- Page 1 Dust Deputy D.I.Y. Dust Deputy D.I.Y. SD Dust Deputy Plus Cyclone Separator # AXD001004 # AXD001004SD # AXD050004 Patents: www.oneida-air.com/patents Appearance may vary slightly Rev: B 20221214LL Doc. # ZBM000036DIYA...
-
Page 2: System Start-Up Information
8. Can be used for collecting non-flammable liquids. 9. Dispose of waste in a FIRE SAFE AREA. SOME DUSTS ARE HIGHLY FLAMMABLE OR Ÿ EXPLOSIVE. LEARN/ KNOW WHAT YOU ARE DEALING WITH. FOLLOW ALL LOCAL, STATE, FEDERAL & NFPA CODES AND GUIDE LINES. Oneida Air Systems... - Page 3 System Dimensions Nominal dimensions shown. Dimensions subject to slight variations in manufacturing. 6-3/4" 171 mm 8" 203 mm 2" O.D. 1-7/8" I.D. 51 mm O.D. 48 mm I.D. 13-1/4" 2" O.D. 337 mm 1-7/8" I.D. 51 mm O.D. 48 mm I.D. 9-5/8"...
- Page 4 You will need the following: • Air tight dust container and lid • Hole Saw or reciprocating saw • Power Drill • Wet/Dry Vacuum • 5/16" Drill Bit • Vacuum Hose • 7/16" Open End Wrench • Vacuum hose adapters Oneida Air Systems...
- Page 5 System Contents (Cont.) oneida-air.com...
- Page 6 Gasket (B) and align all the holes. Secure Cyclone (A), Gasket (B) and lid together using six Bolts (C1), six Washers (C2), and six Whiz-Lock Nuts (C3) as shown in [FIG. 2]. Note: Thoroughly tighten hardware to eliminate air leaks. FIG. 2 Oneida Air Systems...
- Page 7 Assembly Instructions (Cont.) Turn the Cyclone (A) upside-down. Place Gasket (B) on the base of the Cyclone and align all the holes. Place the topside of the Lid (H) against the Gasket and align all the holes. Secure Cyclone, Gasket and Lid together using six Bolts (C1), six Washers (C2), and six Whiz-Lock Nuts (C3) as shown in [FIG.
- Page 8 The larger the container, the sturdier the walls must be to prevent collapse. Oneida Air Systems has many container options available at oneida-air.com. If you purchased the Dust Deputy Plus, when emptying the Bucket, lift up on latch and pull up on the lid to release the cyclone assembly from the Bucket.
- Page 9 Assembly Instructions (Cont.) If you purchased the Dust Deputy Plus (#AXD050004), continue to step 6. Connect the Cyclone's (A) inlet (sideways facing port) to your dust producing tool with your vacuum's hose or ductwork. Connect Cyclone's outlet (upwards facing port) to your vacuum [FIG.
- Page 10 Note: If your vacuum hose is not tight on the inlet or it keeps pulling off use the Clamp Band (F) and/or the two O-Rings (G) [FIG. 6b] [FIG. 6c]. To wet/dry vacuum To Tool FIG. 6a FIG. 6b FIG. 6c Oneida Air Systems...
- Page 11 Assembly Instructions (Cont.) Make sure there are no air leaks at the connections. Review [FIG. 7] for common leak points. Note: Any air leak in the lid or drum will affect separation performance. Make sure to check your dust drum frequently so you do not overfill it.
- Page 12 To Tools Same particle efficiency but increases the CFM. Top View 200 CFM 100 CFM 100 CFM Multiple Vacuums More CFM/airflow to larger tools such as Table Saw, Jointer, and Planer. To Tools Top View 2 or More Oneida Air Systems...
- Page 13 Additional D.I.Y. Ideas You are only limited by your imagination. The lid must be sealed and the container must stand up to your vacuum's suction pressure without collapsing. Examples of DIY setups An example of a plywood top that had a groove routed out of it to fit the bucket rim and accommodate the gasket.
- Page 14 1.5" x 6.5' Dust Extraction Hose Whip #AHE000001 • This highly flexible vacuum hose fits onto the dust collection ports of common portable power tools. Includes 2.5" rotating swivel cuff. Oneida Air Systems...
- Page 15 Accessories 2.5" x 5.5 Wire Reinforced Vacuum Hose #AXD250066 • Crush-resistant, flexible hose with a smooth- wall inner lining that minimize air resistance. 1.25" x 1.5" Hose Adapter Kit #AKD000000 • Includes reducers, adapters, and O-rings for connecting smaller vacuum hoses to standard 2"...
-
Page 16: Troubleshooting
2. Use a hose clamp. 3. Wrap the inlet and outlet of the Dust Deputy with a layer of electrical tape to increase the friction fit. 4. Secure hose with a sheet metal screw. Oneida Air Systems... -
Page 17: Warranty Information
Limited Warranty – Activate online at oneida-air.com/warranty Oneida Air Systems®, Inc. (OAS) warrants the Dust Deputy for a period of 1 year, to the original purchaser from the date of purchase, unless otherwise specified. Items not manufactured by Oneida Air Systems are limited to their own manufacturer’s warranties. All electrical items such as magnetic starters, remotes, sensors, pumps, bin sensors, bag grippers, etc. - Page 18 LID MOUNTING TEMPLATE Dust Deputy Template FOR STANDARD 14" TALL DUST DEPUTY CYCLONES Use this template to prepare your lid for installation of the Dust Deputy. 1:1 SCALE. DO NOT ALTER DOCUMENT SIZE WHEN PRINTING Oneida Air Systems...
- Page 19 oneida-air.com...
- Page 20 Regardless of where you purchased your Oneida Air Systems' product, if you have any questions or issues with missing / damaged parts, please call Oneida Air Systems first to let us help resolve your problem. We fully stand behind the quality of our products and place the utmost value on the satisfaction of our customers.
