DC Epic
Installation Guide
For Model:
DCEP70
WARNING:
DC Motor will not operate
until blades are installed
4009218
APPROVED FOR USE
IN DAMP LOCATIONS
net weight of fan: 17.19 lb (7.8 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Wiring. pg. 7
Warranty. pg. 12
page 1
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCEP70 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Craftmade DCEP70

Summary of Contents for Craftmade DCEP70

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE DC Epic Installation Guide For Model: DCEP70 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 WARNING: Parts Inventory. pg. 3 DC Motor will not operate Installation Preparation. pg. 4 Hanging Bracket Installation.

  • Page 2: Safety Tips

    Distributed by: Craftmade, 3901 South 20th Avenue, DFW Airport, TX, 75261; 1-800-486-4892 NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. Check against parts inventory that all parts have been included.

  • Page 4: Installation Preparation

    3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that the hanging location allows the blades a clearance of inches 7 feet (76cm) 7 feet (2.13m) from the floor and 30in. (76cm) from (2.13m) any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.

  • Page 5: Fan Assembly. Pgs

    5. Fan Assembly. set screw stop pin Remove hanging ball from downrod provided by loosening set screw on hanging ball. Remove pin and clip. Lower hanging ball and remove stop pin. Then hanging ball slide hanging ball off downrod. [Refer to diagram 1.] Remove vice from safety cable by loosening the screw clip and nut on the vice.
  • Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet safety cable loop wood box and able to support the fan, you are now ceiling ready to hang your fan. Grab the fan firmly with joist two hands. Slide downrod through opening in “J”...

  • Page 7: Wiring

    6. Wiring. WARNING: Turn off circuit breakers to current white supply wire ground fixture from breaker panel and be sure operating (green or bare) light switch is turned to the OFF position. black supply wire CAUTION: Be sure outlet box is properly grounded and that a ground wire (GREEN or Bare) is present.

  • Page 8: Canopy Assembly

    7. Canopy Assembly. Remove 2 screws on underside of hanging bracket. hanging bracket Lift canopy to hanging bracket. Align holes in canopy with holes in hanging bracket. While holding canopy in place, slide anti-sway adapter up to canopy. Align holes canopy in anti-sway adapter with holes on underside of canopy and then re-insert the screws that...

  • Page 9: Switch Housing Assembly

    9. Switch Housing Assembly. Locate screws in slotted holes on opposite motor housing sides of switch housing cap and partially loosen screws. Remove other 2 screws--save screws for later use. Remove 1 screw from fitter plate on underside of motor and partially loosen the other 2 screws.

  • Page 10: Automated Learning Process./Activating Code

    10. Automated Learning Process./Activating Code. WALL REMOTE CONTROL CONTROL LED LIGHT FAN OFF LED LIGHT FAN OFF LEARN IMPORTANT: FAN SPEED Remote and wall FAN SPEED controls must be REVERSE REVERSE SYNCHRONIZED with fan in order to LIGHT KIT LEARN properly function.

  • Page 11: Testing Your Fan

    11. Testing Your Fan. It is recommended that you test fan before finalizing installation. Test wall control (optional installation) by locating ON/OFF slider switch on wall control, then set to ON position. Test light ON/OFF and then test fan speeds. Next, locate remote control. Start with the lights OFF and test the light ON/OFF function button.

  • Page 12: Troubleshooting

    WARNING: Failure to disconnect power supply CRAFTMADE LIMITED LIFETIME WARRANTY: prior to troubleshooting any wiring issues may CRAFTMADE warrants this fan for use as intended under result in serious injury. the following provision: CRAFTMADE will replace any fan which has faulty performance due to a defect in material Problem: Fan fails to operate.
