Check connection status and cellular
signal strength
When the IQ System Controller establishes an internet connection,
the IQ Gateway Network Communications LED is solid green. You
can use the Enphase Installer App to check the modem status and
cellular signal strength. The IQ Gateway's AP (Access Point) Wi-Fi
network allows you to connect your mobile device (smartphone or
tablet) to the
IQ Gateway.
1. On the IQ Gateway, the AP Mode LED is solid green when the
AP mode is active. If the AP Mode LED is not lit, press the AP
Mode button.
2. Launch Enphase Installer App and tap connect to IQ Gateway.
3. Tap Network.
4. Under Network Configuration, tap Cellular. The app displays
connection status and an indication of signal strength.
5. Check the connection status and verify that signal strength is
at least two bars for adequate data transmission.
Troubleshooting:
I S S U E
No communication with Enphase App after connecting the Cellular modem
to the IQ Gateway.
I want to disconnect the modem and reuse it at a different site.
IQ System Controller 3 INT Quick Install Guide
LED status:
P O W E R L E D
Off
On
L I N K L E D
Flashing slowly
(200 ms high/1,800 ms low)
Flashing slowly
(1,800 ms high/200 ms low)
Flashing quickly
(125 ms high/125 ms low)
S I G N A L L E D s D E S C R I P T I O N
All OFF
Bar 1 ON
Bar 1 and 2 ON
Bar 1, 2, and 3 ON
A C T I O N
1. Disconnect the USB cable.
2. Reboot the IQ Gateway using the Enphase App or the Enphase
Installer App
3. Wait until the IQ Gateway boots completely.
4. Reconnect the Cellular modem USB cable.
Moving the modem to a different
IQ Gateway deactivates the modem. Contact Enphase Customer
Support if you need to reinstall the modem at a different site.
I N D I C AT E S
DC power via USB not present
DC power via USB present
I N D I C AT E S
Searching for available network
Idle
Data transfer in progress
I N D I C AT E S
Very weak signal
Weak signal
Good signal
Very good signal
