Summary of Contents for Vestfrost CNF 201 X

  • Page 1 NO FROST COMBI REFRIGERATOR Freezer - Fridge User manual КОМБІ-ХОЛОДИЛЬНИК NO FROST Інструкція користувача CNF 201 X CNF 201 DX CNF 201 WB...
  • Page 3: Table Of Contents

    Index BEFORE USING THE APPLIANCE ......... 4 General warnings..............4 Old and out-of-order fridges............8 Safety warnings ................ 8 Installing and operating your fridge........... 9 Before Using your Fridge ............10 Information about New Generation Cooling Technology ..11 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ............
  • Page 4 BEFORE CALLING YOUR AFTER SALES SERVICE ... 29 TIPS FOR SAVING ENERGY .......... 32...
  • Page 5: Before Using The Appliance

    BEFORE USING THE APPLIANCE General warnings WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 6 BEFORE USING THE APPLIANCE the cooler) you should take care during transportation and installation to prevent the cooler elements from being damaged. R600a is an environmentally friendly and natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your and ventilate the room where the appliance is located for a few minutes.
  • Page 7 BEFORE USING THE APPLIANCE specially grounded socket of 16 amperes. If there is no such socket in your house, please have one installed by an authorised electrician. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given...
  • Page 8 BEFORE USING THE APPLIANCE If the supply cord is damaged, it must be replaced by the manufacturer, an authorised order to avoid a hazard. This appliance is not intended for use at altitudes exceeding 2000 m. To avoid contamination of food, please respect the following instructions: Opening the door for long periods can cause the compartments of the appliance.
  • Page 9: Old And Out-Of-Order Fridges

    BEFORE USING THE APPLIANCE Old and out-of-order fridges If your old fridge has a lock, break or remove the lock before discarding it, because children may get trapped inside it and may cause an accident. Old fridges and freezers may contain isolation material and refrigerant with CFC or HFC.
  • Page 10: Installing And Operating Your Fridge

    BEFORE USING THE APPLIANCE This appliance is designed for use by adults, do not allow children to play with the appliance or let them hang off the door. Never touch the power cord/plug with wet hands as this could cause a short circuit or electric shock. Do not place glass bottles or beverage cans in the ice- making compartment as they can burst as the contents freeze.
  • Page 11: Before Using Your Fridge

    BEFORE USING THE APPLIANCE When your fridge is placed next to a deep freezer, there should be at least 2 cm between them to prevent humidity forming on the outer surface. Do not place anything on your fridge, and install your fridge in a suitable place so that at least 15 cm of free space is available above it.
  • Page 12: Information About New Generation Cooling Technology

    BEFORE USING THE APPLIANCE Information about New Generation Cooling Technology Fridges with new generation cooling technology have a different working system than static fridges. In normal fridges, humid air that enters into fridge and the water vapor that comes out from the foods, accumulates frost formation in freezer compartment.
  • Page 13: The Parts Of The Appliance And The Compartments

    THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS This presentation is only for information about the parts of the appliance. Parts may vary according to the appliance model.
  • Page 14 THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS A) Fridge compartment B) Freezer compartment 1) Fridge shelves 2) Wine rack * 3) Interior display / In room control 4) Chiller * 5) Crisper cover 6) Crisper 7) Freezer top basket 8) Freezer middle basket 9) Freezer bottom basket 10) Leveling feet...
  • Page 15: The Various Function And Possibilities

    THE VARIOUS FUNCTION AND POSSIBILITIES Display and control panel Thermostat set level indicator 8 6 5 4 2 It is Economy mode It is Super cool mode indicator. indicator. Set button Button LED Operating your fridge Cooler temperature settings Initial temperature value for Cooler Setting Indicator is 6 Press set button once, the set value will start to blink.
  • Page 16: Super Cool Mode

    THE VARIOUS FUNCTION AND POSSIBILITIES Super cool mode How would it be used? Press set button until super cool symbol will be seen on the screen. Buzzer will sound beep beep. Mode will be set. During this mode: Economy mode can not be selected. Super cool mode can be cancelled by the same operation of selecting.
  • Page 17: Accessories

    THE VARIOUS FUNCTION AND POSSIBILITIES This appliance is designed Climate Class Ambient Temperature for use at an ambient temperature within the Between 16 and 43 (°C) 10°C - 43°C range. Between 16 and 38 (°C) Between 16 and 32 (°C) Between 10 and 32 (°C) Important installation instructions C or 110 degrees F) and is powered with ‘Freezer Shield’...
  • Page 18: Chiller Shelf

    THE VARIOUS FUNCTION AND POSSIBILITIES Chiller Shelf (In some models) Keeping food in the Chiller compartment instead of the freezer or refrigerator compartment allows preserving its fresh appearance. When chiller tray becomes dirty, remove it and wash it with water. (Water freezes at 0°C, but foods containing salt or sugar freeze at temperature lower than that) Normally people use the chiller compartment for...
  • Page 19: Adjustable Door Shelf

    THE VARIOUS FUNCTION AND POSSIBILITIES Adjustable Door Shelf (In some models) Six different height adjustments can be made to provide storage areas that you need by adjustable door shelf. To change the position of adjustable door shelf ; Hold the bottom of the shelf and pull the buttons on the side of the door shelf direction of arrow (Fig.1).
  • Page 20: Natural Ion Tech / Ionisier

    THE VARIOUS FUNCTION AND POSSIBILITIES Natural Ion Tech / Ionisier (In some models) Natural Ion Tech spreads negative ions which neutralize particles of unpleasant smell and dust in the air. By removing these particles from the air in the refrigerator, Natural Ion Tech improves air quality and eliminates odours.
  • Page 21: Cleaning And Maintenance

    CLEANING AND MAINTENANCE Disconnect the unit from the power supply before cleaning. Do not clean the appliance by pouring water. Make sure that no water enters the lamp housing and other electrical components. The refrigerator should be cleaned periodically using a solution of bicarbonate of soda and lukewarm water.
  • Page 22: Defrosting

    CLEANING AND MAINTENANCE Defrosting Your refrigerator has fully automatic defrosting. The water formed as a result of defrosting passes through the water the condenser and evaporates there. Evaporating Make sure you have disconnected the plug of your tray refrigerator before cleaning the vaporization container. Remove the vaporization container from its position by unscrewing the screws as indicated.
  • Page 23: Arranging Food In The Appliance

    ARRANGING FOOD IN THE APPLIANCE Refrigerator compartment For normal operating conditions, adjusting the temperature value of the cooler partition of the fridge to 4°C will be enough. To reduce humidity and consequent increase of frost never place liquids in unsealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporator and in time will require more frequent defrosting.
  • Page 24: Freezer Compartment

    ARRANGING FOOD IN THE APPLIANCE Freezer compartment Please use the deep freeze compartment of your refrigerator for storing the frozen food for a long time and for producing ice. To get maximum capacity for freezer compartment, please just use glass shelves for upper and middle section. For bottom section, please use lower basket.
  • Page 25 ARRANGING FOOD IN THE APPLIANCE During long lasting power failures, please do not open the door of the deep freeze compartment. During longer power failures, do not refreeze your food and consume them as soon as possible. Not that; if you want to open again immediately after closing the freezer door, it will not be opened easily.
  • Page 26 ARRANGING FOOD IN THE APPLIANCE Maximum Storing time Preparation (month) Steak Wrapping in a foil 6 - 8 Lamb meat Wrapping in a foil 6 - 8 Veal roast Wrapping in a foil 6 - 8 Veal cubes In small pieces 6 - 8 Lamb cubes In pieces...
  • Page 27 ARRANGING FOOD IN THE APPLIANCE Maximum Vegetables and Storing Preparation Fruits time (months) String beans and Wash and cut into small pieces and 10 - 13 beans boil in water Beans Hull and wash and boil in water Cabbage Cleaned and boil in water 6 - 8 Clean and cut to slices and boil in Carrot...
  • Page 28 ARRANGING FOOD IN THE APPLIANCE Maximum Dairy Preparation Storing time Storing Conditions Products (months) Packet In its own Pure Milk – In its (Homogenize) 2 - 3 packet own packet Milk Original package may be used for Cheese- short storing period. excluding In slices 6 - 8...
  • Page 29: Transportation And Changing Of Installation Position

    TRANSPORTATION AND CHANGING OF INSTALLATION POSITION Transportation and Changing of Installation Position The original packages and foamed polystyrene (PS) can be retained if required. During transportation, the appliance should be secured with a wide string or a strong rope. The instructions written on the corrugated box must be followed while transporting.
  • Page 30 BEFORE CALLING YOUR AFTER SALES SERVICE Check Warnings; Your fridge warns you if there is/are some part(s) out of order. In this case, LED around the button will blink and buzzer will sound beep. ERROR TYPE MEANING WHAT TO DO Call Service for "Failure There is/are some...
  • Page 31 BEFORE CALLING YOUR AFTER SALES SERVICE to its function. When the required cooling level is reached, noises will be decreased automatically. If the noises persist; Is your appliance stable? Are the legs adjusted? Is there anything behind your fridge-freezer? Are the shelves or dishes on the shelves vibrating? Re-place the shelves and/or dishes if this is the case.
  • Page 32 BEFORE CALLING YOUR AFTER SALES SERVICE If the edges of fridge cabinet that the door joint contact are warm; Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the compressor, this is normal. IMPORTANT NOTES: Compressor protection function will be activated after sudden power breakdowns or after unplugging the appliance, because the gas in the...
  • Page 33 TIPS FOR SAVING ENERGY 1. Install the appliance in a cool, well ventilated room , but not in direct sunlight and not near a heat source (radiator, cooker.. etc). Otherwise use an insulating plate. 2. Allow warm food and drinks to cool down outside the appliance. 3.
  • Page 48 8 6 5 4 2...
  • Page 65 1– 2– 3– 4– 5– 6– 7–...
  • Page 68 In Ukrainian: In English: «VFD» LLC...
