Caddytek CaddyCruiser ONE V4 User Manual page 4

Package contents:
1. The main frame of the cart
2. Two front wheels and 2 rear wheels.
3. Umbrella holder
4. Basket (pre-installed on the cart)
5. Drink holder
6. This user manual
7. Hangtags on the handle
8. Tools for adjustment
In case any of the above items are missing or damaged, please call 800-906-6918 or email
service caddytek@gmail.com to report.
Parts identification:
A: TPE handle grip
B: Scorecard holder assembly
A
C. Handle frame
D: Upper bag holder bracket assembly
X
E: Adjustable handle mechanism B
F: Main connecting rod
G: Main frame
W
H: Leg bracket
I: 2 holes right leg frame
Z
J: 4 holes leg frame
D
K: 2 holes left leg frame
C
L: Left stabilization bar
E
L1: Right stabilization bar
M: Footbrake assembly
G
N: Left rear wheel holder
F
N1: Right rear wheel holder
O: Holding slot for folded cart frame
S
Q
H
Y1
P: Supporting cable
P
Q: Sub-connecting rods
I
J
R: Front wheel fork assembly
S: Rear wheel assembly
T: Lower bag holder bracket assembly
L1
T
U: Front wheel lock mechanism
M
V: Front wheel assembly
R
N1
W: Umbrella holder base
X: Umbrella holder
O
Y: Basket with cooler
V
Y1: Handle mesh net
U
Z: Drink holder
Z1
Z1: Umbrella holder storage rack
Y
K
