I 2-Way Air Discharge Semi-Concealed Type
(CAFM2V Type)
3-9. Suspending the Indoor Unit
(1) Follow the diagrams to make the holes in the ceil-
ing.
A
7, 9, 12, 18
1,020
25
1,320
(2) Depending on the ceiling type:
G
Insert suspension bolts as shown in Fig. 3-36
or
G
Use existing ceiling supports or construct a suitable
support as shown in Fig. 3-37.
WARNING
(3) Cut the ceiling material, if necessary. (Refer to
Figs. 3-34 and 3-35, and Table 3-2.)
12/16/04
3:13 PM
Page 43
Unit: mm
B
C
D
E
920
840
400
440
1,220
1,140
550
590
It is important that you use
extreme care in supporting
the indoor unit from the ceil-
ing. Ensure that the ceiling
is strong enough to support
the weight of the unit.
Before hanging the unit, test
the strength of each
attached suspension bolt.
D
40
C
70
Suspension bolt pitch B
Ceiling opening dimension A
600
110
30
Drain outlet
Refrigerant
connection outlet
(wide tube)
Adjust so that the distance between the indoor unit
and the ceiling bottom is 60 to 65 mm.
Hole-in-anchor
Hole-in-plug
Suspension bolt (M10 or 3/8")
(field supply)
Fig. 3-36
Fig. 3-37
43
Center of panel
and ceiling
opening
E
30
Unit: mm
Unit: mm
70
Refrigerant connection
outlet (narrow tube)
Outlet for power cord,
inter-unit wiring &
optional cord
Concrete
Insert
Ceiling tiles
Ceiling support
CAFM2V
