AUDIO OUTPUT
(LOWER
CONNECTOR)
NOTE:
FOR AN UNBALANCED CONNECTION, TIE PIN1 TO PIN 2 (UPPER CONNECTOR)
AND UTILIZE PINS 2 AND 3 (UPER CONNECTOR) FOR THE AUDIO INPUT TO
THE VAD7000 SERIES MODULE. UTILIZE PINS 2 AND 3 (LOWER CONNECTOR)
FOR THE AUDIO OUTPUT FROM THE VAD7000 SERIES MODULE.
6
5
4
3 AUDIO OUTPUT
2 AUDIO OUTPUT
1
