MultiModem ZPX Quick Start Guide
•
If you change IRQ, click the up or down arrow for the Value field to select the
interrupt value that you recorded earlier. Click OK.
12. Click Finish. A restart Windows prompt appears. Click Yes to restart.
13. After the system reboots, verify that your com port is available and your IRQ is
correct. Click Start |Control Panel and double-click System. Then, click the Hardware
tab.
14. Click Device Manager. Click Ports (COM & LPT) to display the Communications Ports.
If either a yellow Exclamation point or Red Question mark appears, there is either a
conflict with another resource or that the device is disabled. If there are no yellow
exclamation points or red question marks, there are no conflicts.

Step 5 - Run Add Modem Wizard

1. Download the driver zip file for modem model MT5634ZPX-V92 from
www.multitech.com/setup/product.go. Extract the zpxisa.inf file to your hard drive.
Note the location where you saved the zpxisa.inf file.
2. Click on Start I Control Panel and double-click Phone and Modem Options.
3. Click the Modems tab of the Phone and Modem Options window.
4. Click Add.
5. Check Don't detect my modem; I will select it from a list and click Next.
6. Click Have Disk.
7. Browse to the location where you saved the zpxisa.inf file. Click on zpxisa.inf and click
Open. Click OK.
8. In the Models field, select MT5634ZPX-V92 and click Next.
9. Click Selected Ports for the On which ports do you want to install it field and select
the COM port from the list shown. This is the COM port that you selected in
Determine System Resources. Click Next.
10. Windows will display the logo compatibility test screen, click Continue Anyway.
11. Click Finish.

Step 6 - Query Modem

To verify that the system can access the modem:
1. Select the MT5634ZPX-V92 from the Modem tab of the Phone and Modem Options
window. Click Properties. The MT5634ZPX-V92 Properties window displays.
2. Click the Diagnostics tab.
8
