PART IDENTIFICATION CHART

Use the drawings below to identify small parts used for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see whether
it is preattached. Extra parts may be included.
M4.2 x 19mm
Screw (3)–4
3/8" x 3/4"
Screw (24)–2
M10 x 45mm Screw (2)–4 3/8" x 2 1/4" Screw (1)–2
