SightLine 3000-OEM Startup Manual

Hide thumbs Also See for 3000-OEM:
Table of Contents

Advertisement

Quick Links

Download this manual
EAN-Startup Guide 3000-OEM
2023-05-04
Exports:
Export Summary Sheet
EULA:
End User License Agreement
Web:
sightlineapplications.com
1
Overview ................................................................ 1
1.1
Additional Support Documentation ....................... 1
1.2
SightLine Software Requirements .......................... 1
2
Safe Device Handling .............................................. 1
3
3000-EVAL Kit with 3000-mIO ................................ 1
4
Hardware Bench Setup .......................................... 2
4.1
Additional SightLine Adapter Boards ..................... 4
5
Network Configuration .......................................... 4
6
Serial Communications .......................................... 5
6.1
Direct Serial Connection (optional) ........................ 5
7
Panel Plus ............................................................... 6
CAUTION: Alerts to a potential hazard that may result in personal injury, or an unsafe practice that causes damage to the equipment
if not avoided.
IMPORTANT: Identifies crucial information that is important to setup and configuration procedures.
Used to emphasize points or reminds the user of something. Supplementary information that aids in the use or understanding of the
equipment or subject that is not critical to system use.
© SightLine Applications, Inc.
Sales:
sales@sightlineapplications.com
Support:
support@sightlineapplications.com
7.1
Camera Acquisition ................................................ 7
7.2
Stream Network Video to This PC .......................... 8
8
Summary ................................................................ 9
8.1
Demo Mode ......................................................... 10
9
Modifying Encoder Parameters ........................... 10
10
Troubleshooting ................................................... 11
10.1 Network Connection ............................................ 11
10.2 3000-OEM HD-SDI Camera Input ......................... 12
10.4 Questions and Additional Support ....................... 13
Phone: +1 (541) 716-5137

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3000-OEM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SightLine 3000-OEM

Summary of Contents for SightLine 3000-OEM

  • Page 1: Table Of Contents

    Network Configuration .......... 4 10.2 3000-OEM HD-SDI Camera Input ......12 Serial Communications .......... 5 10.3 Send Diagnostic Files to SightLine Support ..13 Direct Serial Connection (optional) ......5 10.4 Questions and Additional Support ....... 13 Panel Plus ............... 6 ...

  • Page 2: Overview

    EAN-Startup Guide-3000-OEM 1 Overview The 3000-OEM Startup Guide provides the steps for connecting, configuring, and evaluating the 3000- OEM video processing board on the SLA-3000-mIO interface board. The mIO is optimized for connections in an integrated assembly. Compared to the SLA-3000-IO the mIO is smaller, uncomplicated, has small round wire interfaces and supports a two-board stack height.

  • Page 3: Hardware Bench Setup

    Serial adapter (stripped) Mounting hardware Spacers and mounting screws The SLA-3000-IO board is alternate interface board for the 3000-OEM that comes in the standard 3000-EVAL kit. 4 Hardware Bench Setup  IMPORTANT: To prevent damage to hardware boards, disconnect the power before connecting or disconnecting all cable connections.
  • Page 4 A green light on the 3000-IO or 3000-mIO board indicates that all boards are powered on. An • amber light on the 3000-OEM board verifies network connection. To prevent voltage spikes to the board, plug in the power adapter to an AC power source first and •...

  • Page 5: Additional Sightline Adapter Boards

    Figure 3: 3000-OEM Serial Port and Connector Reference 5 Network Configuration The 3000-OEM board can be connected directly to the host PC or through a network switch. During startup, the board sends three DHCP discover requests in three second intervals. It will self-assign the link-local address of 169.254.1.181 if it does not receive a response.

  • Page 6: Serial Communications

    Board Figure 5: Serial COM and Power Connection-SLA-3000-IO 6.1 Direct Serial Connection (optional) 1. Connect the serial cable to the 3000-OEM board and host PC as described in Serial Communications. 2. From the Connect tab, click the Refresh List button to get a list of available COM ports.

  • Page 7: Panel Plus

    This section covers the Panel Plus setup and configuration process. Panel Plus provides a basic graphical interface to the features and functions of the 3000-OEM and 3000-mIO board. Before connecting with the Panel Plus software, the 3000-OEM and 3000-mIO boards should be powered up and connected through: a network switch or directly to the host PC (preferred) or, Direct serial connection (for troubleshooting or if a network connection cannot be established).

  • Page 8: Camera Acquisition

     Once the connection is successful, the button changes to Connected. 5. Verify the connection. When Panel Plus has successfully connected to the 3000-OEM board, operating information is displayed under the Video Output section and the bottom status bar in Panel Plus.

  • Page 9: Stream Network Video To This Pc

    EAN-Startup Guide-3000-OEM 2. Since the SLA-3000-HDSDI-IN board is on J4 on the 3000-OEM or VIN 1 on the 3000-IO, set the Camera Index to Cam 2. Set the Camera Type to Generic Digital. In the Auto Fill drop-down menu, select HD-SDI 720p from the Auto Fill menu or enter the Height and Width settings of the connected camera.

  • Page 10: Summary

    EAN-Startup Guide-3000-OEM 8 Summary This completes the startup guide for the 3000-OEM board. See the Panel Plus User Guide (main menu » Help » User Guide) for additional user and setup information. If the board has been connected to a camera and encoding functions are part of the configuration, video will be displayed in the main window.

  • Page 11: Demo Mode

    EAN-Startup Guide-3000-OEM 8.1 Demo Mode SightLine offers a free demo mode for testing non-licensed features. To test and evaluate these features, click the Demo Mode button located in the Connect tab. To exit the demo mode power cycle the OEM. The Demo Mode screen overlay will continue to display until the Demo Mode function is turned off.

  • Page 12: Troubleshooting

    EAN-Startup Guide-3000-OEM 10 Troubleshooting 10.1 Network Connection Issue: Unable to connect with the Panel Plus application to the 3000-OEM board over a standard network connection. Check static IP address: Check the static IP address configuration. Improper or unknown static IP address setup is a common connection problem.

  • Page 13: 3000-Oem Hd-Sdi Camera Input

    The Panel Plus software will automatically recognize serial ports and list them in the drop- down menu for available connections.  Connecting to the serial COM port on the 3000-OEM board from a host PC requires a null modem adapter or null modem serial cable. 10.2 3000-OEM HD-SDI Camera Input Issue: Network output video shows image in the upper left corner of Panel Plus with a green background.

  • Page 14: Send Diagnostic Files To Sightline Support

    SightLine upgrade utility application to download files and then send them to Support. Figure 16: Get Diagnostic Files Additional diagnostic information can also be obtained from the 3000-OEM by displaying the system log. 1. Establish an SSH session to the OEM with Tera Term (recommended) or similar application.
