The Status Bar
The Status Bar is displayed in the upper left corner of the web browser
interface screen. Figure 5-15 shows an expanded view of the status bar.
Status Indicator
Figure 5-15. Example of the Status Bar
The Status bar consists of four objects:
■ Status Indicator. Indicates, by icon, the severity of the most critical
alert in the current display of the Alert Log. This indicator can be one of
three shapes and colors as shown in the following table.
Table 5-1.Status Indicator Key
Color Switch Status
Blue Normal Activity; "First time installation"
information available in the Alert log.
Green Normal Activity
Yellow Warning
Red Critical
■ System Name. The name you have configured for the switch by using
Identity screen, system name command, or the switch console System
Information screen.
Using the Web Browser Interface
Most Critical Alert Description
Product Name
Status Indicator Shape
Status Reporting Features
5-23
