04-408 InveterW_Techn_a-p50
Table 1-1 (1-Way Air Discharge Semi-Concealed)
Part Name
Flare insulator
Insulating tape
Vinyl clamp
Hose band
Packing
Drain insulator
Drain hose
Installation gauge
Special washer
Table 1-2 (1-Way Air Discharge Semi-Concealed Slim)
Part Name
Full-scale installation diagram
Special washer
Flare insulator
Insulating tape
Vinyl clamp
Hose band
Packing
Drain insulator
Sealing putty
Cable
Drain hose
12/16/04
3:12 PM
Page 9
Figure
(Black)
(White)
Figure
(Black)
(White)
Q'ty
Remarks
2
For wide and narrow tubes
3
For wide and narrow tubes
2
For wide and narrow tube flare nuts
8
For flare insulator
1
For securing drain hose
1
For drain joint
1
For drain joint
1
For securing drain hose
For measuring clearance between the unit and ceiling
1
8
For suspension bolts
Q'ty
Remarks
1
For determining suspension bolt pitch
8
For temporarily suspending indoor unit from ceiling
2
For wide and narrow tubes
2
For wide and narrow tubes
2
For wide and narrow tube flare nuts
8
For flare insulator
1
For securing drain hose
1
For drain joint
1
For drain joint
For sealing recessed portion of power supply
1
1
Connection cable for fan motor
1
For securing drain hose
9
