Agrimate AM-RT-212-7P-MAX User Manual

Intercultivator / power weeder
Hide thumbs

Advertisement

Quick Links

Download this manual
INTERCULTIVATOR / POWER WEEDER
AM-RT-212-7P
AM-RT-212-7P-MAX
AM-RT-212-7P-WL
ENGINE DIAGRAM WITH PART LIST

Advertisement

loading
Need help?

Need help?

Do you have a question about the AM-RT-212-7P-MAX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agrimate AM-RT-212-7P-MAX

Summary of Contents for Agrimate AM-RT-212-7P-MAX

  • Page 1 INTERCULTIVATOR / POWER WEEDER AM-RT-212-7P AM-RT-212-7P-MAX AM-RT-212-7P-WL ENGINE DIAGRAM WITH PART LIST...
  • Page 2 ENGINE ASSY - A...
  • Page 3 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EA01 HEAD ASSY AM-170FPK-EA02 CRANKCASE ASSY AM-170FPK-EA03 CRANKCASE COVER ASSY AM-170FPK-EA04 CRANK-CONNECTING ROD ASSY AM-170FPK-EA05 VALVE TRAIN ASSY AM-170FPK-EA06 STAR ASSY AM-170FPK-EA07 FLYWHEEL AND IGNITION ASSY AM-170FPK-EA08 INLET ASSY AM-170FPK-EA09 CARBURETOR CIRCUIT ASSY AM-170FPK-EA10 THROTTLE CONTROL ASSY...
  • Page 4 HEAD ASSAMBLY-B...
  • Page 5 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EB01 HEAD COVER AM-170FPK-EB02 BOLT AM-170FPK-EB03 HEAD COVER GASKET AM-170FPK-EB04 BOLT AM-170FPK-EB05 SPARK PLUG AM-170FPK-EB06 STUD AM-170FPK-EB07 STUD AM-170FPK-EB08 CYLINDER HEAD ASSY AM-170FPK-EB09 CYLINDER HEAD GASKET AM-170FPK-EB10 DOWEL PIN...
  • Page 6 CRANK CASE ASSY-C...
  • Page 7 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EC1.1 CRANKCASE COMP AM-170FPK-EC10 DRAIN PLUG BOLT AM-170FPK-EC1.2 CRANKCASE COMP AM-170FPK-EC11 OIL SEAL AM-170FPK-EC02 GOVERNOR ARM SHAFT AM-170FPK-EC12 OIL SEAL AM-170FPK-EC03 GOVERNOR ARM SHAFT LOCKER AM-170FPK-EC13 START MOTOR ASSY AM-170FPK-EC04 PLAIN WASHER AM-170FPK-EC14 BOLT...
  • Page 8 CRANK CASE COVER ASSY-D SL NO PART NO DESCRIPTION AM-170FPK-ED01 CRANKCASE COVER AM-170FPK-ED02 OIL FILLER PLUG ASSY AM-170FPK-ED03 DIPSTICK SEALING RING AM-170FPK-ED04 OIL FILLER PLUG AM-170FPK-ED05 BOLT AM-170FPK-ED06 OIL SEAL AM-170FPK-ED07 DIPSTICK ASSY AM-170FPK-ED08 DIPSTICK AM-170FPK-ED09 BEARING AM-170FPK-ED10 CASE COVER GASKET AM-170FPK-ED11 DOWEL PIN...
  • Page 10 CRANK CONNECTING ROD ASSY - E...
  • Page 11 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EE01 CRANK SHAFT ASSY AM-170FPK-EE02 SPECIAL WOODRUFF KEY AM-170FPK-EE03 CRANK SHAFT AM-170FPK-EE04 CONNECTING ROD ASSY AM-170FPK-EE05 PISTON AM-170FPK-EE06 CLIP PISTON PIN AM-170FPK-EE07 PIN PISTON AM-170FPK-EE08 PISTON RING ASSY AM-170FPK-EE09 FILM LOOP AM-170FPK-EE10 BUSH RING AM-170FPK-EE11...
  • Page 12 VALVE TRAIN ASSY - F...
  • Page 13 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EF01 CAMSHAFT ASSY AM-170FPK-EF10 INLET VALVE AM-170FPK-EF02 VALVE LIFTER AM-170FPK-EF11 EXHAUST VALVE AM-170FPK-EF03 PUSH ROD AM-170FPK-EF12 VALVE SEAL AM-170FPK-EF04 PUSH ROD GUIDE PLATE AM-170FPK-EF13 VALVE SPRING AM-170FPK-EF05 VALVE ROCKER ARM ASSY AM-170FPK-EF14 INTAKE VALVE SPRING SEAT AM-170FPK-EF06...
  • Page 14 STARTER ASSY - G...
  • Page 15 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EG01 RECOIL STARTER ASSY AM-170FPK-EG10 RETURN SPRING AM-170FPK-EG02 WIND SCOOPER AM-170FPK-EG11 RECOIL STARTER REEL AM-170FPK-EG03 BOLT AM-170FPK-EG12 STARTER RETURN SPRING AM-170FPK-EG04 ENGINE STOP SWITH ASSY AM-170FPK-EG13 RECOIL STARTER COVER COMP AM-170FPK-EG05 RECOIL STARTER COMP AM-170FPK-EG14...
  • Page 16 INLET ASSY - H SL NO PART NO DESCRIPTION AM-170FPK-EH01 AIR INTAKE WASHER AM-170FPK-EH02 INSULATOR AM-170FPK-EH03 CARBURETOR PACKING AM-170FPK-EH04 CARBURETOR AM-170FPK-EH05 AIR CLEANER GASKET AM-170FPK-EH06 AIR CLEANER ASSY AM-170FPK-EH07 AIR CLEANER ASSY AM-170FPK-EH08 BOLT AM-170FPK-EH09...
  • Page 18 AIR FILTER ASSY - J SL NO PART NO DESCRIPTION AM-170FPK-EJ01 AIR CLEANER ASSY AM-170FPK-EJ02 AIR CLEANER CASE AM-170FPK-EJ03 WASTE GAS PIPE AM-170FPK-EJ04 PACKING AM-170FPK-EJ05 Air filter oil filter oil cup AM-170FPK-EJ06 AIR CLEANER SPENGE ELEMENT AM-170FPK-EJ07 AIR CLEANER SPENGE ELEMENT AM-170FPK-EJ08 SEAL COVER AM-170FPK-EJ09...
  • Page 20 CARBURETOR CIRCUIT ASSY - K...
  • Page 21 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EK01 CARBURETOR AM-170FPK-EK12 FUEL SWITCH SEAL AM-170FPK-EK02 CHOKE PLATE HANDLE AM-170FPK-EK13 SEDIMENT BOWL SEAL AM-170FPK-EK03 IDLE HOLE COMPONENT AM-170FPK-EK14 SEDIMENT BOWL AM-170FPK-EK04 PILOT JET SET AM-170FPK-EK15 FLOAT SET AM-170FPK-EK05 AM-170FPK-EK16 FLOAT CHAMBER SET AM-170FPK-EK06 MAIN NOZZLE...
  • Page 22 THROTTLE CONTROL ASSY - L...
  • Page 23 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EL01 GOVERNOR ARM AM-170FPK-EL09 BOLT AM-170FPK-EL02 T-SHAPE BOLT AM-170FPK-EL10 SCREW AM-170FPK-EL03 AM-170FPK-EL10.1 WIRE TERMINAL AM-170FPK-EL04 TIE ROD AM-170FPK-EL10.2 WIRE TERMINAL AM-170FPK-EL05 FINE ADJUSTMENT SPRING AM-170FPK-EL11 BOLT AM-170FPK-EL06 GOVERNING SPRING AM-170FPK-EL12 PRESS LINE BOARD AM-170FPK-EL07 CONTROL ASSY...
  • Page 24 FLYWHEEL AND IGNITION ASSY -M...
  • Page 25 FLYWHEEL AND IGNITION ASSY -M...
  • Page 26 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EM01 IGNITION AM-170FPK-EM08 AM-170FPK-EM02 IGNITION CAP AM-170FPK-EM09 CHARGE COIL ASSY AM-170FPK-EM03 CORD STOP SWITCH AM-170FPK-EM10 AM-170FPK-EM04 BOLT AM-170FPK-EM11 CLAMPING PLATE AM-170FPK-EM5.1 FLYWEEL AM-170FPK-EM12 AM-170FPK-EM5.2 FLYWEEL AM-170FPK-EM06 COOLING FAN AM-170FPK-EM07 STARTER PULLEY...
  • Page 27 EXHAUST ASSY - N...

  • Page 28: Spring Washer

    SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EN01 MUFFLER COMP AM-170FPK-EN02 MUFFLER COMP AM-170FPK-EN03 GUIDING COVER AM-170FPK-EN04 SCREW AM-170FPK-EN5.1 FLYWHEEL AM-170FPK-EN5.2 FLYWHEEL AM-170FPK-EN6 BOLT AM-170FPK-EN7 BOLT AM-170FPK-EN8 AIR EXHAUST WASHER AM-170FPK-EN9 AM-170FPK-EN10 SPRING WASHER...
  • Page 29 FULE OIL ASSY-P...
  • Page 30 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EP1.1 TANK FUEL COMP AM-170FPK-EP1.2 TANK FUEL COMP AM-170FPK-EP02 FUEL FILLER CAP COMP AM-170FPK-EP03 FUEL FILLER PACKING AM-170FPK-EP04 FILTER FUEL AM-170FPK-EP5.1 FUEL TANK AM-170FPK-EP5.2 FUEL TANK AM-170FPK-EP06 PACKING AM-170FPK-EP07 FUEL TANK JOINT AM-170FPK-EP08 TUBE CLIP AM-170FPK-EP09...
  • Page 31 WIND DEFECLECTOR - Q SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-EQ01 WINDSHIELD AM-170FPK-EQ02 BOLT AM-170FPK-EQ03 SHROUD COMP AM-170FPK-EQ04 PROTECTIVE BREAKER...
  • Page 33 REDUCTION ASSY - R...
  • Page 34 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-170FPK-ER01 CRANKCASE COVER ASSY AM-170FPK-ER10 PACKING AM-170FPK-ER02 DRIVE SPROCKET WHEEL AM-170FPK-ER11 REDUCTION GEARBOX COVER AM-170FPK-ER03 WASHER AM-170FPK-ER12 BOLT AM-170FPK-ER04 BOLT AM-170FPK-ER13 OIL SEAL AM-170FPK-ER05 CHAIN COMP AM-170FPK-ER14 BOLT AM-170FPK-ER06 DOWEL PIN AM-170FPK-ER15 SCREW AM-170FPK-ER07...

  • Page 35: Warranty Card

    WARRANTY CARD CUSTOMER COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE DATE OF DELIVERY PURCHASERS NAME & ADDRESS CUSTOMER SIGN INVOICE/DN NO. PRODUCT SERIAL NO. PRODUCT NAME I/Will accept the terms and conditions of warranty as in the warranty card DEALERS COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE...
  • Page 36 1.LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under warranty will be accepted on submission of Warranty Card duly filled and stamped by authorized dealer together with the original purchase document.
  • Page 37 1st service coupon ISO 9001 : 2015 CERTIFIED COMPANY FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER SERIAL NUMBER MODEL SERVICE NO. PURCHASE BILL NO. DATE PDI DATE OPERATIONS DEALERS OFFICE SEAL 1. Check and test the fuel mixture 2. check and clean the air filter 3.Check , clean and adjust the spark plug 4.
  • Page 38 DONTS attempting to use the equipments. Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before trousers and jackets while operating potentially dangerous machines 2. It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, 3.
  • Page 39 NO. 1 CHOICE OF FARMERS SINCE 1999 RATNAGIRI IMPEX PVT., LTD., Annapurna House, #1 / 1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore - 560 026 Missed Call : 7393 938 938 Email: ask@agrimart.in...

This manual is also suitable for:

Am-rt-212-7pAm-rt-212-7p-wl
