- Page 1 EN Installation / User Instructions / Warranty FR Instructions de montage / Mode d'emploi / Garantie ES Instrucciones de montaje / Manejo / Garantía Unica´C 27617xx0...
-
Page 2: Installation Considerations
English Installation Considerations max. 3¾" • For best results, Hansgrohe recommends that this unit be installed by a licensed, professional plumber. • Please read over these instructions thoroughly before beginning installation. Make sure that ⅞" you have all tools and supplies needed to complete the installation. • The screws and anchors included with this set are suitable for use in a tile or other solid surface wall. They are not suitable for use in an acrylic or fiberglass shower enclosure. Please... -
Page 3: Consideraciones Para La Instalación
Français Español À prendre en considération Consideraciones para la pour l’installation instalación • Pour de meilleurs résultats, Hansgrohe • Para obtener mejores resultados, la instalación recommande que ce produit soit installé par un debe estar a cargo de un plomero profesional plombier professionnel licencié. matriculado. • Veuillez lire attentivement ces instructions avant • Antes de comenzar la instalación, lea estas de procéder à l’installation. Assurez-vous instrucciones detenidamente. Asegúrese de de disposer de tous les outils et du matériel tener las herramientas y los insumos necesarios nécessaires pour l’installation. -
Page 4: Installation
English Installation Place the bar against the wall. Mark the positions of the screw holes. Drill the holes using a 6 mm bit. Do not drill into existing water lines! Install the anchors. Seal the wall around the anchors with waterproof sealant. Failure to seal the wall can lead to possible water damage. 6 mm... -
Page 5: Instalación
Français Español Installation Instalación Placez la barre murale sur l’emplacement sou- Coloque el soporte de pared en el lugar de- haité. Marquez les positions des trous de vissage. seado. Marque las posiciones de los orificios para tornillos. Percez les trous à l’aide d’une mèche de 6 mm. Perfore los orificios con una broca de 6 mm. Ne percez pas dans les conduites ¡No perfore las tuberías de agua d’eau! existentes! Installez les chevilles. Instale los pernos de anclaje. Scellez le mur autour des chevilles Selle la pared alrededor de los à l’aide d’un agent d’étanchéité. pernos de anclaje con un sellador impermeable. - Page 6 English Install the wallbar using the screws and washers. If the tile does not go all the way up the wall, install the spacer. Install the screw covers. Place a black rubber washer in the short end nut of the handshower hose. Connect this end to the wall supply (not included). Place a second washer in the long end nut of the hose. Connect this end to the handshower (not included). Rest the handshower in the holder.
- Page 7 Français Español Installez la barre murale à l’aide des vis et des Instale el soporte de pared con tornillos y rondelles. arandelas. Si les carreaux ne couvrent pas la surface Si el azulejo no va hasta arriba de la pared, jusqu’au plafond, installez le disque adaptateur. instale el disco que coincida con el azulejo. Installez les cache-vis. Instale las tapas de los tornillos. Placez la rondelle de tuyau en caoutchouc noir Coloque la arandela de goma negra en un dans l’une des extrémités du tuyau. Vissez cette extremo de la manguera. Enrosque este extremo extrémité du tuyau à la sortie pour douchette sur al puerto de la ducha de mano en la válvula (no la valve (pas d'inclus). incluidos). Placez le tamis dans l’autre extrémité du Coloque la arandela de filtro en el otro extremo tuyau. Vissez cette extrémité à la douchette (pas de la manguera. Enrosque este extremo a la d'inclus). ducha de mano (no incluidos). Placez la douchette dans son support. Coloque la ducha de mano en el soporte.
- Page 8 Replacement Parts / Pièces détachées / Repuestos 95171xx0 95129xx0 98992xx0 95172xx0 98058000 96179000 28276xx3 xx = Colors / Couleurs / Acabados 00 = Chrome 62 = Oil Rub Bronze 82 = Brushed Nickel 83 = Polished Nickel 92 = Rubbed Bronze 93 = Polished Brass...
- Page 9 Cleaning Recommendation for Hansgrohe Products Modern bathroom faucets, kitchen faucets and shower products are made from different materials to comply with the needs of the market with regard to design and functionality. To avoid damage to the product, it is necessary to take proper care of it. For best results: • Prevent the buildup of mineral scale and /or soap residue by cleaning your Hansgrohe product(s) when needed. • Select a cleaning agent specifically intended for the type of product. • Do not use these types of cleaners as they will cause damage to your Hansgrohe product: Any cleaning agent containing hydrochloric acid, formic acid, lye, or acetic acid. Abrasive cleaning powders, pads, or brushes. Steam cleaners. “No rinse” cleaning agents. • Always follow the instructions provided by the manufacturer of the cleaning agent. • Do not mix cleaning agents, unless directed by the manufacturer. • Do not spray cleaners directly onto the product as drops could enter openings and gaps and cause damage. When using spray cleaners, spray the cleaner onto a soft cloth or sponge. • Always rinse your Hansgrohe product thoroughly with clear water and polish dry with a soft cloth after cleaning. Important • Residue from soaps and shampoos can cause damage. Rinse the product with clean water after each use.
-
Page 10: Indications Importantes
• Après le nettoyage rincez avec suffisamment d’eau claire pour éliminer les restes de produits attachés. • L’utilisation d’appareil de nettoyage à vapeur n’est pas autorisée, car les températures importantes peuvent détériorer les produits. Indications importantes • Les produits pour le corps comme les savons liquides, les shampooings ou les gels de douche peuvent causer des détériorations. • Ici aussi on doit: Après l’utilisation rincer soigneusement les restes avec de l’eau. Conseil de nettoyage • Les deteriorations imputables à un mauvais entretien ne peuvent être pris en considération par notre garantie. • Par l’action d’un nettoyant sur les revêtements déjà endommagé il se produit une aggravation des dégâts. Recomendación de limpieza para los productos de Hansgrohe Hoy en día, las griferías de baño y de cocina así como duchas modernas se componen de materiales muy distintos para satisfacer las exigencias del mercado respecto al diseño y la funcionalidad. Para evitar daños y reclamaciones hay que tener en cuenta ciertos aspectos tanto en el uso como en su limpieza. -
Page 11: Limited Consumer Warranty
Limited Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products that are purchased by a consumer in the United States or Canada after March 1, 1996, and installed in either in the United States or in Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original purchaser only. This warranty is non-transferable. WHAT IS COVERED BY THE WARRANTY The warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product against defects in material or workmanship as follows: Hansgrohe will replace at no charge for parts only or, at its option, replace any product or part of the product that proves defective because of improper workmanship and/or material, under normal installation, use, service and maintenance. If Hansgrohe is unable to provide a replacement and repair is not practical or cannot be made in timely fashion, Hansgrohe may elect to refund the purchase price in exchange for the return of the product. LENGTH OF WARRANTY Replacement or repaired parts of products will be covered for the term of this warranty, as stated in the following two sentences. If you are a consumer who purchased the product for use primarily for personal, family or household purposes, this warranty extends for as long as you own the product and the home in which the product is originally installed. If you purchased the product for use primarily for any other purpose, including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect to Hansgrohe & Commercial products, and (ii) for 5 years, with respect to Axor products. THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: A. Conditions, malfunctions or damage not resulting from defects in material or workmanship. - Page 12 When warranty service is completed, any repaired or replacement product or part will be returned to you postage prepaid. EXCLUSIONS AND LIMITATIONS REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
