1 Speaker
2 Camera Button
3 Voice Recorder/
Voice Recognition
4 Infrared Port
5 Backlight
6 Volume
7 Power/Backlight
8 Microphone
9 MMC/SD Cards or SDIO
Accessories Slot
10 Touch Screen
11 Navigation Pad
12 Video Camera Lens
13 Notification LED
14 Light Sensor
Listen to audio media or a phone call from here.
Press to launch the camera. Press again to take a
picture.
Press to record a voice note or load the voice
recognition program.
Lets you exchange file(s) or data with other devices
wirelessly.
Press to turn on the backlight.
Slide left or right to adjust the volume.
Press to turn on and off your device or backlight.
Speak into the microphone when receiving or making
a phone call or voice recording.
Lets you insert a storage card (MMC/SD) for storing
data.
Use to write, draw, or make a selection with the
stylus.
Press this multi-directional control up, down, left, or
right to move through menus, program instructions;
carry out the selection by pressing the center button.
Bi-color LED on the right side: Green and Orange
for GSM/WCDMA standby, SMS message, GSM/
WCDMA network status, notification, battery charging
status.
Bi-color LED on the left side: Blue andGreen for
Bluetooth system notification of powered-up and
ready to transmit radio frequency signal, and Wi-Fi
status.
When you use the device in a dark environment, the
system will turn on keyboard backlight as you press
any key.
|
