Agrimate AM-MPT-9D User Manual

Intercultivator / power weeder
Hide thumbs

Advertisement

Quick Links

Download this manual
INTERCULTIVATOR / POWER WEEDER
AM-MPT- 9D/6D
MANUAL
ELECTRIC
DGB

Advertisement

loading
Need help?

Need help?

Do you have a question about the AM-MPT-9D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Agrimate AM-MPT-9D

Summary of Contents for Agrimate AM-MPT-9D

  • Page 1 INTERCULTIVATOR / POWER WEEDER AM-MPT- 9D/6D MANUAL ELECTRIC...
  • Page 2 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Transmission Case Comp-...
  • Page 3 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TA-01 Bolt AM-MPT-1100-9D-TA-13 Bush AM-MPT-1100-9D-TA-02 Locked washer AM-MPT-1100-9D-TA-14 Spring washer AM-MPT-1100-9D-TA-03 Big washer AM-MPT-1100-9D-TA-15 Circlip F AM-MPT-1100-9D-TA-04 Ball bearing AM-MPT-1100-9D-TA-16 Shift gear rocker AM-MPT-1100-9D-TA-05 Clutch comp...
  • Page 4 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TA-29 Clutch cable seat AM-MPT-1100-9D-TA-30 II Oil ruler AM-MPT-1100-9D-TA-31 Locked nut AM-MPT-1100-9D-TA-32 Washer AM-MPT-1100-9D-TA-33 Clutch AM-MPT-1100-9D-TA-34 AM-MPT-1100-9D-TA-35 Clutch fork...
  • Page 5 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Transmission Back Case Comp- B...
  • Page 6 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TB-01 Vice shaft AM-MPT-1100-9D-TB-17 Ball bearing AM-MPT-1100-9D-TB-02 Ball bearing AM-MPT-1100-9D-TB-18 Back case cover AM-MPT-1100-9D-TB-03 Adjustment washer AM-MPT-1100-9D-TB-19 Circlip F AM-MPT-1100-9D-TB-04 Needle bearing AM-MPT-1100-9D-TB-20 Shif gear rocker...
  • Page 7 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION Output slutch push dog Reverse cable seat AM-MPT-1100-9D-TB-33 AM-MPT-1100-9D-TB-49 Plastic clutch cover Bolt AM-MPT-1100-9D-TB-34 AM-MPT-1100-9D-TB-50 Reverse fork AM-MPT-1100-9D-TB-35 AM-MPT-1100-9D-TB-51 Bolt Main shaft AM-MPT-1100-9D-TB-36 AM-MPT-1100-9D-TB-52...
  • Page 8 Transmission Back Case Comp- BN (Improved)
  • Page 9 SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TBN-01 Transmission case back cover AM-MPT-1100-9D-TBN-17 AM-MPT-1100-9D-TBN-02 Shaft circlip AM-MPT-1100-9D-TBN-18 output clutch handle AM-MPT-1100-9D-TBN-03 Coupling sleeve AM-MPT-1100-9D-TBN-19 circlip A AM-MPT-1100-9D-TBN-04 Spindle AM-MPT-1100-9D-TBN-20 Deep groove ball bearing AM-MPT-1100-9D-TBN-05 Wear washer AM-MPT-1100-9D-TBN-21 Circlips for holes AM-MPT-1100-9D-TBN-06 Needle bearing...
  • Page 10 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Transmission Back case comp- C...
  • Page 11 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TC-01 Combination gasket AM-MPT-1100-9D-TC-02 Stud bolt AM-MPT-1100-9D-TC-03 Dowel pin AM-MPT-1100-9D-TC-04 Output clutch srping AM-MPT-1100-9D-TC-05 Washer AM-MPT-1100-9D-TC-06 Split pin AM-MPT-1100-9D-TC-07 Washer AM-MPT-1100-9D-TC-08 Spring washer AM-MPT-1100-9D-TC-09...
  • Page 12 Transmission combination parts- C N SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TCN-01 Back cover closing paper pad AM-MPT-1100-9D-TCN-02 Hexagon head bolt...
  • Page 13 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Walking case comp -...
  • Page 14 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TD-01 Bolt AM-MPT-1100-9D-TD-17 Spring washer AM-MPT-1100-9D-TD-02 Spring washer AM-MPT-1100-9D-TD-18 Gasket AM-MPT-1100-9D-TD-03 Gasket AM-MPT-1100-9D-TD-19 Split pin AM-MPT-1100-9D-TD-04 Lip seal AM-MPT-1100-9D-TD-20 Slotted nut AM-MPT-1100-9D-TD-05 Walking case end cover AM-MPT-1100-9D-TD-21...
  • Page 15 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Tow Bar Comp -...
  • Page 16 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TE-01 Bolt AM-MPT-1100-9D-TE-02 AM-MPT-1100-9D-TE-03 AM-MPT-1100-9D-TE-04 Connection frame AM-MPT-1100-9D-TE-05 Clip B AM-MPT-1100-9D-TE-06 Tow bar AM-MPT-1100-9D-TE-07 Bolt AM-MPT-1100-9D-TE-08 Spring washer AM-MPT-1100-9D-TE-09 Pin with ring AM-MPT-1100-9D-TE-10 Resistance rod...
  • Page 17 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB KM handle Bar Comp(Usually open clutch) -...
  • Page 18 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TF-01 handle rubber AM-MPT-1100-9D-TF-17 AM-MPT-1100-9D-TF-02 Handle frame AM-MPT-1100-9D-TAF-18 Shift gear rod AM-MPT-1100-9D-TF-03 III usually open clutch cable AM-MPT-1100-9D-TF-19 Clip B AM-MPT-1100-9D-TF-04 Cable clip AM-MPT-1100-9D-TF-20...
  • Page 19 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Engine and connections-...
  • Page 20 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TG-01 AM-MPT-1100-9D-TG-02 Spring Washer AM-MPT-1100-9D-TG-03 Gasket AM- 178F diesel engine for 6D AM-MPT-1100-9D-TG-04 AM-186FB diesel engine for 9D Engine frame for 6D AM-MPT-1100-9D-TG-05 Engine frame for 9D Bumper for 6D...
  • Page 21 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Engine & Connections - H SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TH-01 Hexagon socket head screw AM-MPT-1100-9D-TH-02 Spring washer AM-MPT-1100-9D-TH-03 Hexagon socket head screw AM-MPT-1100-9D-TH-04 2nd generation diesel engine flange AM-MPT-1100-9D-TH-05 2nd generation pressure relief bolt AM-MPT-1100-9D-TH-06 Split pin AM-MPT-1100-9D-TH-07...
  • Page 22 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Fender parts -...
  • Page 23 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TJ-01 AM-MPT-1100-9D-TJ-17 AM-MPT-1100-9D-TJ-02 Front fender AM-MPT-1100-9D-TJ-03 Bolt AM-MPT-1100-9D-TJ-04 Big gasket AM-MPT-1100-9D-TJ-05 Bolt AM-MPT-1100-9D-TJ-06 II dust fender right frame(Higher) AM-MPT-1100-9D-TJ-07 Right vice fender AM-MPT-1100-9D-TJ-08 Press piece AM-MPT-1100-9D-TJ-09...
  • Page 24 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB WHEEL PARTS -...
  • Page 25 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-9D-TK-01 Bolt AM-MPT-1100-9D-TK-02 Outside rim(with hole) AM-MPT-1100-9D-TK-03 Wheel and tyre AM-MPT-1100-9D-TK-04 Inner rim AM-MPT-1100-9D-TK-05 Wheel axle AM-MPT-1100-9D-TK-06 Gasket AM-MPT-1100-9D-TK-07 Spring washer AM-MPT-1100-9D-TK-08 AM-MPT-1100-9D-TK-09 Hexagon fasten sheath...
  • Page 26 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB ROTARY PARTS -...
  • Page 27 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION Bolt AM-MPT-1100-9D-TL-01 Bolt Right blades AM-MPT-1100-9D-TL-02 Right blades 3+1 cylinder for 6D AM-MPT-1100-9D-TL-03 3+1+1 cylinder for 9D Spring washer 10 AM-MPT-1100-9D-TL-04 Spring washer 10 AM-MPT-1100-9D-TL-05...
  • Page 28 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB ELECTRIC START -...
  • Page 29 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION Handle 178FE diesel engine AM-MPT-1100-9D-TM-13 AM-MPT-1100-9D-TM-01 186FBE diesel engine Bolt AM-MPT-1100-9D-TM-02 Bolt II battery(Higher) AM-MPT-1100-9D-TM-03 III battery box 18Ah battery AM-MPT-1100-9D-TM-04 36Ah battery Battery cable...
  • Page 30 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB 9D differential Gear Box -...
  • Page 31 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-DGB-A01 Hexagon socket head bolt AM-MPT-1100-DGB-A17 Split pin AM-MPT-1100-DGB-A02 Cover AM-MPT-1100-DGB-A18 Hexagon Slotted Thin Nut AM-MPT-1100-DGB-A03 Lip-shaped oil seal AM-MPT-1100-DGB-A19 Spring washer AM-MPT-1100-DGB-A04 Hexagon head bolt...
  • Page 32 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB SL NO PART NO DESCRIPTION SL NO PART NO DESCRIPTION AM-MPT-1100-DGB-A33 Circlip for shaft AM-MPT-1100-DGB-A34 Oil drain bolt AM-MPT-1100-DGB-A35 O-ring seal AM-MPT-1100-DGB-A36 Walking bevel gear AM-MPT-1100-DGB-A37.1 Adjusting pad A AM-MPT-1100-DGB-A37.2 Adjusting pad B...
  • Page 33 TRANSMISSION DIAGRAM & SPARE PARTS LIST OF AM-MPT-1100-9D/6D / DGB Differential left & Right Clutch cable- SL NO PART NO DESCRIPTION AM-MPT-1100-DGB-B01 Steering clutch handle AM-MPT-1100-DGB-B02 Steering cable AM-MPT-1100-DGB-B03 Hex nut AM-MPT-1100-DGB-B04 Spring washer AM-MPT-1100-DGB-B05 Flat washer AM-MPT-1100-DGB-B06 Hexagon head bolt...
  • Page 34 WARRANTY CARD CUSTOMER COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE DATE OF DELIVERY PURCHASERS NAME & ADDRESS CUSTOMER SIGN INVOICE/DN NO. PRODUCT SERIAL NO. PRODUCT NAME I/Will accept the terms and conditions of warranty as in the warranty card DEALERS COPY DEALERS SIGN DEALERS OFFICIAL SEAL DATE...
  • Page 35 1.LIMITED WARRANTY PERIOD : For a period of six months from the date of Sale / delivery of the product which ever is earlier. 2. LIMITED WARRANTY OBLIGATION : Replacement of defective part(s) by authorized dealer are free of charges. If found defective by reasons of defective material / poor workmanship, parts will be replaced and there will be no value re-imbursement. 3. TERMS & CONDlTlONS : a. Claims under warranty will be accepted on submission of Warranty Card duly filled and stamped by authorized dealer together with the original purchase document.
  • Page 36 1st service coupon ISO 9001 : 2015 CERTIFIED COMPANY FREE SERVICE COUPON (30DAYS/30HRS. WHICHEVER IS EARLIER SERIAL NUMBER MODEL SERVICE NO. PURCHASE BILL NO. DATE PDI DATE OPERATIONS DEALERS OFFICE SEAL 1. Check and test the fuel mixture 2. check and clean the air filter 3.Check , clean and adjust the spark plug 4.
  • Page 37 DONTS Always read the instruction manual supplied along with the equipments and understand the correct installation and operating procedures before attempting to use the equipments. 2. It is important to use the personal protection equipments such as head helmet with visor, ear defenders, goggles, safety gloves, cut resistant shoes, trousers and jackets while operating potentially dangerous machines 3.
  • Page 38 Agrimate Army For Pest Control ANY WHERE - ANY TIME - ANY CROP RATNAGIRI IMPEX PVT., LTD., Annapurna House, #1 / 1G, 7th Cross, New Guddadahalli Mysore Road, Bangalore - 560 026 Missed Call : 7393 938 938 Email: ask@agrimart.in...

This manual is also suitable for:

Am-mpt-6dAm-mpt-dgb
