A Carrier Detect
Power
B
A Carrier Detect
Power
B
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.
VT1520WDM
VR1520WDM
LED illuminates
LED illuminates
A
B
A
B
