INSTALLATION MANUAL
IEC & UL version
The Honey/Allmax Module
The Honey Plus Module
The Tallmax Module
The Honey M Module
The Honey/Allmax M Plus Module
The Tallmax M Plus Module
The Trinasmart Module
The Trinaswitch Module
The Trinapeak Module
The Splitmax Module
The Quadmax Module
The Airmax Module
The Spacemax Module
TSM-PC05A
TSM-PC05A.05
TSM-PC05A.08
TSM-PD05
TSM-PD05.05
TSM-PD05.08
TSM-PE05A
TSM-PE05A.08
TSM-PC05A(II)
TSM-PC05A.08(II)
TSM-PC14
TSM-PD14
TSM-PE14A
TSM-DC05A
TSM-DC05A.05
TSM-DC05A.08
TSM-DC05A(II)
TSM-DC05A.05(II)
TSM-DC05A.08(II)
TSM-DD05A(II)
TSM-DD05A.05(II)
TSM-DD05A.08(II)
TSM-DE05A(II)
TSM-DD14A(II)
TSM-DE14A(II)
TSM-PD05.052
TSM-PD05.082
TSM-PD14.002
TSM-DD05A.052(II)
TSM-DD05A.082(II)
TSM-PD05.08S
TSM-DD05A.08S(II)
TSM-DD05A.05S(II)
TSM-PD05.08D
TSM-DC06.08(II)
TSM-PE05H
TSM-DE05H
TSM-PE14H(II)
TSM-DE14H(II)
TSM-DC80.08
TSM-PC05B
TSM-DC03A.08(II)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Trina Solar TSM-PC05A TSM-PC05A.05 TSM-PC05A.08
Summary of Contents for Trina Solar TSM-PC05A TSM-PC05A.05 TSM-PC05A.08
- Page 1 INSTALLATION MANUAL IEC & UL version TSM-PC05A TSM-PC05A.05 TSM-PC05A.08 TSM-PD05 The Honey/Allmax Module TSM-PD05.05 TSM-PD05.08 TSM-PE05A TSM-PE05A.08 TSM-PC05A(II) The Honey Plus Module TSM-PC05A.08(II) TSM-PC14 The Tallmax Module TSM-PD14 TSM-PE14A TSM-DC05A The Honey M Module TSM-DC05A.05 TSM-DC05A.08 TSM-DC05A(II) TSM-DC05A.05(II) TSM-DC05A.08(II) The Honey/Allmax M Plus Module TSM-DD05A(II) TSM-DD05A.05(II) TSM-DD05A.08(II)
-
Page 2: Table Of Contents
Table of Contents DISCLAIMER OF LIABILITY ......................- 3 - SAFETY PRECAUTIONS ........................- 3 - UNPACKING AND STORAGE ......................- 5 - PRODUCT IDENTIFICATION ......................- 6 - ENVIRONMENTAL CONSIDERATIONS AND SITE SELECTION ............- 6 - CLIMATE CONDITIONS ......................- 6 - SITE SELECTION ........................ -
Page 3: Disclaimer Of Liability
• Trina Solar assumes no responsibility for any infringement of patents or other rights of third parties that may result from use of the module. No license is granted by implication or under any patent or patent rights. - Page 4 • Rated electrical characteristics are within ± 10 percent of measured values at Standard Test Conditions of 1000 W/m², 25°C cell temperature and AM 1.5 solar spectral irradiance. • The fire rating of a Trina Solar PV module is valid only when mounted in the manner specified in the mechanical mounting instructions of this installation manual.
- Page 5 Please check the related UL description files when Module Fire Performance: TSM-xxxDD14A(II) checking the fire protection rank of the BOM Type 1/ Type 2 concerned TSM-xxxPE14H(II) TSM-xxxDE14H(II) Date: 2018.7.16 Doc No: PS-M-0434 Ver. D Page - 5 - of 17...
-
Page 6: Unpacking And Storage
• For cUL listed products only: Fire class rating: C • The fire rating of the module is valid only when mounted in the manner specified in the mechanical mounting instructions. • The module is considered to be in compliance with UL1703 only when the module is mounted in the manner specified by the mounting instructions. -
Page 7: Product Identification
5. ENVIRONMENTAL CONSIDERATIONS AND SITE SELECTION 5.1 CLIMATE CONDITIONS Trina Solar Crystalline series modules may be installed in the following conditions for more than 25 years. In addition to the required IEC certification, Trina Solar products have also been tested to verify resistance to ammonia fumes that may be present around barns sheltering cattle, as well as suitability for installation in humid (coastal) areas and areas of high sand storms. -
Page 8: Mounting Instructions
• The frame of each module has 4-φ9*14mm mounting holes, ideally placed to optimize the load handling capability, to secure the modules to supporting structure. • To maximize mounting longevity, Trina Solar strongly recommends the use of corrosion proof (stainless steel) fixings •... -
Page 9: Mounting With Clamps
6) HEX Stainless Nut B. Mounting with Clamps • Trina Solar has tested its modules with a number of clamps from different manufacturers and recommends the use of clamps which have an EPDM or similar insulating washer, fixing bolt of at least •... - Page 10 • Modules clamps should not come into contact with the front glass and must not deform the frame. • Be sure to avoid shadowing effects from the module clamps. • The module frame is not to be modified under any circumstances. •...
-
Page 11: Mounting With Single-Axis Tracking System
5400/2400Pa (IEC), 30 lbs.ft (UL1703) and product failure as a result of an overload situation will not be covered by the Trina Solar warranty. C. Mounting with Single-axis Tracking System • This installation is only for 72 cells polycrystalline modules. -
Page 12: Grounding
National Electrical Codes. The grounding conductor must then make a connection to earth using a suitable earth ground electrode. • Trina Solar modules can be installed with the use of third party listed grounding devices for grounding the metallic frames of PV modules. The devices have to be installed in accordance with the grounding device manufacturer’s specified instructions. - Page 13 www.trinasolar.com. • We also recommend using the following methods to ground installation properly under UL investigation, Method 1: Tyco grounding bolt # 2058729-1: • • • • • • • • • Figure 4. Tyco grounding bolt # 2058729-1 1) Wire bolt and slot 2) Mounting wash hex nut 3) Aluminum frame 0.006 to 0.025in...
-
Page 14: Module Wiring
10V between strings then check the string configuration before making the connection. • Trina Solar modules are provided with stranded copper cables with a cross sectional area of 4mm²(0.006in²) which are rated for 1000V DC, 90°C and are UV resistant.( For TSM-PE05A.**, PE14A.**, 1500 V DC, 90°C and are UV resistant) All other cables used to connect the DC system... -
Page 15: Electrical Configuration
7.2 INVERTER SELETION AND COMPATIBILITY • When installed in systems governed by IEC regulations, Trina Solar modules normally do not need to be electronically connected to earth and therefore can be operated together with either galvanically isolated (with transformer) and transformerless inverters. -
Page 16: Maintenance And Care
• Cover the front surface of modules by an opaque material when repairing. Modules when exposed to sunlight generate high voltage and are dangerous. • Trina Solar PV modules are equipped with bypass diodes in the junction box. This minimizes module heating and current losses. -
Page 17: Warning
• Reporting Technical Issues or Claims: Contact your installer Contact Trina Solar after sales service team at http://customerservice.trinasolar.com/ Submit the Customer Feedback form at: http://www.trinasolar.com/ and one of our technical service representatives will contact you within 5 business days. A username and password is required to send feedback from the customer service link ...
