Please Read

U S E R M A N U A L

www.rovedashcam.com

Smart & Beau�ful

ROVE APP

For

iOS & Android

Table of Contents

Need help?

Do you have a question about the R2-4K PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for ROVE R2-4K PRO

Page 2 EMAIL US help@rovedashcam.com For faster response text us TEXT US 1 (401) 484-ROVE(7683) Scan the QR Code to Email US Scan the QR Code to Text US Just Scan the QR Code with your iPhone or Android’s Camera to get in touch with us.
Page 3 WATCH HOW TO VIDEOS Visit our website www.rovedashcam.com/pages/videos Understanding ROVE R2-4K PRO Watch HOW-TO VIDEOS to learn & understand all the features so you can get the maximum benefit out of it.
Page 4: Table Of Contents
Inser�ng/ Removing Memory Card ............... Forma�ng Memory Card ....................Time-Zone Se�ng ......................... Using WiFi Feature ....................... Pairing your R2-4K PRO with your Smart Phone using WiFi ... Understanding 3 – Camera Modes ................ Playback Your Recorded Videos ................Understanding Camera Se�ngs ................
Page 5: Introduc�On
R2-4K PRO Digital Vehicle Dash Cam (Automobile Black Box). This product provides high-quality image capture and irrefutable evidence for what goes on from the perspective of your dashboard. Rove Dash Cam is a very elegant, convenient, and durable multi-vehicle driving recorder.
Page 6: Features
Remote Firmware Updates using Time Lapse Video iOS/Android ROVE Dash Cam APP 24hr Auto Trigger Parking Mode (ROVE USB Type-C HWK Required - Not Included) 4K Ultra-HD 3840x2160 30FPS 150° Ultra-wide A+ Viewing Angle Loop Cycle and Split Recording Mode...
Page 7: User Agreement
USER AGREEMENT By purchasing the ROVE Dash cam, it is assumed that by default you agree with precautions, user warnings, and all the terms & conditions of warranty. If for any reason you do not agree with any of the terms mentioned in this manual, then you may return the product in its original packaging unused within its return window for a full refund.
Page 8 USER MANUAL became loose and falls off the windshield while driving. Do not expose this device to excessive heat, or dust or use any chemical substance or cleaning solvent to clean this device. Instead use soft moist cloth for cleaning. Pay careful attention when cleaning the lens surface.
Page 9: Ge�Ng Started
Micro-SD card up to 512 GB max for reliable operation. (Memory card is NOT included in the packaging) (We recommend ROVE Ultimate Micro-SD Card up to 512 GB MAX.) Before first time use, you MUST format the memory card in the camera to prevent any errors and for smooth operation.
Page 10 USER MANUAL ROVE R2-4K Pro Car dash cam is programmed to turn ON and START RECORDING automatically when it receives power, and STOPS RECORDING, save the last video file, and turns OFF automatically when power gets disconnected within 1-2 seconds. (i.e., when you start /turn off your car) Setting Date &...
Page 11: Camera Specifica�Ons
CAMERA SPECIFICATIONS Chipset / Sensor NOVATEK 96670 / SONY IMX335 Display 2.4 Inch IPS Lens 150° A+ Ultra HD Wide Angle 4K 3840x2160 @30FPS Video Resolu�on 2K 2560x1440 @30FPS & 60FPS 1080P 1920x1080 @60FPS 1080P 1920x1080 @30FPS Photo Resolu�on VGA, 2MHD, 3M, 4M, 5M, 8M, 10M, 12M Lens Aperture F 1.5 Built-in GPS Geo-Tagging Support...
Page 12: Firmware Update
Firmware updates for R2-4K Pro are provided over the air/remotely using the ROVE Dash Cam APP. To check/Update Firmware: Please connect your R2-4K Pro to the ROVE Dash Cam APP using the WiFi Feature. (See Page 33) Click “Firmware Update” from the left navigation menu while staying connected to R2-4K PRO using WiFi Feature.
Page 13: Package Contents
2.5FT Type-C USB Data Cable Cleaning Pads & Car Wire Trim Tool ROVE Dual USB Car Charger Quick Start Guide User Manual PLEASE NOTE: Memory Card Is NOT Included. We Recommend ROVE Ultimate Class 10, U3 Speed Micro-SD Card, UP to 512GB...
Page 14: Unit Structure Appearance & Bu�Ons
USER MANUAL UNIT STRUCTURE APPEARANCE & BUTTONS Reset Built-In GPS Serial Number Windshield Label Mount Latch TV Out LED Indicator 2.4” IPS Display Rec. On/Oﬀ, OK or Menu/Mode Bu�on Conﬁrm Bu�on Down or LCD UP or Mute on/oﬀ Bu�on on/oﬀ Bu�on Emergency Lock or WiFi on/oﬀ...
Page 15: Shortcuts & Understanding Bu�Ons
SHORTCUTS & UNDERSTANDING BUTTONS BUTTON IMAGE BUTTON NAME SHORTCUTS / FUNCTIONS To Turn ON The Camera: Press power bu�on once. POWER To Turn OFF The Camera: Long press power bu�on for 3-seconds. BUTTON Press once while video is being recorded to take a quick snap shot. Press Once - to enter/exit menu se�ngs MENU / MODE LONG PRESS for 2-Seconds - to Switch Modes...
Page 16: Installa�On
Make sure to clean your windshield from dust particles and evaporated grease from the dashboard surface. Attach the ROVE R2-4K PRO with the suction mount. Set the camera lens to point forward to the center when installing it. NOTE Make sure that the camera’s view is not obstructed by any window �nt or...
Page 17 Use the power cord to connect the USB Port of the product to the car's cigarette lighter socket. CAUTION: Only use ROVE’s USB Car Charger, otherwise the camera may frequently reboot or flicker LCD due to insufficient power. Hide the cable inside the trim and use the included cable clips for additional support to organize the cable if needed so it does not interfere with the driver’s vision.
Page 18 USER MANUAL Adjust the lens angle of the camera. Loosen the screw to adjust the camera’s view/tilt Simply rotate the angle and then tighten camera 360 o to it to lock that angle. record any direction you prefer. Start the engine and check if the product works properly. CAUTION: Make sure to remove the Plastic Lens Screen Protector from the lens before recording videos.
Page 19 Lighter Plug Dash Cam Wiring at a glance Charging Only use the supplied charger to power and charge the Rove R2-4K PRO dash cam. NOTE You can use your iPhone or Android Phone’s USB Charger, and plug into your home’s 110V wall outlet to power/charge the camera while in your home.
Page 20: Turning Your Camera On/Off
USER MANUAL TURNING YOUR CAMERA ON/OFF AUTO POWER ON/OFF Auto Power ON: ROVE R2-4K PRO Dash Cam is designed to turn ON and start recording automatically when it receives power. i.e. when the car engine is started. Auto Power OFF: The camera is also pre-configured to turn itself OFF automatically within a few seconds when the power gets disconnected, i.e.
Page 21: About Supercapacitor
Now, all dash cams must be plugged into the power at all times for continuous recording, regardless of which brand you will purchase. ROVE R2-4K PRO uses a Supercapacitor instead of a small internal battery. Main Beneﬁt The main benefit of using a supercapacitor in a dash cam is that it drastically increases the product’s life span compared to internal...
Page 22 • about 2 seconds. Why Supercapacitor? ROVE R2-4K PRO dash cam uses a supercapacitor, making it a unique, reliable dash cam on power consumption and safety. Moreover, it is more resistant to heat, unlike batteries, and it extends the overall product life span of the camera.
Page 23: Home Screen
HOME SCREEN Recording Status Time Lapse Video Loop Recording Timer Video Mode (Resets every loop) Video Resolution Loop Recording Total Trip Time Wide Dynamic Range (Resets at every restart) Exposure Value Parking Mode Indicator Microphone Indicator G-Sensor Emergency Video Lock Memory Card Indicator Current Time WiFi On/Off Indicator...
Page 24: Led Status Light Indicator
USER MANUAL LED STATUS LIGHT INDICATOR BLINKING LED - Recording Video SOLID LED - Not Recording Video LED - Camera is Turned OFF DIFFERENT SCENARIOS When Camera Is Plugged Into The POWER Solid Camera Idle Blinking Camera Recording Video...
Page 25: Which Memory Card Should I Get
In order to save time, money, and hassle in the long run, we simply recommend our ROVE Ultimate microSDXC Cards. See a few details below to understand why? FAQ ABOUT MEMORY CARDS: WHY SHOULD I GET...
Page 26 That is why, to save time, money, and hassle in the long run, we strongly recommend you to invest in a ROVE Ultimate Micro SD Card.
Page 27 SD Card. At ROVE, we have higher standards. Because in the long run, we all want the camera and memory card to just work without any issues because we need peace of mind, and we have better things to do in life than fight to find a simple memory card.
Page 28: Inser�Ng/ Removing Memory Card
INSERTING / REMOVING A MICRO SD CARD Must use only Brand Name, Class-10, U3, or higher speed Micro-SD Card. Max supports 512GB. We Recommend ROVE Ultimate Class 10, U3 Speed Micro-SD Card. You can purchase it from Amazon here: Search for “ROVE Ultimate Micro SD Card”...
Page 29 If you experience camera FREEZING or LAGGING or STOPS Recording a�er few seconds. Then It is the issue of the MEMORY CARD. (NOT THE CAMERA ISSUE) - Please Contact US. ROVE R2-4K PRO Dash Camera is High Bit-Rate 4K Video recording device. Which requires High Speed Ra�ng SPECIFIC Micro-SD Cards.
Page 30: Forma�Ng Memory Card
USER MANUAL FORMATTING MEMORY CARD Press to STOP video recording first or to clear the error message. If you have any on the screen. Please press the button once to enter the video settings. Press the button again to switch to the System Settings. Format Default Setting Firmware Version...
Page 31: Time-Zone Se�Ng
TIME-ZONE SETTING: To set the date & time, choose one of the following options below: You can choose the date and time of your choice manually, go to System Settings > Date/Time and select the date and time of your choice. You can also set the GMT/UTC time-zone value instead, so the camera will set the date and time based on the GMT/UTC value selection when it receives the GPS signal lock automatically.
Page 32: Using Wifi Feature
It is NOT a cloud or an IP camera and it is NOT meant to do that. You can get live video and footage on ROVE R2-4K PRO’s APP as long as you stay within the 10M range from the dash cam.
Page 33: Pairing Your R2-4K Pro With Your Smart Phone Using Wifi
NOTE ROVE R2-4K PRO's WiFi Connec�on paring does NOT broadcast the internet. The WiFi Connec�on to ROVE R2-4K PRO is meant to transfer the data between your phone and the ROVE R2-4K PRO dash cam. Scan this QR Code download the ROVE Dash Cam APP.
Page 34 USER MANUAL STEP 2: Sign Up (For First Time Users Only), Skip this step if you already have an account. IMPORTANT: Do NOT Connect your iOS/Android device to ROVE R2-4K PRO's WiFi yet. First Time Users FIRST-TIME USERS: You will need to register and create a free account using ROVE APP, so you can keep your videos and data secure on your device.
Page 35 You should see the live video feed from the camera on the main home screen of the ROVE APP. Now you are all set to access your recording from the ROVE app and explore it further.
Page 36 USER MANUAL For Android phones: There is one extra step you will have to take for the ﬁrst �me. Once you connect to ROVE R2-4K PRO WiFi, it will say “No Internet”. Which is ﬁne. Wait about 10-15 seconds un�l you see the below pop up or no�ﬁca�on.
Page 37: Understanding 3 - Camera Modes
UNDERSTANDING 3 – CAMERA MODES ROVE R2-4K PRO has 3 different camera modes: VIDEO MODE PHOTO MODE PLAYBACK MODE TO SWITCH MODE: Press & Hold “M button for 2-seconds. Each Mode has their own separated Menu settings. NOTE System Settings are common between all three Modes.
Page 38 USER MANUAL 2. PHOTO MODE: Photo mode lets you take a snapshot. While in the Photo Mode: Press button to take a snapshot • Press MEbutton to enter Photo Mode’s Menu Settings • Press & Hold “ ” to turn ON/OFF WiFi •...
Page 39: Playback Your Recorded Videos
Playback Your Recorded Videos There are 3 different ways you can access your videos. A. Directly On The CAMERA by switching to the PLAYBACK MODE You can do this by pressing and holding the button for two seconds so it will switch from Video mode to Photo mode.
Page 40 USER MANUAL B. On PC/MAC To play on your PC/Mac, simply connect the camera using included short USB Type C Data cable and choose the Connect as USB Flash Drive on the camera when this message pops up. Connect to PC/MAC Connect as USB Flash Drive Connect as PC/MAC Webcam Operate Camera Normally...
Page 41 Once you find the added flash drive, double-click on it, then you will see the R2-4K PRO folder where you will find your unlocked videos. You will also see a folder named "EVENT" which means read-only,...
Page 42 USER MANUAL Correct Video Player To Play 4K VIDEOS: We recommend VLC Media player. You can get it free at www.videolan.org You can also use our GPS Player from our website for free to view the google maps from www.rovedashcam.com...
Page 43 C. On Smart Phone To play on Smart Phone, simply turn on WiFi first from the camera, then connect the ROVE R2-4K PRO WiFi by entering the defalt password “1 23 456 78 ” Once connected, simply open the correct ROVE APP for your model.
Page 44 USER MANUAL VIDEO SETTINGS SYSTEM SETTINGS...
Page 45: Understanding Camera Se�Ngs
UNDERSTANDING CAMERA SETTINGS Short press Key to enter the setting interface after power on. In this case, the video recording will be stopped and you get the Settings Menu. Attention: To EXIT the Settings Menu, Press the button to go back. VIDEO SETTINGS VIDEO RESOLUTION You can choose the video resolution you like.
Page 46 USER MANUAL LOOP RECORDING This feature allows the camera to continuously record loop by loop so it can delete the oldest video files automatically when the memory card becomes full so you don’t have to manually delete them. This feature will split each video file to an appropriate length based on your selection.
Page 47 VIDEO RECORDING G-SENSOR G-Sensor is a 3-axis impact gravitational accelerometer which is designed to detect physical and gravitational forces on the camera. While Video is Being Recorded: In the event when G-Sensor is triggered due to physical or gravitational impact force on the camera, the current loop cycle length of the video file will be locked so it will NOT be deleted by the normal loop cycle function.
Page 48 USER MANUAL TIME-LAPSE VIDEO Time Lapse recording mode allows you to capture specific images per second at a much lower rate. So when you combine and play those images at the normal 30fps rate, everything seems to be moving faster in time-lapse. •...
Page 49 It needs a step-down circuit in the middle (Hardwire Kit) to adjust the current required by the dash cam. You must connect the dash cam using the ROVE Ul�mate USB Type-C Hardwire Kit and connect it to the car’s fuse box (NOT to ba�ery terminals directly).
Page 50 Hardwiring your dash cam to your car's fuse box is necessary to give power to the dash cam. ROVE Ultimate USB Type-C Hardwire Kit is NOT Included in the packaging. Purchase separately.
Page 51 PARKING MODE WORK? Time-Lapse 1fps & G-Sensor: (See how this feature works) When this feature is set to ON and ROVE Ultimate USB Type-C Hardwire Kit is installed properly. Then, when you turn OFF the car’s engine and turn the key to the lock position.
Page 52 STOP the Continuous Recording from the normal video mode. Then the R2-4K PRO will turn OFF. However, it actively senses any impact while the car is turned OFF. Now, if someone hits your car & if the impact reaches the set "Parking Mode G-Sensor"...
Page 53 PARKING MODE GOT ACTIVATED! The parking mode got activated while you were away. Check the LOCKED Video to see what happened. You will need to tap the OK button on the screen to acknowledge that pop-up. Then you can check and see what happened by going through the last event video.
Page 54 G-SENSOR" PARKING MODE WORK? Motion Detection & G-Sensor: (See how this feature works) When this feature is set to ON and ROVE Ultimate USB Type-C Hardwire Kit is installed properly. Then, when you turn OFF the car’s engine and turn the key to the lock position.
Page 55 WHAT LEVEL SHOULD I SET MY "PARKING MODE G-SENSOR" SETTING AT? ANSWER This depends on your various factors and your personal preference. We will discuss a few most common scenarios to educate yourself. For the Parking Mode G-Sensor setting, you can select between 1 to 9 different Gravitational Sensor (G-Sensor) levels.
Page 56 Even the lowest vibration, such as hard tapping the LCD or Closing the Car's Door, will activate the R2-4K Pro dash cam. You would want this if you want your dash cam activated with the slightest hit to the car.
Page 57 RECORD AUDIO Rove r2-4k-- has a built-in microphone to record audio with video. You can choose to record mute video by choosing OFF. You can also press the UP button to mute/un-mute while the video is being recorded. • •...
Page 58 USER MANUAL HIDE STATUS ICON This feature allows you to hide all icons on the LCD screen of the camera so you can have a full view of the image. OFF (Default) 1-minute 3-minutes 5-minutes LIVE SPEED & COMPASS This feature allows you to see LIVE SPEED & COMPASS Direction on the HOME SCREEN.
Page 59: Photo Se�Ngs
PHOTO SETTINGS To Enter Photo Se�ng Press & Hold "M"button to enter Photo Mode. Press " button ONCE to enter Photo Settings. Press "D" button to access photo settings. Now use " " "D" buttons to scroll through > then press "0K"...
Page 60 USER MANUAL IMAGE QUALITY This feature allows you to set the quality level of an image captured. Higher the image quality more space it will take on the memory card. • Fine (Default) Standard • Commonly • IMAGE SHARPNESS This feature allows you to choose the clarity of an image’s sharpness. •...
Page 61 This feature allows you to set the camera’s sensitivity to light when taking photos. The higher the setting value the greater the sensitivity. • Auto (Default) • 100 • 200 • EXPOSURE This feature allows you to adjust the brightness of a captured image. •...
Page 62: Playback Se�Ngs
USER MANUAL PLAYBACK SETTINGS To Enter Playback Se�ng 1. Press & Hold "M" button two times to enter Playback Mode. 2. Press "M" button ONCE to enter Play Settings. 3. Press "D" button to access Play settings. 4. Now use "U"...
Page 63: System Se�Ngs
SYSTEM SETTINGS WIFI This feature will allow you to turn the WiFi broadcast ON from the camera so you can connect your phone with ROVE R2-4K PRO Dash Cam to access videos, photos, and settings. • ON - Once (WiFi will turn off at restart) •...
Page 64 USER MANUAL FORMAT SD CARD This feature will allow you to format an inserted memory card, all the data will be deleted. Cancel • Format • DATE / TIME Here you can choose the date and time of your choice manually. NOTE The GPS Time Zone will be automa�cally set to OFF if you manually set the date and �me.
Page 65 SCREEN SAVER Live Video Always ON: This will keep the video LCD ON all the time. Screen Saver ON After 1-Min: This will turn ON the screen saver as shown in the photo below after 1-min if NO button is pressed. LCD OFF After 1-Min: This will only turn OFF the LCD after 1-min if NO button is pressed (NOTE only the LCD Will turn OFF, the camera still be operational)
Page 66 • CAUTION: ROVE R2-4K Pro has an important failsafe voice feedback if the camera is not recording the video when it is turned ON and si�ng idle. Therefore the camera will remind you every 30 seconds that it is NOT recording the video.
Page 67 BOOT UP TONE This feature allows you to choose the camera's boot-up chime to be set to ON/OFF. • ON (Default) • TV MODE Here you can choose your TV mode based on your country’s TV setting. NTSC (Default) • •...
Page 68 You will need this information in the future to check if a newer version of firmware is available. Please visit: For the latest firmware www.rovedashcam.com upgrade instructions. Firmware updates are provided for R2-4K PRO using iOS or Android APP. (See page 12) ROVE-R2-4K-PRO-04-01-2023 (First - Original Firmware) •...
Page 69: Rese�Ng The Camera
LEGAL Copyright 2023, All rights are reserved by ROVE. FCC ID: 2A3IW-R24KPRO This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions. This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
Page 70: Gps Player Installa�On
USER MANUAL GPS player Software Installation (PC/MAC Only) (Only suitable for the units with GPS function) To download FREE GPS Player, visit www.rovedashcam.com Why GPS Player? What are the features? Check G-Sensor data Play back your recorded videos To see the Exact GPS route with the video on google maps Check driving speed Check driving direction (i.e.
Page 71 Date & Time Shows Date & Time of video was recorded Past Viewed Files These are you previously viewed ﬁles. Click on to view them again. Driving Speed This is where your driving speed will be displayed. Playback Controls Reverse •...
Page 72: One Year Limited Warranty
USER MANUAL ONE-YEAR LIMITED WARRANTY We at would like to provide One (1) full year of limited warranty for your product from the date of purchase to be free from defects in materials and craftsmanship. IMPORTANT: Please save your warranty/serial number card as a piece of evidence.
Page 73 lieu of repairs will be calculated based on company's prevailing depreciation rules and the same will be binding on the purchaser. The replacement unit will be either new or refurbished based on the availability. We reserve the right to even upgrade you to the newest version be it similar or not if we have discontinued the current model.
Page 74: Safety & Legal Aspects
Dash Cam must be placed at proper location so • it does not obstruct your view while driving. Do not use or manipulate any functions or any accessories of ROVE • Dash Cam while driving. Distraction is a leading cause of accidents.
Page 75: Troubleshoo�Ng Your Rove R2-4K Pro
Please trust us. We have sold thousands of ROVE Dash Camera’s and they do NOT lag, we stand by our prduct and we do extensive tes�ng. Some customers simply thinks the camera is bad or not stable, but that is NOT the case here.
Page 76 If s�ll having issue, please reach out to customer care. My oldest video ﬁles are missing Your ROVE Dash Cam has Loop Cycle Recording. When it is set to either 1, 3, 5 or 10-mins, it will delete oldest ﬁles and record newer ﬁles over and over when the memory card is full.
Page 77 Camera showing "Memory Error" or "Please Insert Micro SD Card" even though memory card is already installed into the camera. Please make sure memory card is at least Class 10, U3 and purchased from trusted vendor such as Walmart, target, best buy, Ship & Sold by Amazon" etc. (there are many fake cards out there Online, remember if it's cheap, its fake.) Now go to camera's system se�ngs and FORMAT your memory card.
Page 78: A Big Thank You
USER MANUAL A BIG THANK YOU!! Thank you for purchasing your new Dash Cam. We hope you find your new dash cam useful and fun to use. If you are having difficulties setting it up, please email us at help@rovedashcam.com. 99% of all setup problems can easily be resolved and should be able to get you up and running in no time.
Page 79 QUESTIONS QUESTIONS QUESTIONS CUSTOMER SERVICE: For faster response text us Response in just 6 hours 1 (401) 484-ROVE(7683) help@rovedashcam.com HOURS Mon - Fri 9am-5pm PST Scan the QR Code to CONTACT US Scan to Text US: Scan to Email US: 1-401-484-7683 help@rovedashcam.com...
