Agrimate AM-RT-212-7P User Manual

Intercultivator / power weeder
Hide thumbs Also See for AM-RT-212-7P:

Advertisement

Quick Links

Download this manual
INTERCULTIVATOR / POWER WEEDER
AM-RT-212-7P
AM-RT-212-7P-WL
TRANSMISSION DIAGRAM WITH PART LIST

Advertisement

loading
Need help?

Need help?

Do you have a question about the AM-RT-212-7P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agrimate AM-RT-212-7P

Summary of Contents for Agrimate AM-RT-212-7P

  • Page 1 INTERCULTIVATOR / POWER WEEDER AM-RT-212-7P AM-RT-212-7P-WL TRANSMISSION DIAGRAM WITH PART LIST...
  • Page 2 Precautions Ÿ When starting the machine, set shifting bar to the neutral position. Ÿ When the machine is working, pay attention to the safety! Ÿ Be careful not to be hurt by the rotary blades! Ÿ When grasp the reverse handle, the shifting bar must be set to the neutral position. Ÿ...
  • Page 3 1. Handle Bar 2. Gear-box Assy. 7. Diesel Engine 8. Bumper 3. Adjustment Screw 9. Throttle Switch 10. Shifting Bar 4. Fender 5. Deep Furrowing Resistance Stick 6. Stepped Box Assy.
  • Page 4 Cultivating Fix the cultivating device onto the left and right side of the transmission shaft of the running part of the power tiller, then use two M8×55 screw bolts for axial positioning. After that, the machine can start cultivating finally. Form of cultivating Four groups 3 blades...
  • Page 5 Multi-Functional Working Dismount protection cover of the gear-box (No.2 in Figure 1), unscrew the bolts away from the rear part of the main shaft, take the cover for keys out of shaft, fasten the self-contained belt pulley or coupling onto the gear-box’s main shaft’s rear part with screws. Type A of common V belt is adopted for belt pulley’s cross section.
  • Page 7 BRACKET OF COLLISION BUMPER(LEFT) CONNECTOR JOINTING ASSEMBLY 2. BRACKET OF COLLISTION BUMPER(FRONT) 23. DEEP FURROWING RESISTANCE STICK 3. BOLT 24. BOLT 4. BRACKER OF COLLISION BUMPER(RIGHT 25. BULLING SET 5. NUT 26. BRCRET OF FENDER COMP 6. SPRING WASHER 27. BRACKET (LEFT) 7.
  • Page 9 Adjustment of the reversing gear cable Unscrew the locknut of the tie rod. ⁒ Spin the tie rod clockwise until the bare handle support is the shortest. ⁓ Get the cable into the reversing fork shaft besides the gear-box, and ensure the joint of cable goes into the hole of the fork shaft. ⁔...

  • Page 10: Technical Specifications

    TECHNICAL SPECIFICATIONS MODEL AM-RT-212-7P-WL ENGINE MODEL 170F ENGINE TYPE Air cooled ,4 stroke ,OHV gasoline ,single cylinder POWER DISPLACEMENT 208CC FUEL TANK CAPACITY 3.6L GEAR 2 FORWARD 1 REVERSE TILLING DEPTH 100-250mm TILLING WIDTH 1000mm WEIGHT 100kg...
  • Page 11 HANDLE CONTROL - A...
  • Page 12 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TA01 Handle Grip AM-RT-212-7P-WL-TA17 Handle bar assy AM-RT-212-7P-WL-TA02 Shut Down Switch Comp AM-RT-212-7P-WL-TA17.1 Handle bar assy(Electric start) AM-RT-212-7P-WL-TA03 Bolt AM-RT-212-7P-WL-TA18 T Figure Lock Comp AM-RT-212-7P-WL-TA04 AM-RT-212-7P-WL-TA19 Spring Washer AM-RT-212-7P-WL-TA05 Throttle Cable Comp...
  • Page 13 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TA32 AM-RT-212-7P-WL-TA33 Startup Lock AM-RT-212-7P-WL-TA34 Startup Control Cord AM-RT-212-7P-WL-TA35 Connecting Bolt AM-RT-212-7P-WL-TA36 Accumulator Fixation Board AM-RT-212-7P-WL-TA37 Accumulator Assy AM-RT-212-7P-WL-TA38 Accumulator Connecting Cord A AM-RT-212-7P-WL-TA39 Accumulator Connecting Cord B AM-RT-212-7P-WL-TA40 Base，Accumulator Assy...
  • Page 14 SHIFT GEAR PARTS - B...
  • Page 15 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TB01 Sheath, Shift rod AM-RT-212-7P-WL-TB17 O-ring AM-RT-212-7P-WL-TB02 Pin , Shift rod AM-RT-212-7P-WL-TB18 Pushing panel AM-RT-212-7P-WL-TB03 Splitpin AM-RT-212-7P-WL-TB19 Oil seal B AM-RT-212-7P-WL-TB04 Bush Shift axes AM-RT-212-7P-WL-TB20 O-ring AM-RT-212-7P-WL-TB05 O-ring AM-RT-212-7P-WL-TB21 Sheath, principal axes...
  • Page 16 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TB33 Washer AM-RT-212-7P-WL-TB49 Ball bearing AM-RT-212-7P-WL-TB34 Restrict cover, reverse gear AM-RT-212-7P-WL-TB50 Double gear, countershaft AM-RT-212-7P-WL-TB35 Spring AM-RT-212-7P-WL-TB51 Gasket, countershaft AM-RT-212-7P-WL-TB36 Spring seat, reverse gear AM-RT-212-7P-WL-TB52 Sheath, countershaft AM-RT-212-7P-WL-TB37 Double gear, reverse gear...
  • Page 17 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TB65 Seat, clutch cable AM-RT-212-7P-WL-TB82 Cushion AM-RT-212-7P-WL-TB66 Seat, clutch cable AM-RT-212-7P-WL-TB83 Cover, clutch AM-RT-212-7P-WL-TB67 Spring washer AM-RT-212-7P-WL-TB84 Core comp, clutch AM-RT-212-7P-WL-TB68 Pin ,clutch fork AM-RT-212-7P-WL-TB85 Platen AM-RT-212-7P-WL-TB69 Axes, clutch fork...
  • Page 18 TRANSMISSION PART LIST - C...
  • Page 19 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TC01 AM-RT-212-7P-WL-TC17 Gasket AM-RT-212-7P-WL-TC02 Splitpin AM-RT-212-7P-WL-TC18 Taper ball bearing AM-RT-212-7P-WL-TC03 Spring washer AM-RT-212-7P-WL-TC19 Gasket AM-RT-212-7P-WL-TC04 Driven umbrella gear AM-RT-212-7P-WL-TC20 Side cover, walking case AM-RT-212-7P-WL-TC05 Taper ball bearing AM-RT-212-7P-WL-TC21 Washer AM-RT-212-7P-WL-TC06...
  • Page 20 BLADES - D SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TD01 Round plate(optional) AM-RT-212-7P-WL-TD07 Blade(L) AM-RT-212-7P-WL-TD02 Counter tube AM-RT-212-7P-WL-TD08 Blade( R ) AM-RT-212-7P-WL-TD03 Bolt AM-RT-212-7P-WL-TD09 Hex bolt AM-RT-212-7P-WL-TD04 Spring washer AM-RT-212-7P-WL-TD10 AM-RT-212-7P-WL-TD05 AM-RT-212-7P-WL-TD11 Washer AM-RT-212-7P-WL-TD06 Main tube...
  • Page 21 WHEEL PARTS - E SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TE01 AM-RT-212-7P-WL-TE06 Inner tube AM-RT-212-7P-WL-TE02 Spring washer AM-RT-212-7P-WL-TE07 Outer rubber tyre AM-RT-212-7P-WL-TE03 Washer AM-RT-212-7P-WL-TE08 Spoke ( L ) AM-RT-212-7P-WL-TE04 Wheel axle AM-RT-212-7P-WL-TE09 Hex bolt AM-RT-212-7P-WL-TE05 Spoke ( R )
  • Page 22 JOINT PARTS - F...
  • Page 23 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TE01 Diesel engine comp AM-RT-212-7P-WL-TE17 Bolts AM-RT-212-7P-WL-TE1.1 Diesel engine comp(Electric start) AM-RT-212-7P-WL-TE18 Washer AM-RT-212-7P-WL-TE02 Flange gasket AM-RT-212-7P-WL-TE19 Spring washer AM-RT-212-7P-WL-TE03 Flange AM-RT-212-7P-WL-TE20 AM-RT-212-7P-WL-TE04 Bolt AM-RT-212-7P-WL-TE21 Frame( R ) AM-RT-212-7P-WL-TE05 Airproof gasket, gear box...
  • Page 24 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-RT-212-7P-WL-TE34 Bolts, AM-RT-212-7P-WL-TE51 Clip AM-RT-212-7P-WL-TE35 Dragging assy AM-RT-212-7P-WL-TE52 Flange bolt AM-RT-212-7P-WL-TE36 Pin with ring AM-RT-212-7P-WL-TE53 Flange bolt AM-RT-212-7P-WL-TE37 Clip AM-RT-212-7P-WL-TE38 Bolts AM-RT-212-7P-WL-TE39 Connection plate AM-RT-212-7P-WL-TE40 Connection frame AM-RT-212-7P-WL-TE41 AM-RT-212-7P-WL-TE42 Clip...

  • Page 25: Warranty Card

    WARRANTY CARD CUSTOMER COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE DATE OF DELIVERY PURCHASERS NAME & ADDRESS CUSTOMER SIGN INVOICE/DN NO. PRODUCT SERIAL NO. PRODUCT NAME I/Will accept the terms and conditions of warranty as in the warranty card DEALERS COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE...
  • Page 26 1.LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under warranty will be accepted on submission of Warranty Card duly filled and stamped by authorized dealer together with the original purchase document.
  • Page 27 1st service coupon ISO 9001 : 2015 CERTIFIED COMPANY FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER SERIAL NUMBER MODEL SERVICE NO. PURCHASE BILL NO. DATE PDI DATE OPERATIONS DEALERS OFFICE SEAL 1. Check and test the fuel mixture 2. check and clean the air filter 3.Check , clean and adjust the spark plug 4.
  • Page 28 DONTS Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before attempting to use the equipments. 2. It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, trousers and jackets while operating potentially dangerous machines 3.
  • Page 29 Agrimate Army For Pest Control ANY WHERE - ANY TIME - ANY CROP RATNAGIRI IMPEX PVT., LTD., Annapurna House, #1 / 1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore - 560 026 Missed Call : 7393 938 938 Email: ask@agrimart.in...

This manual is also suitable for:

Am-rt-212-7p-wl
