3G-SDI Fiber Extender
Extend high-quality 3G-SDI video
up to 10 kilometers (6.2 mi.)
over secure single-mode fiber.
Customer
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S.
Support
call 724-746-5500) • FREE technical support 24 hours a day, 7 days
Information
a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address:
Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
Web site: www.blackbox.com • E-mail: info@blackbox.com
VX-SDI-FO-10KM
BLACK BOX
®
Advertisement
Table of Contents
Related Manuals for Black Box VX-SDI-FO-10KM
Summary of Contents for Black Box VX-SDI-FO-10KM
- Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. Support call 724-746-5500) • FREE technical support 24 hours a day, 7 days Information a week: Call 724-746-5500 or fax 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
- Page 2 Trademarks Used in this Manual Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. UL is a registered trademark of Underwriters Laboratories. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
- Page 3 FCC and IC RFI Statements/NOM Statement FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference...
- Page 4 NOM Statement 5. El aparato eléctrico no deberá ser usado cerca del agua — por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc. 6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
- Page 5 NOM Statement 17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación. 18. Servicio por personal calificado deberá ser provisto cuando: A: El cable de poder o el contacto ha sido dañado; u B: Objectos han caído o líquido ha sido derramado dentro del aparato;...
-
Page 6: Table Of Contents
1. Specifications ....................7 2. Overview ....................8 Introduction ..................8 Features ....................8 What’s Included ..................9 Hardware Description .................9 2.4.1 Transmitter ................9 2.4.2 Receiver .................10 3. Typical Installation ..................12 Appendix. Troubleshooting ................13 Contacting Black Box................13 Shipping and Packaging ..............13 724-746-5500 | blackbox.com Page 6... -
Page 7: Specifications
Chapter 1: Specifications 1. Specifications Auto Reclocker Mode — Automatic detection: 270 Mbps/1.483 Gbps/ 1.485 Gbps/2.97 Gbps/2.967 Gbps; Automatic bypass: 177 Mbps/360 Mbps/540 Mbps<BR> Cable Equalization — On coax connections: SD-SDI: 300 m (1000 ft.); HD-SDI: 150 m (500 ft.); 3G-SDI: 90 m (295 ft.) Data Rates —... -
Page 8: Overview
Chapter 2: Overview 2. Overview 2.1 Introduction The 3G SDI Fiber Extender transmits multirate SDI video, with embedded audio and metadata, as far as 10 kilometers (6.2 mi.) over single-mode fiber. The transmitter module receives one 3G/HD/SDI electrical input, and converts a SMPTE 292M, SMPTE424M, or DVB-ASI electrical SDI signal to single-mode fiber optic SDI signals. -
Page 9: What's Included
Chapter 2: Overview 2.3 What’s Included Your package should include the folllowing items. If anything is missing or damaged, contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. • (1) Transmitter • (1) Receiver • (1) single-mode simplex transmit SFP module (mounted in Transmitter) •... -
Page 10: Receiver
Chapter 2: Overview Table 2-1. Transmitter components. Number Component Description (1) BNC connector 3G/HD/SD–SDI input Power LED lights when power is active on 3G/HD/SD–SDI output connector (1) Power LED (1) Signal LED Signal LED lights when a signal is present on the 3G/HD/SD–SDI output connector Connects to a 5-VDC power +5 VDC power connector... - Page 11 Chapter 2: Overview Table 2-2. Receiver components. Number Component Description (1) BNC connector 3G/HD/SD–SDI output Power LED lights when power is active on 3G/HD/SD–SDI input (1) Power LED connector (1) Signal LED Signal LED lights when a signal is present on the 3G/HD/SD–SDI input connector Connects to a 5-VDC power +5 VDC power connector...
-
Page 12: Typical Installation
Chapter 3: Typical Installation 3. Typical Installation Broadcast Coax cable equipment SDI Transmitter Flat-panel display SDI Receiver Fiber cable Coax cable (up to 6.2 mi. [10 km]) Figure 3-1. Sample application. 724-746-5500 | blackbox.com Page 12... -
Page 13: Appendix. Troubleshooting
• Package it carefully. We recommend that you use the original container. • If you are returning the unit, make sure you include everything you received with it. Before you ship for return or repair, contact Black Box to get a Return Authorization (RA) number. - Page 14 NOTES 724-746-5500 | blackbox.com Page 14...
- Page 15 NOTES 724-746-5500 | blackbox.com Page 15...
- Page 16 Great tech support is just 30 seconds away at 724-746-5500 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.
