- Page 1 Installation Operation Maintenance PF-H-1 HALF SIZE PROOFER Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203 Part Number 1-800-224-5264...
-
Page 2: Table Of Contents
ELECTRICAL CONNECTION ...........................4 OPERATION ..............................5 CONTROLS .................................5 STARTUP................................5 PROOFING GENERAL ............................5 PROOFING SPECIFICS ............................6 HOLDING CABINET ............................6 MAINTENANCE..............................7 CLEANING ................................7 PARTS LIST ...............................8 WIRING DIAGRAM............................10 WARRANTY ..............................11 Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203 Part Number 1-800-224-5264... -
Page 3: Installation
15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier. -
Page 4: Electrical Connection
ELECTRICAL CONNECTION WARNING ELECTRICAL GROUNDING INSTRUCTIONS THIS APPLIANCE IS EQUIPPED WITH A 3-PRONG (GROUNDING) PLUG FOR YOUR PROTECTION AGAINST SHOCK HAZARD AND MUST BE PLUGGED DIRECTLY INTO A PROPERLY GROUNDED 3-PRONG RECEPTACLE. DO NOT CUT OR REMOVE THIS GROUNDING PRONG FROM THE PLUG. 120 Volt Models: The electrical connection must be made in accordance with local codes or in the absence of local codes with NFPA No. -
Page 5: Operation
OPERATION LANG CONTROLS The controls on your proofer are simple and easy to operate. Indicator Lamp Glows when power Switch is turned on. Power Switch Press UP to turn the unit On, press DOWN to turn the unit Off. Temperature Control Dial The six temperature ranges for proofing are 80 deg. -
Page 6: Proofing Specifics
PROOFING SPECIFICS There are many variables involved in the baking process. It is difficult to assign proofing times, temperatures, and humidity levels. Here are some genereal guide lines that may be helpful. 1. Temperature, age and volume of dough should be the same to obtain similar results (keep accurate records). -
Page 7: Maintenance
UNPLUG THE PROOFER BEFORE CLEANING To provide the proper atmosphere for proofing or holding Lang has designed a sealed cabinet. A characteristic of the unit is an accumulation of water on the bottom of the cabinet. This accumulation should be removed daily. -
Page 8: Parts List
PARTS LIST Bearing Bronz - For Lower Door Pin 50800-72 Casters, Swivel 72901-01 Casters, Non-Swivel 72900-01 Circuit Board, Temperature Control 40101-16 Contactor 2 Pole 24 Volt AC 30701-04 Cord, Power 120 Volt 31106-04 Cord Cap, NEMA #6-15P 240 Volt 31203-20 Diagram, Wiring 61124-06 Door Assembly, Proofer... - Page 9 PARTS LIST Plug, Power Cord 31203-03 Spring, Left Hand Door 51001-25 Spring, Right Hand Door 51001-26 Strain Relief, Power Cord 70801-20 Switch, Toggle, On-Off 30303-08 Switch, Temperature Control 30304-26 Terminal Block, 24 Pole 30503-01 Timer, Mechanical Long Ring 30801-01 Thermostat, Proofing Temperature 30402-30 Thermostat, Over-Temperature 30401-20...
-
Page 10: Wiring Diagram
WIRING DIAGRAM... -
Page 11: Warranty
Lang Equipment. This warranty does not cover and subject to the following limitations. defects caused by improper installation, abuse, careless operation, or improper maintenance of equipment. I. This parts and labor warranty is limited to Lang Equipment sold original commercial V.
