Extended Range HDMI and IR Extender
Use a single CAT5e/6 cable run to extend
uncompressed HD video, audio, and control
signals up to 328 feet (100 m).
• Supports IR extension and CEC passthrough.
• Enables you to control source devices at the screen.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
Customer
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax
Support
724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence,
Information
PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com
BLACK BOX
VX-HDMI-TP-100M
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Box VX-HDMI-TP-100M
Summary of Contents for Black Box VX-HDMI-TP-100M
-
Page 1: Black Box
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax Support 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, Information PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com... - Page 2 FCC and IC RFI Statements FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference...
- Page 3 NOM Statement 4. Todas las instrucciones de operación y uso deben ser seguidas. 5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc. 6.
- Page 4 NOM Statement 16. El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo. 17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de ventilación. 18.
-
Page 5: Trademarks Used In This Manual
Trademarks Used in this Manual Trademarks Used in this Manual Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Dolby Digital and Dolby True HD are registered trademarks of Dolby Laboratories. DTS Digital and DTS-HD are registered trademarks of DTS, Inc. -
Page 6: Table Of Contents
Introduction ..................8 Features ...................8 What’s Included ................8 Hardware Description ..............9 2.4.1 Transmitter ................9 2.4.2 Receiver ................10 Connection and Operation ............... 12 Appendix. Troubleshooting ................13 Contacting Black Box ..............13 Shipping and Packaging ..............13 Page 6 724-746-5500 | blackbox.com... -
Page 7: Specifications
Chapter 1: Specifications 1. Specifications Approvals — Converter Unit: FCC Power Supply: UL , FCC ® Input Video Signal — 1.2 volts p-p Operating Frequency — Video Amplifier Bandwidth: 3.4 Gbps/340 MHz, Vertical Frequency Range: 50/60 Hz Output Video — HDMI *Transmission Distance —... -
Page 8: Overview
• CAT5e/6 cable should conform to the IEEE-568B standard. 2.3 What’s Included Your package should contain the following items. If anything is missing or damaged, contact Black Box Technical Support at 724-746-5500 or info@blackbox.com. • Transmitter unit • Receiver unit •... -
Page 9: Hardware Description
Chapter 2: Overview • (4) wallmount brackets with (8) screws • This user’s manual 2.4 Hardware Description 2.4.1 Transmitter Figures 2-1 and 2-2 show the front and back panels of the transmitter unit. Table 2-1 describes its components. 2 3 4 Figure 2-1. -
Page 10: Receiver
Chapter 2: Overview Table 2-1. Transmitter’s components. Number Component Description Barrel connector Links to 5-VDC power supply Power LED Lights when the unit is receiving power. When this LED is ”ON,” an HDBASE-T link connection is Link LED established between the transmitter and the receiver over the CAT5e/6 cable. - Page 11 Chapter 2: Overview Figure 2-4. Receiver’s back panel. Table 2-2. Receiver’s components. Number Component Description Barrel connector Links to 5-VDC power supply Power LED Lights when the unit is receiving power. When this LED is ”ON,” an HDBASE-T link connection is Link LED established between the transmitter and the receiver over the CAT5e/6 cable.
-
Page 12: Connection And Operation
328 ft. (100 m) CAT5e/6 cable External infrared External infrared receiver emitter Extended Range HDMI and IR Extender Transmitter unit HDMI cable (VX-HDMI-TP-100M) HDTV HDMI cable Extended Range HDMI and IR Extender HDMI source Receiver unit (VX-HDMI-TP-100M) Figure 3-1. Connection diagram. Page 12... -
Page 13: Appendix. Troubleshooting
• Package it carefully. We recommend that you use the original container. • If you are returning the unit, make sure you include everything you received with it. Before you ship for return or repair, contact Black Box to get a Return Authorization (RA) number. - Page 14 NOTES Page 14 724-746-5500 | blackbox.com...
- Page 15 NOTES Page 15 724-746-5500 | blackbox.com...
- Page 16 724-746-5500 or blackbox.com. About Black Box Black Box provides an extensive range of networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.
