2 Track System which will not be covered under normal warranty. TECHNICAL SUPPORT If your dealer or distributor is unable to solve a problem related to the System, you may contact the Camso support team from Monday to Friday.
-
Page 3: Symbols And Signal Words
No matter where or in what conditions, get there and back safely with your Camso track systems. Ready to benefit from optimal traction, mobility, stability, and flotation? Let’s go make tracks! -
Page 4: Parts List
PARTS LIST CAUTION: Before beginning the installation, make sure that you have received all the components included in the parts lists below. ITEM PART # DESCRIPTION 1004-38-0460 FRONT BRACKET KIT ANTI-ROTATION FRONT BRACKET - LH ANTI-ROTATION FRONT BRACKET - RH FRONT BRACKET COVER - LH FRONT BRACKET COVER - RH 1033-10-0055... -
Page 5: Torque Specifications
PREPARATION TORQUE SPECIFICATIONS 1. Set each Track System unit near the position Recommended torque specifications according to indicated by the sticker affixed on the frame. bolt size and grade. GRADE DIMENSION lb-ft M6-1.0 M8-1.25 M10-1.5 M12-1.75 Fig. 2 NOTE: Use a thread locker (Loctite 262 or equivalent) at the specific points of the System indicated in the User Manual’s exploded views. - Page 6 4. Insert bolt in the rear anchor bracket (B1-B2) as 6. Position anchor bracket (B1) under rear suspension shown in Fig. 4 arm. See Fig. 7 Fig. 7 Fig. 4 CAUTION: Make sure that the bolt is inserted in the 7.
- Page 7 9. Secure undercarriage to rear hub using the 11. Verify that spring assembly bolt (7) is tightened to vehicle’s lug nuts. Use bolt circle Ø110 mm. See the recommended torque specification: 75 N•m [55 Fig. 10 lb•ft]. Refer to Fig. 12 CAUTION: If needed, take rubber protector off of hub.
- Page 8 FRONT TRACK SYSTEM 5. Position bottom part of anchor bracket assembly (A1-A2) under lower suspension arm. Position INSTALLATION bracket cover (A3-A4) over suspension arm. Align holes and insert the cover's tenon in the mortise cut 1. Remove front wheels. Make sure that wheel studs in the bottom part.
- Page 9 7. Secure undercarriage to front hub re-using the 9. Verify that spring assembly bolt (6) is tightened to vehicle’s lug nuts. Use bolt circle Ø110 mm. See the recommended torque specification: 75 N•m [55 Fig. 18 lb•ft]. Refer to Fig. 20 CAUTION: If needed, take rubber protector off of hub.
- Page 10 STEERING LIMITER INSTALLATION 12.Attach steering limiter cable assembly under anchor bracket using bolt (C3) inserted through bracket cover, washer (C6), and nut (C7). Tighten nut to 50 10.Assemble steering limiter cables (C2), aluminum N•m [37 lb•ft]. Refer to Fig. 24 disks (C1) and step spacers (C5) together as NOTE: Make sure arrow on top of aluminum disk shown on Fig.
-
Page 11: Final Installation
STEERING LIMITER ADJUSTMENT FINAL INSTALLATION WARNING: Before going to the next steps, 1. Verify the suspension settings. If the shock make sure that stabilizing arms are correctly absorbers are adjustable, adjust them to the stiffest installed, and that the angle of attack and setting to allow for maximum clearance between the alignment are correct. - Page 12 ADJUSTMENTS CAUTION: The Track System is designed to provide best traction performance floatability. Adjustments such as alignment, track tension, and angle of attack are necessary for optimal System performance. more information on these adjustments, refer to the document entitled ADJUSTMENTS or to the USER MANUAL provided with the installation kit specific to the vehicle.
