Clear All Stored Learned Commands Under a Mode
Clearing all stored Learned commands under a specific mode allows you to continuously update your
remote with the latest commands. To clear all Learned commands under one mode (e.g., TV, VCR,
DVD, etc.), follow these steps:
1. Press and hold the SETUP key until the touchscreen
shows the Code Setup Mode? Screen. Release the
SETUP key.
2. Press and release the SETUP key repeatedly until the
Delete IR Mode? Screen appears.
3. Press and release the desired component key for
the Learned commands to be cleared (TV, VCR, SAT,
AUX, etc.).
Only the components that have previously
Note:
programmed Learned commands are shown on the
LCD touchscreen.
4. The Confirm to Delete? Screen is displayed. Press and
release the OK key on the touchscreen. The display
shows the Deleting Wait Screen. If there are no other
component modes with Learned commands, the Learn
IR Mode? Screen appears. If there are other component
modes with Learned commands, the Delete IR Mode?
Screen is displayed.
5. All Learned commands that were previously stored
under that mode are now cleared. To exit the Setup
Mode, press and release the EXIT key, followed by the
LCD OK key on the Exit Setup Screen.
Master Clear
This feature allows you to simultaneously delete all Learned commands. Clearing all stored
Learned commands is recommended before first-time Learning.
1. Press and hold the SETUP key until the touchscreen
shows the Code Setup Mode? Screen. Release the
SETUP key.
2. Press and release the SETUP key repeatedly until the
Delete IR All? Screen appears.
3. Press and release the LCD OK key.
Note: If, at this point, you wish to abort the Master
Clear operation, press and release the LCD EXIT key.
4. The Confirm to Delete? Screen is displayed. Press and
release the LCD OK key. The LCD touchscreen displays
the Deleting Wait Screen, followed by the Learn IR
Mode? Screen.
5. All Learned commands are now cleared for all
component modes. To exit the Setup Mode, press and
release the EXIT key, followed by the LCD OK key on
the Exit Setup Screen.
SmartMacros
SmartMacros allow you to program your RCU1010 to perform a series of sequential commands with one
keypress. For example, you can program a SmartMacro to turn on your TV, tune it to a specific channel,
turn on your VCR, and record. A total of 20 Learned commands can be programmed under each of the
nine available LCD Macro keys. If you program all 20 keys into a SmartMacro, the Macro is automatically
stored after the twentieth Learned command is completed. The sequence of commands you want a
SmartMacro to execute must be programmed in correct sequential order. Any sequence of commands
that you regularly perform can be programmed as a SmartMacro and reduced to a single keypress.
Program a SmartMacro
To program a SmartMacro, follow these steps:
1. Gather all your original remotes that contain functions
you would like to add to a SmartMacro.
2. Place the first original remote in the Learning position.
(See section on Learning.) The remotes should be
positioned 2-3 inches apart.
3. Press and hold the SETUP key until the touchscreen
shows the Code Setup Mode? Screen. Release the
SETUP key.
4. Press and release the LCD MACRO Key. The Set
SmartMacro? Screen is displayed.
5. Press and release the LCD OK key.
6 The touchscreen displays the SmartMacro Key? Screen.
Press and release the digit key under which you want
to program the SmartMacro (from 1-9).
7. The touchscreen displays the S-MacroX Learn? Screen.
Press and release the LCD LEARN key.
8. The S-Macro X Learning Screen appears on the
touchscreen. Press and hold the key on the original
remote until the LED indicator light on the RCU1010
blinks once.
Note: If no Learned command is detected, the RCU1010
will timeout after 30 seconds.
9. Release the original remote key.
10. Program additional commands in the order you want
them to be stored in the SmartMacro. To add
commands to the SmartMacro, repeat steps 7-9 above,
using original remotes to program. When finished,
press and release the LCD OK Key. You can program
up to 20 learned commands under one SmartMacro.
11. Once you are finished programming the Macro, press
and release the LCD OK key to confirm and save. The
touchscreen returns to the Set SmartMacro? Screen.
12. The SmartMacro programming is complete. To exit the
Setup Mode, press and release the EXIT key, followed
by the LCD OK key on the Exit Setup Screen.
Note: If the EXIT key does not respond, press and
release the SETUP key repeatedly until the Exit Setup
Screen appears.
Execute a SmartMacro
To execute a SmartMacro that has previously been programmed, follow these steps:
1. Press and release the SETUP key, the BACKLIGHT
key, or any LCD touchscreen key to activate the
LCD touchscreen.
2. Press and release the LCD MACRO key.
3. Press and release the programmed LCD MACRO key
number corresponding to the sequence you wish to activate.
4. If the keypress beep is enabled, you hear a series of
beeps as the Macro executes. The number of beeps you
hear corresponds to the number of Learned commands
within the SmartMacro.
