Model No. NTEL71220-INT.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
CUSTOMER SERVICE
UNITED KINGDOM
Call: 0330 123 1045
From Ireland: 053 92 36102
Website: iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
Unit 4, Westgate Court
Silkwood Park
OSSETT
WF5 9TT
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness, Inc.
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL
iconeurope.com
Advertisement
Table of Contents
Related Manuals for ICON Health & Fitness NordicTrack Commercial 12.9
Summary of Contents for ICON Health & Fitness NordicTrack Commercial 12.9
- Page 1 Model No. NTEL71220-INT.0 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 0330 123 1045 From Ireland: 053 92 36102 Website: iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. Unit 4, Westgate Court Silkwood Park OSSETT...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . .2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your elliptical before using your elliptical. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product. - Page 4 17. The elliptical does not have a freewheel; the 19. Over exercising may result in serious injury pedals will continue to move until the fly- or death. If you feel faint, if you become short wheel stops. Reduce your pedaling speed in of breath, or if you experience pain while a controlled way.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary reading this manual, please see the front cover of this ® NORDICTRACK COMMERCIAL 12.9 elliptical. The manual. To help us assist you, note the product model COMMERCIAL 12.9 elliptical provides an impressive number and serial number before contacting us. -
Page 6: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 7: Assembly
ASSEMBLY • Assembly requires two persons. • In addition to the included tool(s), assembly requires the following tools: • Place all parts in a cleared area and remove the one Phillips screwdriver packing materials. Do not dispose of the packing materials until you fi... - Page 8 3. With the help of a second person, place some of the packing materials (not shown) under the front of the Frame (1). Have the second per- son hold the Frame to prevent it from tipping while you complete this step. If there are shipping supports attached to the front of the Frame (1), remove the screws from the shipping supports, and discard the screws...
- Page 9 5. Orient the Upright (4) as shown. Have a second person hold the Upright near the Frame (1). Locate the wire tie (A) in the lower end of the Upright (4). Tie the wire tie to the Upper Wire (110). Then, pull the upper end of the wire tie until the Upper Wire is routed through the Upright.
- Page 10 7. Apply grease to the axle on the right side of the Upright (4). Next, slide a Pivot Spacer (54) onto the right side of the Upright (4). Grease Then, identify the Right Upper Body Leg (60), orient it as shown, and slide it onto the right side of the Upright (4).
- Page 11 9. Apply grease to one of the Pedal Arm Axles (64). Insert the Pedal Arm Axle (64) into the Right Upper Body Leg (60) and the Right Pedal Arm (58) from the direction shown. Next, slide an M8 x 22mm Washer (129) onto an M8 x 13mm Screw (82), and tighten the Screw a few turns into the Pedal Arm Axle (64).
- Page 12 11. Orient the Rear Console Cover (80) as shown, and attach it to the Upright (4) with two M4 x 16mm Screws (101). Then, orient the Front Console Cover (79) as shown, and attach it to the Rear Console Cover (80) with two M4 x 16mm Screws (101).
- Page 13 14. Identify the Right Upper Body Arm (61), orient it as shown, and insert it into the Right Upper Body Leg (60). Attach the Right Upper Body Arm (61) with two M8 x 45mm Bolts (96) and two M8 Locknuts (102);...
- Page 14 16. Identify the Right Leg Inner Cover (83), orient it as shown, and insert it through the Right Upper Body Leg (60). Next, identify the Right Leg Outer Cover (69), orient it as shown, and press it onto the Right Leg Inner Cover (83).
-
Page 15: How To Plug In The Power Cord
HOW TO PLUG IN THE POWER CORD This product must be earthed. If it should Follow the steps below to plug in the power cord. malfunction or break down, earthing provides a path of least resistance for electric current to reduce the risk 1. -
Page 16: How To Use The Elliptical
HOW TO USE THE ELLIPTICAL HOW TO MOVE THE ELLIPTICAL HOW TO LEVEL THE ELLIPTICAL Due to the size and weight of the elliptical, moving If the elliptical rocks slightly on your floor during use, it requires two persons. Stand in front of the elliptical, turn one or both of the leveling feet (D) beneath hold the upright (A), and place one foot against one the rear stabilizer or turn the leveling foot (E) under... - Page 17 HOW TO EXERCISE ON THE ELLIPTICAL THE OPTIONAL TABLET HOLDER To mount the elliptical, hold the handlebars (G) or the The optional tablet upper body arms (H) and step onto the pedal (I) that is holder (J) will hold in the lower position. Then, step onto the other pedal. your tablet securely Push the pedals until they begin to move with a con- in place and enable...
-
Page 18: How To Use The Console
HOW TO USE THE CONSOLE CONSOLE DIAGRAM FEATURES OF THE CONSOLE When you use the manual mode of the console, you can change the resistance of the pedals and the incline The advanced console offers an array of features of the ramp with the touch of a button. designed to make your workouts more effective and enjoyable. - Page 19 HOW TO TURN ON THE POWER HOW TO USE THE TOUCH SCREEN IMPORTANT: If the elliptical has been exposed to The console features a tablet with a full-color touch cold temperatures, allow it to warm to room tem- screen. The following information will help you use the perature before you turn on the power.
- Page 20 HOW TO SET UP THE CONSOLE Firmware updates are always designed to improve your exercise experience. As a result, Before you use the elliptical for the first time, set up the new settings and features may not be described console. in this manual.
- Page 21 HOW TO USE THE MANUAL MODE Drag upward on the screen to enter the fullscreen display mode. Drag downward on the screen to 1. Touch the screen or press any button on the view the workout information displays. console to turn on the console. Touch the various workout information displays See HOW TO TURN ON THE POWER on to view more options.
- Page 22 6. Turn on the fan if desired. 7. When you are finished exercising, unplug the power cord. The fan has several speed settings, including an auto When you are finished exercising, press the power mode. While the auto mode switch to the off position and unplug the power is selected, the speed of cord.
- Page 23 HOW TO USE A FEATURED WORKOUT OR AN To draw your own map for a workout, see HOW TO ONBOARD WORKOUT CREATE A DRAW-YOUR-OWN-MAP WORKOUT on page 25. 1. Touch the screen or press any button on the console to turn on the console. When you select a workout, the screen will show an overview of the workout that includes details See HOW TO TURN ON THE POWER on...
- Page 24 If the resistance level and/or incline level is too high When the workout ends, a workout summary will or too low, you can manually override the setting appear on the screen. If desired, you can select by pressing the Resistance buttons or the Ramp options such as adding the workout to your sched- buttons.
- Page 25 HOW TO CREATE A DRAW-YOUR-OWN-MAP If you make a mistake, touch Undo in the map WORKOUT options. 1. Touch the screen or press any button on the The screen will display the elevation and distance console to turn on the console. statistics for your workout.
- Page 26 HOW TO USE AN IFIT WORKOUT 4. Select an iFit workout from the home screen or the workout library. To use the console, you must be logged into your iFit account (see step 3 below) and the console Touch the buttons at the bottom of the screen to must be connected to a wireless network (see HOW select either the home screen (Home button) or the TO CONNECT TO A WIRELESS NETWORK on...
- Page 27 6. Create a list of favorite iFit workouts if desired. 9. Wear a compatible heart rate monitor and measure your heart rate if desired. To mark an iFit workout as a favorite, simply view the overview or workout summary of the desired See step 5 on page 21.
- Page 28 HOW TO CHANGE CONSOLE SETTINGS Equipment • Equipment Info Firmware updates are always designed to • Equipment Settings improve your exercise experience. As a result, • Maintenance new settings and features may not be described • Wi-Fi in this manual. Take time to explore the console to learn how new settings and features work.
- Page 29 6. Calibrate the incline system. 3. Enable Wi-Fi. To calibrate the incline system, touch Maintenance, Make sure that Wi-Fi ® is enabled. If it is not touch Calibrate Incline, and then touch Begin. The enabled, touch the Wi-Fi toggle to enable it. ramp will automatically rise to the maximum incline level, lower to the minimum incline level, and then 4.
- Page 30 HOW TO USE THE SOUND SYSTEM Connect Your Headphones If the console has a headphones jack, you can plug Connect with an Audio Cable your headphones into the headphones jack to listen to If the console has an audio jack, you can connect an audio from the console through your headphones.
-
Page 31: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE If the console does not boot up properly, or if the con- Regular maintenance is important for optimal sole freezes and does not performance and to reduce wear. Inspect and respond, reset the console properly tighten all parts each time the elliptical is to the factory default set- used. - Page 32 HOW TO ADJUST THE REED SWITCH Next, slightly loosen the indicated two M4 x 12mm Self-tapping Screws (50). Slide the Reed Switch (38) If the console does not display correct feedback, slightly closer to or away from the Magnet (43), and the reed switch should be adjusted.
- Page 33 HOW TO ADJUST THE DRIVE BELT Next, locate and loosen the If the pedals slip while you are pedaling, even while Idler Screw (89). the resistance is adjusted to the highest level, the drive Tighten the Drive belt may need to be adjusted. To adjust the drive belt, Belt Adjustment first press the power switch to the off position and Screw (91) until...
-
Page 34: Exercise Guidelines
EXERCISE GUIDELINES Aerobic Exercise—If your goal is to strengthen your WARNING: cardiovascular system, you must perform aerobic Before beginning this exercise, which is activity that requires large amounts or any exercise program, consult your physi- of oxygen for prolonged periods of time. For aerobic cian. -
Page 35: Part List
PART LIST Model No. NTEL71220-INT.0 R0421A Key No. Qty. Description Key No. Qty. Description Frame/Ramp Roller Rear Stabilizer Left Pedal Handle Access Cover Axle Cover Upright Pivot Spacer M4 x 19mm Screw Retainer Front Stabilizer Roller Arm Bushing Console Pedal Arm Bearing Roller Guide Right Pedal Arm Crank Bearing Sleeve... - Page 36 Key No. Qty. Description Key No. Qty. Description M4 x 16mm Screw M4 x 16mm Machine Screw M8 Locknut Right Upper Grip M6 x 12mm Screw M4 x 25mm Screw M10 x 115mm Screw Disc Bracket M4 x 25mm Flange Screw Long Bumper Lower Ramp Cover M8 x 22mm Washer...
-
Page 37: Exploded Drawing
EXPLODED DRAWING A Model No. NTEL71220-INT.0 R0421A... - Page 38 EXPLODED DRAWING B Model No. NTEL71220-INT.0 R0421A...
- Page 39 EXPLODED DRAWING C Model No. NTEL71220-INT.0 R0421A...
-
Page 40: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
