www.nordictrack.com
USER'S MANUAL
Model No. NTEL09815.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
ACTIVATE YOUR
WARRANTY
To register your product and
activate your warranty today, go
to www.nordictrackservice.com/
registration.
CUSTOMER CARE
For service at any time, go to
www.nordictrackservice.com.
Or call 1-800-TO-BE-FIT
(1-800-862-3348)
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Advertisement
Table of Contents
Related Manuals for ICON Health & Fitness NordicTrack C9.5
Summary of Contents for ICON Health & Fitness NordicTrack C9.5
- Page 1 www.nordictrack.com USER’S MANUAL Model No. NTEL09815.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to www.nordictrackservice.com/ registration. CUSTOMER CARE For service at any time, go to www.nordictrackservice.com.
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. - Page 4 18. The elliptical does not have a freewheel; the 20. Over exercising may result in serious injury pedals will continue to move until the fly- or death. If you feel faint, if you become short wheel stops. Reduce your pedaling speed in of breath, or if you experience pain while a controlled way.
- Page 6 STANDARD SERVICE PLANS...
-
Page 7: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this NORDICTRACK C 9.5 elliptical. The C 9.5 elliptical manual. To help us assist you, note the product model ® provides an impressive selection of features designed number and serial number before contacting us. -
Page 8: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 9: Assembly
ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you fi... - Page 10 3. Press the Cover Mounts (106) on the underside of the Rear Stabilizer Cover (15) into the Rear Stabilizer (2). 4. With the help of a second person, place some of the packing materials (not shown) under the front of the Frame (1). Have the second per- son hold the Frame to prevent it from tipping while you complete this step.
- Page 11 5. Orient the Upright (4) as shown. Have a second person hold the Upright near the Frame (1). Wire See the inset drawing. Locate the wire tie in the lower end of the Upright (4). Tie the wire tie to the Main Wire (110).
- Page 12 7. Using a plastic bag to keep your fingers clean, apply some of the included grease to the Pivot Axle (35) and to two 16mm Wave Washers (54). Insert the Pivot Axle (35) through the Upright (4) and center it. Tip: It may be helpful to use a rubber mallet.
- Page 13 9. Untie and discard the wire tie on the Main Wire (110). While a second person holds the Console (7) near the Upright (4), plug the Main Wire (110) and the Sensor Wires (63) into the receptacles on the Console. The connectors on the Main Wire (110) and the Sensor Wires (63) should slide easily into the receptacles and snap into place.
- Page 14 11. Orient the Right Pedal Arm (58) as shown. Apply grease to the axle on the Right Pedal Arm (58). Attach the Right Pedal Arm (58) to the Right Roller Arm (59) with an M8 x 14mm Shoulder Screw (79), a Small Axle Cover (55), and an M8 Washer (97).
- Page 15 13. Orient the Rear Upright Cover (81) as shown. Attach the Rear Upright Cover (81) to the Upright (4) with four M4 x 16mm Screws (101); start all the Screws, and then tighten them. Next, orient the Front Upright Cover (117) as shown.
- Page 16 15. Identify the Right Leg Inner Cover (83) and orient it as shown. Attach the Right Leg Inner Cover (83) to the Right Upper Body Leg (60) with an M4 x 16mm Screw (101) and an M5 Washer (94). Next, identify the Right Leg Outer Cover (69) and orient it as shown.
- Page 17 17. Attach the Tablet Holder (9) to the Console (7) with four #8 x 12mm Screws (111); start all the Screws, and then tighten them. 18. Make sure that all parts are properly tightened before you use the elliptical. Extra parts may be included. Place a mat beneath the elliptical to protect the floor.
-
Page 18: How To Use The Elliptical
HOW TO USE THE ELLIPTICAL HOW TO PLUG IN THE POWER CORD A temporary adapter may 2-pole Receptacle This product must be grounded. If it should mal- be used to function or break down, grounding provides a path of connect the Adapter least resistance for electric current to reduce the risk power cord... - Page 19 HOW TO MOVE THE ELLIPTICAL HOW TO ADJUST THE POSITIONS OF THE PEDALS Due to the size and weight of the elliptical, moving it requires two persons. Stand in front of the elliptical, Each pedal can be hold the upright, and place one foot against one of the adjusted to several wheels.
- Page 20 HOW TO EXERCISE ON THE ELLIPTICAL To mount the elliptical, hold the handlebars or the upper body arms and step onto the pedal that is in the lower position. Then, step onto the other pedal. Push the pedals until they begin to move with a continuous Upper motion.
- Page 21 CONSOLE DIAGRAM MAKE YOUR FITNESS GOALS A REALITY WITH Upload your workout results to the iFit cloud IFIT.COM and track your accomplishments. With your new iFit-compatible fitness equipment, you can use an array of features on iFit.com to make your Set calorie, time, or distance goals for your fitness goals a reality: workouts.
- Page 22 FEATURES OF THE CONSOLE HOW TO TURN ON THE POWER The advanced console offers an array of features IMPORTANT: If the elliptical has been exposed to cold temperatures, allow it to warm to room tem- designed to make your workouts more effective and perature before you turn on the power.
- Page 23 HOW TO USE THE TOUCH SCREEN 2. Check for firmware updates. The console features a tablet with a full-color touch First, see step 1 on page 30 and step 2 on page screen. The following information will help you become 32 and select the maintenance mode.
- Page 24 HOW TO USE THE MANUAL MODE To vary the motion of the pedals, you can change the incline of the ramp. To change the incline, 1. Touch the screen or press any button on the press one of the numbered 1 Step Ramp buttons console to turn on the console.
- Page 25 5. Measure your heart rate if desired. 6. Turn on the fan if desired. If there are sheets The fan has several speed of plastic on the settings, including an auto Contacts metal contacts mode. While the auto mode on the handgrip is selected, the speed of the heart rate monitor, fan will automatically increase...
- Page 26 HOW TO USE AN ONBOARD WORKOUT 4. Start the workout. 1. Begin pedaling or press any button on the Touch the Start Workout button to start the workout. console to turn on the console. Each workout is divided into segments. One See HOW TO TURN ON THE POWER on resistance level, one ramp incline level, and one page 22.
- Page 27 If the resistance level and/or incline level for the The workout will continue in this way until the last current segment is too high or too low, you can segment ends. A workout summary will appear on manually override the setting by pressing the the screen.
- Page 28 HOW TO USE A SET-A-GOAL WORKOUT manually override the setting by pressing the Resistance buttons or the Ramp buttons. If you 1. Begin pedaling or press any button on the press a Resistance button, you can then manu- console to turn on the console. ally control the resistance (see step 3 on page 24).
- Page 29 HOW TO USE AN IFIT WORKOUT For more information about the iFit workouts, please see www.iFit.com. Note: To use an iFit workout, you must have access to a wireless network (see HOW TO USE THE When you select an iFit workout, the screen will WIRELESS NETWORK MODE on page 33).
- Page 30 HOW TO USE THE EQUIPMENT SETTINGS MODE 6. Turn on or turn off the display demo mode. IMPORTANT: Some of the features described may The console features a display demo mode, not be enabled. Occasionally, a firmware update may designed to be used if the elliptical is displayed cause your console to function slightly differently.
- Page 31 13. Select an update time. Note: If a passcode is enabled, the console will regularly ask for you to enter the passcode. The console will remain locked until the correct pass- To select a time for automatic console updates, code is entered. IMPORTANT: If you forget your touch the Update Time button and select the passcode, enter the following master passcode desired time.
- Page 32 HOW TO USE THE MAINTENANCE MODE 4. Calibrate the incline system. IMPORTANT: Some of the features described may Touch the Calibrate Incline button. Then, touch the not be enabled. Occasionally, a firmware update may Begin button to calibrate the incline system. The cause your console to function slightly differently.
- Page 33 HOW TO USE THE WIRELESS NETWORK MODE name (SSID). If your network has a password, you will also need to know the password. The console features a wireless network mode that allows you to set up a wireless network connection. An information box will ask if you want to connect to the wireless network.
- Page 34 HOW TO USE THE SOUND SYSTEM HOW TO USE THE INTERNET BROWSER To play music or audio books through the console Note: To use the Internet browser, you must have sound system while you exercise, plug a 3.5 mm male access to a wireless network including a wireless to 3.5 mm male audio cable (not included) into the jack router (802.11b/g/n) with SSID broadcast enabled (hid-...
-
Page 35: Fcc Information
FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 36: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE HOW TO ADJUST THE REED SWITCH Regular maintenance is important for optimal If the console does not display correct feedback, the performance and to reduce wear. Inspect and properly reed switch should be adjusted. To adjust the reed switch, first unplug the power cord. - Page 37 HOW TO ADJUST THE DRIVE BELT See EXPLODED DRAWING C on page 43. Identify the Left and Right Shields (73, 74). Remove the If the pedals slip while you are pedaling, even while M4 x 19mm Screws (5) and the M4 x 48mm Screw the resistance is adjusted to the highest level, the drive (107) from the Left and Right Shields.
-
Page 38: Exercise Guidelines
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy. -
Page 39: Part List
PART LIST Model No. NTEL09815.0 R1115A Key No. Qty. Description Key No. Qty. Description Frame Roller Rear Stabilizer Right Pedal Ramp Large Axle Cover Upright 16mm Wave Washer M4 x 19mm Screw Small Axle Cover Front Stabilizer Roller Arm Bushing Console Arm Bearing Roller Guide... - Page 40 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Screw Plastic Spacer M8 Locknut M4 x 19mm Self-tapping Screw M6 x 12mm Screw Boss M10 x 122mm Screw M6 x 110mm Screw M10 Split Washer Tablet Holder Cover Mount Left Pedal Plate M4 x 48mm Screw Left Pedal Handle...
-
Page 41: Exploded Drawing
EXPLODED DRAWING A Model No. NTEL09815.0 R1115A... - Page 42 EXPLODED DRAWING B Model No. NTEL09815.0 R1115A...
- Page 43 EXPLODED DRAWING C Model No. NTEL09815.0 R1115A...
-
Page 44: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
